- Page 1 ® POWER SYSTEMS, INC. Post Installation Start-up and Adjustment Manual Air-cooled, Prepackaged Standby Generators Models: 04109-2 (8 kW) 04079-2 (10 kW)
-
Page 2: Before Initial Start-Up
Section 1 — Post Installation Start-up and Adjustments Guardian Air-cooled Generators Section 1 – Post Installation Start-up BEFORE INITIAL START-UP and Adjustments ..........2 Before starting, complete the following: Before Initial Start-up ......2 1. Set the generator's Auto/Off/Manual switch to the Battery Installation ........2 OFF position. -
Page 3: Section 1 - Post Installation Start-Up And Adjustments
Section 1 — Post Installation Start-up and Adjustments Guardian Air-cooled Generators Figure 1.1 – Battery Cable Connections 4. When certain that utility supply voltage is com- patible with transfer switch and load circuit rat- ings, turn OFF the utility power supply to the transfer switch. -
Page 4: Setting The Exercise Timer
Section 1 — Post Installation Start-up and Adjustments Guardian Air-cooled Generators With the Auto/Off/Manual switch at AUTO, the engine should crank and start when the utility source power is turned OFF . After starting, the transfer switch Do not attempt manual transfer switch opera- should connect load circuits to the standby side. -
Page 5: Engine Governor Adjustment
Section 1 — Post Installation Start-up and Adjustments Guardian Air-cooled Generators ADJUSTING THE LOAD BLOCK 3. Start the engine; let it stabilize and warm up at no-load. When the natural gas system is being used, the load 4. Turn the speed adjust nut to obtain a frequency block is fitted with an adjustment screw that has reading of 62 Hertz. -
Page 6: Voltage Regulator Adjustment
Section 1 — Post Installation Start-up and Adjustments Guardian Air-cooled Generators 1.10 VOLTAGE REGULATOR 1.11 ADDITIONAL GENERATOR ADJUSTMENT FEATURES With the frequency between 61-62 Hertz, slowly turn 1.11.1 8 KW AND 10 KW UNITS the slotted potentiometer (Figure 1.4) until line volt- age reads 244-252 volts. -
Page 7: Section 2 - Notes
Section 2 — Notes Guardian Air-cooled Generators ® Generac Power Systems, Inc. - Page 8 ® GENERAC POWER SYSTEMS, INC. 757 NORTH NEWCOMB ROAD WHITEWATER, WI 53190 PH: (262) 473-5514 • FA X: (262) 472-6511 Part No. D1962 Revision 0 (11/08/00) Printed in U.S.A.
