Complete
H
Sliding Track
1. Connect the power button cable to the
2. Align the motherboard tray with the two sliding
System Panel Header on the motherboard.
tracks on the chassis while sliding it back to the
chassis.
Installing the VESA Bracket (Optional)
1. Secure the VESA Bracket to the
2. Attach the other VESA Bracket to the
3. Mount the DeskMini 110 series
right side panel of the DeskMini 110
rear of a compatible display using the
by turning it counterclockwise.
series by using the four screws.
four screws.
*Choose mounting holes depending on the
mounting hole pattern of your LCD screen
(75 mm × 75 mm or 100 mm × 100 mm).
