Installation
'Network' tab. After doing so, click the 'Save Settings' button, wait 10 seconds and re-attach the
Room Alert Signal Tower unit to the network.

Device Not Found Or Invalid IP Address

If the Room Alert Signal Tower is not discovered by the AVTECH Device Discovery Utility, the
network may be blocking UDP broadcast packets on port 30718. Even if the Room Alert Signal Tower
obtains a valid IP address, this can prevent the Room Alert Signal Tower unit from being discovered. To
resolve this issue, check the DHCP server for the MAC address listed on the label located on the bottom
of the Room Alert Signal Tower unit. If this is not possible or if there is not an entry in the DHCP
server, follow the instructions listed under the 'Static-Only Networks' subsection above.
If the Room Alert Signal Tower unit is discovered although has a '169.xxx.xxx.xxx' IP address, the Room
Alert Signal Tower unit may not have been connected properly or DHCP assignment may currently be
getting blocked. In either case, follow the instructions listed in the 'Static-Only Networks' subsection above.
NOTE: If the instructions provided do not allow configuration of the Room Alert Signal Tower unit, please initiate a Live
Chat technical support request on AVTECH.com or send an email support request to Support@AVTECH.com.
Step 4:
Connect Sensors And Accessories
The graphics below identify the connection ports and channels of the Room Alert Signal Tower ID box
that are visible on the front and rear panels. Use these to connect the appropriate sensors and accessories.
A. Digital Temperature Sensors — Connect the included AVTECH Digital
Temperature Sensor to one of the External Environment Sensor Channels shown
above (A / B). The Digital Temperature Sensor provides a real-time digital
temperature reading at the location of the temperature probe. Position the sensor
in the desired location, running the sensor cable back to the Room Alert Signal
Tower ID box. DO NOT remove the red plastic cap from the tip of the sensor.
B. Digital Temperature/Humidity Sensors (Audio Model Only) — Connect the included
AVTECH Digital Temperature/Humidity Sensor to one of the External Environment Sensor
Channels shown above (A / B). The Digital Temperature/Humidity Sensor provides a real-time
digital temperature and humidity reading at the location of the temperature/humidity probe.
Position the sensor in the desired location, running the sensor cable back to the Room Alert
Signal Tower ID box. DO NOT remove the blue plastic cap from the tip of the sensor.
8
Front View (Room Alert Signal Tower ID Box)
A / B C
Room Alert Signal Tower
