thumb screws
for seat depth
closing the release lever. (fig.2b)
tilt the chair to the required position
then let go of the release lever.
In powered options exercise care in case
of injury to Patient or damage to
surrounding environment.
SeAt dePth: to increase or
•
decrease seat depth, loosen the thumb
screws set at 45 degrees under the
seat. (fig.3 & fig.3b) adjust the seat to
the required depth by carefully pulling
the seat out. tighten the screws again to
ensure the seat depth doesn't
unintentionally change. (fig3b)
• ArM reMovAl: to remove the arms,
loosen the thumb screws behind and in
front of the arm (fig.3a & fig.3b) and
carefully pull the arm out and leaving it
in a safe place to avoid tripping hazards
or other injuries. When replacing the arms
back on to the chair, ensure the thumb
screws are tightened against the frame
of the arm.
arm removal
seat depth
• SeAt Width: to increase the seat
width of the chair, loosen the thumb
screws behind and in front of the arm
(fig.3a & fig.3b) and carefully pull the
arm out. this can be set at any position.
ensure the thumb screws are tightened
again to hold the arm in position.
Phoenix Instruction Manual
™
(fig.3)
seat belt loop
arm removal
(fig.3a)
(fig.3b)
