EcoSmart ESGH-95-DVLN-2 Use And Care Manual

High-efficiency condensing tankless gas water heaters
designed for endless hot water.
Efficiency
• Up to .93 UEF with stainless steel condensing heat
exchanger
Easy Installation and Service
2" venting connections
•
Vent up to 150 ft with 3" PVC and 60 ft with 2" PVC
•
• Built-in condensate neutralizer
• 1/2-inch Gas line compatibility up to 24 ft
Maintenance Notice Setting – alerts homeowner, after
•
500 hours of use, to call for service check (optional)
• Self-diagnostic system for easy installation and service
• High-altitude capability – up to 8,400 ft elevation above
sea level
2
Digital remote control pre-wired and 10
•
ft of thermostat wire included – shows
temperature setting and service codes
• Requires 120V power supply
Performance
Industry Leading! Low Flow Activation – minimum flow
•
rate of .26 GPM and minimum activation flow rate of .40
GPM ensures the user will receive hot water even in low
demand situations
Recirculation Pump Kit-Ready – providing faster hot
•
water at the tap and savings of up to 12,000 gallons
water/year
3
Hot Start Programming – minimizes cold water bursts by
•
staying in ready-fire state for back-to-back hot water
needs
Based on internal testing of 1/2" gas line with gas supply of 7" w.c. up to 24'; Installation conditions vary; Consult the Use and Care Manual, the National Fuel Gas Code (NFPA 54, ANSI Z223.1), and any other
1
local gas codes when installing an EcoSmart Tankless Water Heater.
Indoor Direct Vent
1
2 Contact customer service for exact altitude rating for each model.
DOE test procedures.
Technology
EcoNet Enabled – all gas tankless products from 2010 to
®
•
present can connect to EcoNet mobile app via Tankless
EcoNet Accessory Kit (REWRA630TWH)
• For higher demand applications, easily link multiple
tankless units to operate as one system
Environmentally Friendly
Low Emissions – ultra low NOx burner meets SCAQMD
•
rule 1146.2 requirements
Water Savings Setting – upon activation, this setting can
•
save up to 1,100 gallons water/year
the tap until set temperature is achieved (optional)
Safety
Guardian overheat film wrap - prevents dangerous
•
temperatures and provides industry best side-to-side
clearance of 1/2-inch
Industry Best! Freeze protection to -30°F
•
Warranty
• 12-Year heat exchanger – residential, 5-year heat
exchanger – commercial, 5-year parts and 1-year labor
See Warranty Certificate for complete information
See specifications chart on back.
3 Pump kit designed for single unit applications only.
Outdoor
by reducing flow at
4
LEED Points = 2
4 Savings based on
