- Page 1 SLM750 User Manual File Name：SLM750 User Manual Version Number：V1.6 Company：Shenzhen MEIG SMART TECHNOLOGY Co., LTD Release Date：2017/8/18...
- Page 2 COPYRIGHT NOTICE Copyright, Shenzhen MEIG SMART TECHNOLOGY Co., LTD All rights reserved. This file and its contents are exclusively owned by Shenzhen MEIG SMART TECHNOLOGY Co. , LTD, under the protection of Chinese laws and applicable copyright laws in international conventions. Anyone shall not copy, spread, distribute, modify or use other ways to apply this file or its contents.
-
Page 3: Important Note
cause undesired operation. This device has been tested and found to comply with the limits for a Class B digital device , pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiated radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. -
Page 4: Label Of The End Product
be informed that any changes or modifications not expressly approved by the manufacturer could void the user's authority to operate this equipment. If the size of the end product is smaller than 8x10cm, then additional FCC part 15.19 statement is required to be available in the users manual: This device complies with Part 15 of FCC rules. - Page 5 Revising records Version Date Author Comments V1.0 2016/6/28 Li Yan Create V1.1 2016/11/15 Song Nan Add descriptions of key technologies V1.2 2017/03/09 Song Nan Add SLM750 C7C V1.3 2017/04/19 Song Nan Add descriptions of B5 V1.4 2017/05/04 Song Nan Revise name of SLM750 C5B V1.5 2017/07/04 Gao Mingjun...
- Page 6 SLM750 series of M2M modules are designed to provide customers with wireless communication service. It covers three operators’ network in domestic and the main operators’s network of the world. It delivers maximum 150Mbps-DL and 50Mbps-UL data rates on LTE networks, and has backward compatibility with 3G and 2G networks to ensure that network communication is working in remote areas.
-
Page 7: General Features
Specification of SLM750 General Features Package：LCC（80pin+LGA 64pin） Size: 32.0×29.0×2.4mm Weight: About 5g Data Features LTE FDD (CAT 4): Max 150Mbps(DL)/50Mbps(UL) TD-LTE (CAT 4): Max 130Mbps(DL)/35Mbps(UL) LTE (CAT 1): Max 10Mbps(DL)/5Mbps(UL) DC-HSPA+: Max 42Mbps(DL)/5.76Mbps(UL) TD-SCDMA: Max 4.2Mbps(DL)/2.2Mbps(UL) WCDMA: Max 384kbps(DL)/384kbps(UL) EDGE: Max 236.8kbps(DL)/236.8kbps(UL) GPRS: Max 85.6kbps(DL)/85.6kbps(UL) EVDO RevA: Max 3.1Mbps(DL)/1.8Mbps(UL) - Page 8 SLM750 series Voice/Analog Frequencies GNSS Diversity voice LTE FDD: B1/B3/B5/B8 TD-LTE: B38/B39/B40/B41 WCDMA: B1/B8 SLM750-C7A Yes / Optional TD-SCDMA: B34/B39 CDMA&EVDO: BC0 GSM: 900/1800 LTE FDD: B1/B3/B5/B8 TD-LTE: B38/B39/B40/B41 WCDMA: B1/B8 SLM750-C7B Yes / Optional TD-SCDMA: B34/B39 CDMA&EVDO: BC0 GSM: 900/1800...
- Page 9 LTE FDD: B1/B3/B5/B7/B8/B20 SLM750-G2E Optional Optional/Optional WCDMA: B1/B8 LTE FDD: B2/B4/B5/B7/B28 SLM750-G2C Optional/Optional WCDMA: B2/B4/B5 LTE FDD: B1/B3/B5/B8 SLM750-G2D TD-LTE: B40 Optional Optional/Optional WCDMA: B2/B4/B5 SLM750-G2J LTE FDD:B2/B4/B5/B12/B17 Optional Optional/Optional LTE B2/B25 SLM750-G2M Optional Optional/Optional WCDMA:B1 SLM750-C1A LTE FDD: B1/B3/B5/B8 Optional Optional No/No...
-
Page 10: Transmit Power
Transmit Power GSM900 33±2dBm，GSM1800 30±2dBm，GSM850 33±2dBm, GSM1900 30±2dBm CDMA/EVDO 23~30dBm, WCDMA/HSPA 23+1/-3dBm， TD-SCDMA 23+1/-3dBm，TD-LTE 23±2.7dBm， LTE FDD 23±2.7dBm Protocols TCP/UDP/HTTP/FTP/PPP/PING/DTMF/QMI Working Environment Drivers & Tools ： Drivers：Windows XP, Windows Vista, Restrict Working Temperature -40℃ to 85℃ Windows 7, Windows 8, Windows 8.1, : -45℃... -
Page 11: Antenna Type
Antenna type Dipole Antenna Antenna gain Standalone Collocated Maximum Maximum Device Band Antenna Antenna Gain (dBi) Gain (dBi) GSM850 GSM1900 CDMA2000 BC0 CDMA2000 BC1 WCDMA Band II WCDMA Band IV WCDMA Band V LTE Band 2 SLM750-TA LTE Band 4 LTE Band 5 LTE Band 12 LTE Band 13...
