Seating Matters Phoenix Operating Manual page 16

head rest
adjustment
shoulder
support
adjustment
seat belt loops
(fig.2)
BAcK Angle AdJUStMent:
•
(available on certain models) to recline
the back of the chair, the user must
inform the Patient then stand behind the
chair and with two hands, firmly hold the
push handle while closing the release
lever (fig. 2a). Move the back of the chair
slowly until it is in the required position
and allow the release lever to move to its
relaxed position before letting go of the
push handles. (fig.2) In powered options,
exercise care in case of injury to Patient
or damage to surrounding environment.
adjustments are performed according to
the buttons on the handset.
• tilt in SPAce: to tilt the chair, the
user must first inform the Patient then
stand behind the chair and with two
hands, firmly hold the push handle while
14
tilt in
space
www.seatingmatters.com
back angle adjustment
tilt in space
back angle
adjustment
adjustable
Wing knob
spring Plunger
(fig.2a)
(fig.2b)
