9
EQUATOR
COMBINATION OVENS
GAS
MECHANICAL & ELECTRONIC
MANUFACTURER'S INSTRUCTIONS
Part A: Technical data
Part B: Installation manual
WARNING -
•
Installation and repairs must be carried out by personnel approved by the manufacturer and in
accordance with current regulations and standards.
•
If any modifications are made the manufacturer can accept no responsibility whatsoever.
•
These appliances must be used in a well-ventilated area.
•
Read the notice carefully before installation.
•
The unit must be kept on its base for handling until it is in it's final location.
N° 390 247c
Advertisement
Table of Contents
Related Manuals for Bonnet EQUATOR
Summary of Contents for Bonnet EQUATOR
- Page 1 EQUATOR COMBINATION OVENS MECHANICAL & ELECTRONIC MANUFACTURER’S INSTRUCTIONS Part A: Technical data Part B: Installation manual WARNING - • Installation and repairs must be carried out by personnel approved by the manufacturer and in accordance with current regulations and standards.
-
Page 2: Table Of Contents
3.2 Gas connection ………...……..………….…………………..………. 13 3.3 Water connection ………...……...…………………………..……..14 3.4 Drain connection ……….……………………………...……………... 15 Changing the appliance from one gas to another ………………..…..… 17 BONNET CIDELCEM GRANDE CUISINE Siége social: Rue des Frères Lumière - Z.I Mitry Compans 77292 MITRY MORY Cedex... -
Page 3: A) Technical Data
Page 2 A: TECHNICAL DATA Equator, Mechanical direct injection MIDG 6 1/1 Gas P120E21: Height 995; Width 985, Depth 890 DIMENSIONS (mm) Outside Cavity Height 860; Width 630; Depth 555 Vision panel Height 455; Width 555 CAPACITIES Effective cavity volume (dm... - Page 4 Page 3 Equator, Mechanical direct injection MIDG 10 1/1 Gas P120E22 DIMENSIONS (mm) Outside Height 1275; Width 985, Depth 940 Cavity Height 897; Width 630; Depth 555 Vision panel Height 790; Width 555 CAPACITIES Effective cavity volume (dm GN 1/1 trays (325 x 530)
- Page 5 Page 4 Equator, Mechanical direct injection, MIDG 20 1/1 Gas P120E23 DIMENSIONS (mm) Outside Height 1925; Width 1040, Depth 1110 Cavity Height 1465; Width 630; Depth 565 Vision panel Height 800; Width 555 CAPACITIES Effective cavity volume (dm GN 1/1 trays (325 x 530)
- Page 6 Page 5 Equator, Electronic with boiler, ECG 20 1/1 Gas P130E23 DIMENSIONS (mm) Outside Height 1915; Width 1040, Depth 1110 Cavity Height 1465; Width 630; Depth 565 Vision panel Height 800; Width 555 CAPACITIES Effective cavity volume (dm GN 1/1 trays (325 x 530)
- Page 7 Page 6 Equator, Electronic with boiler, ECG 20 2/1 Gas P130E33 DIMENSIONS (mm) Outside Height 1915; Width 1040, Depth 1435 Cavity Height 1465; Width 630; Depth 955 Vision panel Height 800; Width 555 CAPACITIES Effective cavity volume (dm GN 1/1 trays (325 x 530)
- Page 8 DIMENSIONS (mm) Height Width Depth 723.5 PACKAGING (mm) Height Width 1000 Depth WEIGHT (kg) Non-contractual document Edition 07/1999 - EN126 Module with runners BONNET CIDELCEM GRANDE CUISINE Siége social: Rue des Frères Lumière - Z.I Mitry Compans 77292 MITRY MORY Cedex...
- Page 9 13 / 64 Height 2000; Width 700; Depth 600 PACKAGING (mm) Non-contractual document Edition 10/2000 – EN127 Equator, 20 level manual handling trolleys BONNET CIDELCEM GRANDE CUISINE Siége social: Rue des Frères Lumière - Z.I Mitry Compans 77292 MITRY MORY Cedex...
- Page 10 Height 2000; Width 700; Depth 900 WEIGHT (kg) (Empty) Non-contractual document Edition 07/1999 - EN128 Equator, Banqueting trolley plate holder and trolley covers for 20 level ovens BONNET CIDELCEM GRANDE CUISINE Siége social: Rue des Frères Lumière - Z.I Mitry Compans...
- Page 11 160 kg (products + plates) Plates 285mm ∅ PACKAGING (mm) Height 2000; Width 700; Depth 900 WEIGHT (kg) (Empty) Non-contractual document Edition 07/1999 - EN129 BONNET CIDELCEM GRANDE CUISINE Siége social: Rue des Frères Lumière - Z.I Mitry Compans 77292 MITRY MORY Cedex...
-
Page 12: B) Installation Manual
NOTE: The connected Gas/Pressure for which the appliance is set must be authorised in the country in question. Check this point in the table in section: Changing the appliance from one gas to another.. BONNET CIDELCEM GRANDE CUISINE Siége social: Rue des Frères Lumière - Z.I Mitry Compans... -
Page 13: Installation: General Features
2.3 UNPACKING Before installation, remove the strapping. The individual parts are not bolted down. Remove plastic coating from stainless steel before heating the appliance. BONNET CIDELCEM GRANDE CUISINE Siége social: Rue des Frères Lumière - Z.I Mitry Compans 77292 MITRY MORY Cedex... -
Page 14: Installation: Connections
The gas supply pipe will be sized so as to minimise losses of load : its diameter is determined according to its distance (length, ,number of bends...) and the total power of the appliance. BONNET CIDELCEM GRANDE CUISINE Siége social: Rue des Frères Lumière - Z.I Mitry Compans... -
Page 15: Water Connection
- Inlet at the rear, male thread 15/21 mm ∅ ∅ ∅ ∅ for 20 level ovens. - All damage resulting from scale deposits (sides of the cavity, elements, turbine, hydraulic pipes...) will not be covered by warranty. BONNET CIDELCEM GRANDE CUISINE Siége social: Rue des Frères Lumière - Z.I Mitry Compans... -
Page 16: Drain Connection
APPLIANCE DIRECTLY TO DRAIN. In order to avoid any waste water entering the cooking cell an air break must be installed BETWEEN the appliance and the external drain. BONNET CIDELCEM GRANDE CUISINE Siége social: Rue des Frères Lumière - Z.I Mitry Compans... - Page 17 ∆ ∆ ∆ ∆ The air gap must be lower than the height of the oven drain. This water could be at high temperature (98° C) so t he use of PVC is not recommended. BONNET CIDELCEM GRANDE CUISINE Siége social: Rue des Frères Lumière - Z.I Mitry Compans...
-
Page 18: Changing The Appliance From One Gas To Another
Netherlands II 2L3B/P G 30 28-30 G 31 G 25 II 2L3P G 31 Norway G 30 28-30 I 3B/P G 31 BONNET CIDELCEM GRANDE CUISINE Siége social: Rue des Frères Lumière - Z.I Mitry Compans 77292 MITRY MORY Cedex... - Page 19 - The gas and pressure for which the appliance will be set. - Select and carry the required operations. - Replace the setting plate (code: 308875), and tick the new gas used. BONNET CIDELCEM GRANDE CUISINE Siége social: Rue des Frères Lumière - Z.I Mitry Compans...
- Page 20 Change of category to be carried out under responsibility of our company or our local representative. 4.1.3 GAS OUTLETS AND POWERS See section 1: Technical data. BONNET CIDELCEM GRANDE CUISINE Siége social: Rue des Frères Lumière - Z.I Mitry Compans...
- Page 21 Air ring: The diameter d (mm) refers to hole in the ring. ∅ d ∅ 26 75421M ∅ 28 75421N ∅ 35 27367P BONNET CIDELCEM GRANDE CUISINE Siége social: Rue des Frères Lumière - Z.I Mitry Compans 77292 MITRY MORY Cedex...
- Page 22 G 31 G 20 Switzerland II 2H3P G 31 37/50 G 30 I 3B/P G 31 G 30 Norway I 3B/P G 31 BONNET CIDELCEM GRANDE CUISINE Siége social: Rue des Frères Lumière - Z.I Mitry Compans 77292 MITRY MORY Cedex...
- Page 23 - The gas and pressure for which the appliance will be set. - Select and carry the required operations. - Replace the setting plate (code: 308875), and tick the new gas used. BONNET CIDELCEM GRANDE CUISINE Siége social: Rue des Frères Lumière - Z.I Mitry Compans...
- Page 24 Change of category to be carried out under responsibility of our company or our local representative 4.2.3 GAS OUTLETS AND POWERS See section 1: Technical data BONNET CIDELCEM GRANDE CUISINE Siége social: Rue des Frères Lumière - Z.I Mitry Compans...
- Page 25 (Ref: K14) G 31 * Controller switched off. ** Indicate the diameter after the code. IDENTIFYING THE INJECTORS for 20 GN 1/1 ovens BONNET CIDELCEM GRANDE CUISINE Siége social: Rue des Frères Lumière - Z.I Mitry Compans 77292 MITRY MORY Cedex...
- Page 26 - Turn screw (RP) until a ″click″ is heard. - Re-seal RP in the same way it was sealed in the factory. - Refit the cover (A). BONNET CIDELCEM GRANDE CUISINE Siége social: Rue des Frères Lumière - Z.I Mitry Compans...
