234Z
KPD616
MPEG-4 DVR QUICK
ROHS AND WEEE
All lead-free products offered by the company comply with the requirements of the European law on
the Restriction of Hazardous Substances (RoHS) directive, which means our manufacture processes
and products are strictly "lead-free" and without the hazardous substances cited in the directive.
The crossed-out wheeled bin mark symbolizes that within the European Union the product must be
collected separately at the product end-of-life. This applies to your product and any peripherals
marked with this symbol. Do not dispose of these products as unsorted municipal waste.
Please read this instruction thoroughly before operation and retain it for future reference.
The image shown above may differ from the actual product appearance.
KPD616 Quick _V0.81

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KPD616 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Avtech KPD616

  • Page 1 Do not dispose of these products as unsorted municipal waste. Please read this instruction thoroughly before operation and retain it for future reference. The image shown above may differ from the actual product appearance. KPD616 Quick _V0.81...
  • Page 2: Product Description

    1. OVERVIEW 1.1 Product Description This MPEG-4 multiplex network DVR series combined remote surveillance, burglar prevention, and evidentiary recording features and is designed to become a simple entry-level system with all necessary functions. 1.2 Package Contents □ Digital Video Recorder (DVR) □...
  • Page 3 Note: Due to panel position difference, please place the vertical panel sticker on the removed controller for operation convenience. (Menu) Press this button to enter / exit the quick start menu. Under the sub-layer of the advanced setting menu, use this button to confirm the settings and go back to the upper layer. LIVE Press this button to stop the playback and return to the live mode.
  • Page 4: Remote Controller

    (Key lock) Press this button to lock keys on the DVR front panel. (Digital zoom) Press this button to enlarge the image of the selected channel. 14) ▲ / ▼ / ◄ / ► Press one of these direction buttons to move the cursor up/down/left/right. Under DVR menu mode, these direction buttons can use for the following operation: ▲...
  • Page 5: Rear Panels

    2.3 Rear Panels MONITOR RS485 EXTERNAL I/O RI SK OF E LEC TR IC S HO CK LINK DO NOT OPEN ACT. WARNI NG : TO REDUCE THE RISK O F ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED DC 19V SERVICE PERSONNEL.
  • Page 6: Connections And Setup

    3. CONNECTIONS AND SETUP 3.1 Install HDD Step 1: Loose the screws on the upper cover and open the upper cover of the DVR. Step 2: Screw out the L-shape HDD brackets. Two brackets are used to secure a HDD, and there are 4 of them. Step 3: Get a suitable brand HDD and set the HDD mode (Master or Slave).
  • Page 7: Basic Operation

    4. BASIC OPERATION 4.1 Recording This device offers non-stop recording mode. If the power is off accidentally, the recorded video data will not be lost and is safely stored in the HDD. The device will return to the original recording status after the power is on again. When the HDD is full, this device will overwrite 8GB data from the oldest for continuous recording without notice.
  • Page 8: Key Lock And Unlock

    Icon “ ” means: Live audio of the 3 audio channel / Icon “ ” means: Playback audio of the 3 audio channel Icon “ ” means: Live audio of the 4 audio channel / Icon “ ” means: Playback audio of the 4 audio channel Icon “...
  • Page 9: Menu Configuration

    5. MAIN MENU 5.1 Menu Configuration CHANNEL TITLE STATUS EVENT STATUS CHANNEL STATUS IMAGE SIZE RECORD QUALITY IMAGE PER SECOND QUICK START MENU TIMER TIMER DATE DATE FORMAT DAYLIGHT SAVING CAMERA DETECTION ADVANCE CONFIG ALERT NETWORK DISPLAY SERIAL TYPE BAUD RATE HOST ID PASSWORD RESET DEFAULT...
