Nemtek Druid LCD 2X Network Manual page 6

4 4-Zone Keypad Energizer Setup B
c. Ensure the energizer is restored to factory default:
i. Reconnect the battery power. [2]
ii. Reconnect the mains power. [1]
iii. Within 60 seconds of reconnecting the power, enter 2389# on the keypad.
d. Enter installer mode by entering 012345*0#. Ensure the energizer LCD
display turns purple. [4]
e. Enter 5001*# to activate 4-zone mode. Refer to the Druid LCD installer
manual for more detail on the codes.
f. Configure all user-preferences, for example alarm bypasses, specific to this
energizer as individual energizer configuration is not possible once connected
in the 4-zone configuration.
g. Exit installer mode by entering *#. Ensure the energizer LCD display turns
blue. [4]
h. Disconnect the energizer mains and battery power. [1, 2]
i. Remove the keypad from the energizer. [3]
2. Set up the slave energizer:
a. Disconnect the energizer mains and battery power. [5, 6]
b. Connect the keypad to the slave energizer and reset to factory default by
following the same procedure as the master. [7]
c. Configure all user-preferences, for example alarm bypasses, specific to this
energizer as individual energizer configuration is not possible once connected
in the 4-zone configuration.
d. Insert the slave jumper JP3. [8]
e. Power up the energizer by first connecting
the battery and then the mains power. [6, 5]
f. Ensure that "SLAVE" is displayed on the LCD. [9]
g. Disconnect the energizer mains and battery
power. [5, 6]
h. Remove the keypad from the energizer. [7]
