Dishwasher
Installation Instructions
(To be used in conjunction with User Instructions)
l Please read these Installation Instructions to ensure safe,
correct fitting of this appliance.
l T he dishwasher should be fitted by a suitably competent,
qualified person.
l P lease keep these instructions in a safe place for future reference.
l D anger of suffocation keep packaging material away from children.
Throughout this manual the
following symbols are used.
Warning for hazardous
situations with regard to
life and property.
Warning for
electric shock.
Warning for
risk of fire.
LAM8303

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Lam8303 and is the answer not in the manual?

Questions and answers

Ann
July 23, 2025

Can I raise the upper rack

0
KEITH
July 5, 2025

AFTER PUTTING GLASSES THROUGH A WASH THEY COME OUT ALL MISTED UP WHAT IS THE CAUSE AND CURE PLEASE

0

Related Manuals for Lamona Lam8303

Summary of Contents for Lamona Lam8303

  • Page 1 LAM8303 Dishwasher Installation Instructions (To be used in conjunction with User Instructions) l Please read these Installation Instructions to ensure safe, correct fitting of this appliance. l T he dishwasher should be fitted by a suitably competent, qualified person. l P lease keep these instructions in a safe place for future reference. l D anger of suffocation keep packaging material away from children. Throughout this manual the following symbols are used. Warning for hazardous situations with regard to life and property.

  • Page 2: Table Of Contents

    Safety Information Two person lift. Washing machine Risk of injury: This appliance is not Ensure that all packing must be fixed securely Beware of sharp metal designed for stacking and transit protectors and level. edges. Use gloves when with other appliances. have been removed handling. from the appliance before positioning. Risk of damage to Risk of damage to NOTE: If the electricity Warning: NOTE: Do not leave the appliance: property: Be aware of the dishwasher door open. cable is damaged it Do not attempt to Take care of surrounding instability of the Be careful not to trip must be replaced by a move the appliance area when moving the appliance prior to being over open door. competent person.
  • Page 3 Tools required 24mm open ended spanner DO NOT use high speed impact power tools. T20, flat and cross head screw drivers Parts supplied +50mm A (3.5x14) B (4x43mm) C (4x36mm) www.howdens.com Copyright © 2018 Howden Joinery Ltd. All rights reserved.

  • Page 4: Dimensions

    1 - Dimensions Position the dishwasher 820-920mm relative to service connections. 448mm 550mm 570mm 818mm (+100) 450mm Ensure the floor is level and strong enough to support a fully loaded dishwasher. 15mm 2 - Dishwasher connections max. 1000mm 100mm 1000mm 500mm 500mm 300mm 300mm All dimensions are to the floor. DO NOT insert the hose too deep into the waste pipe, (Maximum hose length, 3.5 metres). www.howdens.com...
  • Page 5 REMOVE CAP/END NOTE: Ensure hoses are not NOTE: If necessary loosen and Ensure cap/end is removed from rotate the water hose towards waste pipe spigot. kinked or trapped behind the the water supply and re-tighten. dishwasher . (Always use the new hose supplied with the dishwasher). Cold water supply 10-80 L/pm. Ensure water is turned on and WARNING! This appliance WARNING! Do not use extension the isolator valve is accessible...

  • Page 6: Fit Feet And Raise 10Mm Below Worktop Height

    3 - Fit feet and raise to 10mm below worktop height For standard installation extension feet need to be fitted. Front feet Foot, max 50mm Plus foot addition +50mm Do not position in cabinet run at this stage. Rear feet 10mm DO NOT use high speed impact power tools. DO NOT damage the plastic screw heads. Flat head screw driver 4 - Locate securing brackets Insert brackets and fold.

  • Page 7: Protection Strip For Timber Worktops

    5 - Protection strip for timber worktops to avoid condensation damage NOTE: This strip must be fitted to timber worktops to avoid damage. Ensure protection strip is set to edge of square edged worktops. Ensure a clean and dust free surface. Cut to fit. 6 - Positioning the dishwasher & NOTE: If necessary loosen and rotate the water hose towards the water supply and re-tighten. Always use the new NOTE: Ensure hoses are not kinked or trapped hose supplied with the behind the dishwasher.

  • Page 8: Adjust Feet And Raise Dishwasher To Underside Of Worktop (Level)

    7 - Adjust feet and raise dishwasher to underside of worktop (level). LEVEL Front feet Rear feet DO NOT use high speed impact power tools. DO NOT damage the plastic screw heads. Flat head screw driver 8 - Remove ‘H’ frame Unscrew the two screws and remove the plastic ‘H’ bracket. Retain the screws for stage 9/10. Cross head A (3.5x14) x2 www.howdens.com...

  • Page 9: Standard Décor Door Preparation

    9 - Standard décor door preparation 267mm Secure with the screws retained from stage 8 plus two additional screws from the accessory bag. Centre line Fit handles at this stage, if A (3.5x14) x4 required, (screws may need countersinking). 10 - Décor drawer frontals preparation 130mm 60mm 267mm 130mm Secure with the screws retained from stage 8 2 x 356mm drawer fronts = 712mm plus two additional screws Normal door height = 716mm Centre from the accessory bag.

  • Page 10: Fit Décor Door / Décor Drawer Frontals

    11 - Fit décor door / décor drawer frontals DO NOT use hole 1, especially when fitting an integrated handle décor door. Fixing for standard décor door. Remove the existing fixings and using the 43mm screws supplied, secure at positions 2 and 5. Ensure correct alignment with the top of the door, (2mm overlap at top). Fixing for décor drawer frontals. Remove the existing fixings and using the 43mm screws supplied, secure at positions 2, 3 and 5. Ensure correct alignment with the top of the door, (2mm overlap at top). DO NOT fully tighten the screws.

  • Page 11: Final Adjustment And Secure Dishwasher

    12 - Final adjustment and secure dishwasher Avoid clash Using feet make final Solid worktop Timber worktop adjustments to height so that the dishwasher touches the underside of the worktop, (side fixing for solid surface worktops and top fixing for timber worktops). A (3.5x14) x4 A (3.5x14) x4 Maximum 450mm (+1) 450mm (+1) 451mm + Side fixing screws to cabinets.

  • Page 12: Fit Plinth

    13 - Fit plinth Once décor door / décor drawer frontals are fitted correctly, fit the plinth. 14 - Switch on water and electric Cold water supply 10-80 L/pm. REMOVE CAP/END Run a programme cycle to confirm successful installation and that there are no leaks. MAKING SPACE MORE VALUABLE Product information correct at the time of publication in June 2018. The company has a policy of continuous product development and reserves the right to change any products and specifications given in this manual. Subject to the Terms and Conditions of Trading, a copy of the Howdens Joinery Terms and Conditions is available upon request. Howden Joinery Ltd, First Floor, 40 Portman Square, London, W1H 6LT. Registered in England 526923 816010AA...
