Summary of Contents for RFT Code Alert Quick Touch Pendant
- Page 1 Quick Touch™ Pendant User Guide...
- Page 2 © 2018 RF Technologies, Inc. All specifications subject to change without notice. All Rights Reserved. No Part of this work may be reproduced or copied in any form or by any means without written permission from RF Technologies, Inc. ® and ™ indicate trademarks owned by RF Technologies, Inc.
-
Page 3: Table Of Contents
Contents CONTENTS CONTENTS ................. 1 WARNINGS AND CAUTIONS ............ 3 Warnings ................3 Bio-Incompatibility Notice ............5 Cautions ................6 PREFACE ..................7 Overview ................7 Intended Audience ..............7 Contact Information ............... 8 Technical Support ............8 Customer Care ............... 8 Sales ................ - Page 4 Contents Testing ................. 17 Visual Inspection............17 Operation ..............17 Cleaning and Care .............. 18 SPECIFICATIONS ..............19 Quick Touch Pendant ............19 REVISION HISTORY..............21 Page 2 of 22 Quick Touch Pendant User Guide 0510-0516-C...
-
Page 5: Warnings And Cautions
Warnings and Cautions WARNINGS AND CAUTIONS It is important for your facility to implement and enforce the following WARNINGS and CAUTIONS in order to keep all equipment functioning properly. Disregarding the information and instructions in this document is considered abnormal use and may result in injury or system failure. - Page 6 Warnings and Cautions INSTALLATION AND CONFIGURATION—It is the responsibility of the facility to follow the installation instructions carefully, as outlined in the applicable system guides, and to use the components and supplies specified by RF Technologies, Inc. for all installations. Failure to use the components and supplies specified by RF Technologies, Inc.
-
Page 7: Bio-Incompatibility Notice
Warnings and Cautions SYSTEM MAINTENANCE AND TESTING—It is the responsibility of the facility to establish and facilitate a regular maintenance schedule for your system, as outlined in the applicable system guides. This includes regular inspection, testing, and cleaning. RF Technologies, Inc. recommends monthly maintenance and testing of your system. -
Page 8: Cautions
Warnings and Cautions Cautions DISPOSAL—At the end of their service life the products described in this manual, as well as accessories (i.e. lithium batteries, banding material, disposable pads, etc.), must be disposed of in compliance with all applicable federal, state and local guidelines regulating the disposal of products containing potential environmental contaminants. -
Page 9: Preface
Preface PREFACE Overview The Quick Touch™ pendant is part of the QR Plus system which immediately notifies staff when a resident requires attention, and provides details that are essential in responding quickly and competently to a resident’s needs. The system offers a variety of devices, each of which interfaces with the Central Server to ensure that when a resident is in need, staff is alerted. -
Page 10: Contact Information
Preface Contact For more information about RF Technologies, Inc. products, go to www.rft.com. Information Technical For technical support, contact the Technical Support Support Team at: (800) 669-9946, option 5 or (262) 790-1771 tech@rft.com Customer For questions on part replacement or for... -
Page 11: General Information
General Information GENERAL INFORMATION Introduction This chapter provides general information about the pendants. It includes information Batteries Alarm activation and clearing Wearing the pendant Pendants The Quick Touch™ Pendant is a small wireless transmitter that enables residents to call for assistance. -
Page 12: Battery
General Information Battery RF Technologies uses only Panasonic 3.0 V Coin Cell Lithium Battery model # CR 2032. These batteries provide 10 to 30 percent more power than other batteries of the same size. Based on use, it will last approximately 1 year. -
Page 13: Alarms
General Information To insert or replace the battery: 1. Using the alarm clearance card or a quarter, turn the battery door counter- clockwise to unlock (align with open padlock icon). 2. Remove the battery door. 3. Insert the CR2032 coin cell battery in the battery compartment. -
Page 14: Low Battery
General Information Low Battery When a low battery is detected, the software will generate a low battery alarm. The Staff will have two days to replace the battery before the yellow low battery LED on the bottom of the pendant begins to blink, informing the resident of the condition. -
Page 15: Wearing The Pendant
General Information Wearing There are three options for wearing the Quick Touch Pendant: around the neck Pendant on the wrist attached to a belt Around the Neck The Quick Touch Pendant with neck lanyard is designed to be worn around the neck. -
Page 16: On The Wrist
General Information On the Wrist The wristband is waterproof and comes attached to the Quick Touch Pendant. The wristband is a standard 16mm width allowing for easy replacement. NOTE: Replacement wristbands must be of similar thickness and material. Metal wristbands are not suitable as the attachment is not reliable. -
Page 17: Storage
Storage STORAGE Storage The Quick Touch Pendant is equipped with an internal backup battery and is shipped in Mode storage mode. Storage mode is the lowest state of the internal battery and designed to protect its life. Storage mode should be used when the pendant is left dormant for a significant period of time. - Page 18 Storage NOTE: If the alarm activation button is pressed when the device is in storage mode and the battery is not installed, the yellow LED illuminates briefly to indicate a missing battery condition. To remove the device from storage mode: 1.
-
Page 19: Testing And Care
Testing and Care TESTING AND CARE Testing The Quick Touch Pendant should be tested monthly to ensure operation. CAUTION: You must test all pendants prior to use to verify proper operation. This includes every time that the band is replaced. Failure to test the pendants before use can result in system failure and/or an elopement. -
Page 20: Cleaning And Care
Testing and Care Cleaning Cleaning should be done by hand using a damp cloth and mild soap or disinfectant and Care wipes designed for household use. CAUTION: To avoid damage to the Quick Touch Pendant, cleaning should only be performed with the battery door in place and in the locked position. -
Page 21: Specifications
Specifications SPECIFICATIONS Quick Touch Pendant 1.6" H x 1.6" W x 0.5" D Size 0.6 oz Weight Off White Pendant with Gray Button Color 3.0V Coin Cell Lithium Battery, CR Power Requirements 2032 1 year battery life (5 alarms per day) Internal non-replaceable battery lasts 3+ years 902-928 MHz, Frequency Hopping... - Page 22 Specifications Part Number Description 1200-7875 Quick Touch Pendant with Necklace 1200-7876 Quick Touch Pendant with Wristband 1200-7871 Replacement Adjustable Necklace 1200-7872 Replacement Wristband 1200-7873 Belt Loop Attachment 1200-7870-5K Alarm Clearance Card with retractable holder (5 pack) 1200-7874 Replacement Battery Door Page 20 of 22 Quick Touch Pendant User Guide 0510-0516-C...
-
Page 23: Revision History
Revision History REVISION HISTORY Revision Change Release Added user activation information Updated format and logos Updated copyright dates, contact information, and graphics Updated Cleaning and Care section Quick Touch Pendant User Guide Page 21 of 22 0510-0516-C... - Page 24 0510-0516-C 3125 North 126th Street, Brookfield, WI 53005 Phone 800.669.9946 fax 262.790.1784 Release Date: 11/2018 www.rft.com...
