Page 1 INSTALLATION GUIDE PTP 820C HP System Release 10.0...
Page 2 Accuracy While reasonable efforts have been made to assure the accuracy of this document, Cambium Networks assumes no liability resulting from any inaccuracies or omissions in this document, or from use of the information obtained herein. Cambium reserves the right to make changes to any products described...
Page 3: Table Of Contents
Unpacking ............................2-2 Inspection ............................2-2 Chapter 3: Product Hardware Description ..................3-3 PTP 820C HP Hardware Overview ....................3-4 PTP 820C HP Interfaces ....................... 3-5 Field-Replaceable Diplexers ....................... 3-6 MultiCore Mediation Devices (MCMD) .................... 3-9 Adaptors and Installation Kits ......................3-12 Antenna Connection ........................
Page 4 Preparing the Ethernet Cable and Plug-in Field ..............4-27 Preparing the Ethernet Cable Already Assembled ..............4-30 Connection of Ethernet Cable to PTP 820C HP ............... 4-30 Management Connection for 1+1/2+2 HSB Configurations ............4-33 Preparing a MIMO/Protection Signaling Cable ..............4-33 Connecting the MIMO/Protection Splitters and Protection Signaling Cable .......
Page 5 Contents List of Items ..........................6-2 Required Tools ..........................6-2 Insertion Loss ..........................6-3 Procedure ............................. 6-3 MultiCore 2+0 Dual Polarization Remote Mount ................6-5 List of Items ..........................6-5 Required Tools ..........................6-6 Insertion Loss ..........................6-6 Procedure ............................. 6-6 MultiCore 2+0 Single Polarization Direct Mount ................
Page 6 Required Tools .......................... 6-73 Insertion Loss ..........................6-74 Procedure ........................... 6-74 Chapter 7: Installing PTP 820C HP on Third-Party Antenna Adaptors ........7-77 Special Note on Converting ValuLine 3 Antennas ................7-1 Chapter 8: Acceptance and Commissioning Procedures .............. 8-2 Site Acceptance Procedure .......................
Page 7 Contents Site Acceptance Checklist Notes ...................... 8-5 Radio Link Commissioning Procedure ..................... 8-7 Scope ............................8-7 Commissioning Test ........................8-7 PTP 820 Commissioning Log ......................8-9 phn-4794_001v000 Page v...
Page 8: List Of Figures
Figure 18 PTP 820C HP Installation – Radio and Diplexers Unit Pre-Assembled ......5-6 Figure 19 PTP 820C HP Installation – Attaching the Diplexers Unit Before the Radio Unit ....5-6 Figure 20 Fitting the Diplexer Unit to the Radio Unit - Radio Side ............ 5-8 Figure 21 Fitting the Diplexer Unit to the Radio Uni - Diplexer Unit Side ........
Page 9: List Of Tables
Contents List of Tables Table 1 MCMD Comparison ........................3-9 Table 2 Adaptors and Installation Kits ....................3-12 Table 3 Antenna Circ. Adapters for OMT .................... 3-12 Table 4 Antenna Flanges ........................3-13 Table 5 Antenna Flange Adaptors ....................... 3-13 Table 6 Cable Grounding Kit.
Page 10: About This User Guide
About This User Guide This guide describes the PTP 820C HP installation procedures and provides additional information concerning system parts and frequency bands This guide contains the following chapters: • Chapter 1: Product description • Chapter 2: Pre-Installation Instructions •...
Page 11: Purpose
Problems and warranty Purpose Cambium Networks Point-To-Point (PTP) documents are intended to instruct and assist personnel in the operation, installation and maintenance of the Cambium PTP equipment and ancillary devices. It is recommended that all personnel engaged in such activities be properly trained.
Page 12: Problems And Warranty
Cambium’s standard hardware warranty is for one (1) year from date of shipment from Cambium Networks or a Cambium distributor. Cambium Networks warrants that hardware will conform to the relevant published specifications and will be free from material defects in material and workmanship under normal use and service.
Page 13: Security Advice
Security advice Security advice Cambium Networks systems and equipment provide security parameters that can be configured by the operator based on their particular operating environment. Cambium recommends setting and using these parameters following industry recognized security practices. Security aspects to be considered are protecting the confidentiality, integrity, and availability of information and assets.
Page 14: Warnings, Cautions, And Notes
Warnings, cautions, and notes Warnings, cautions, and notes The following describes how warnings and cautions are used in this document and in all documents of the Cambium Networks document set. Warnings Warnings precede instructions that contain potentially hazardous situations. Warnings are used to alert the reader to possible hazards that could cause loss of life or physical injury.
Page 15: Caring For The Environment
Caring for the environment The following information describes national or regional requirements for the disposal of Cambium Networks supplied equipment and for the approved disposal of surplus packaging. In EU countries The following information is provided to enable regulatory compliance with the European Union (EU) directives identified and any amendments made to these directives when using Cambium equipment in EU countries.
Page 16: Chapter 1: Product Description
Chapter 1: Product description Cambium’s PTP 820C HP represents a new generation of radio technology, capable of high bit rates and longer reach, and suitable for diverse deployment scenarios. PTP 820C HP supports cutting edge capacity-boosting techniques, such as QPSK to 2048 QAM and Header De-Duplication, to offer a high capacity solution for every network topology and every site configuration.
Page 17: Important Notes
• PTP 820C HP is intended for installation in a restricted access location. • PTP 820C HP must be installed and permanently connected to protective earth by qualified service personnel in accordance with applicable national electrical codes. phn-4794_001v000 Page 1-2...
Page 18: Safety Precautions & Declared Material
Use of controls, adjustments, or performing procedures other than those specified herein, may result in hazardous radiation exposure. Caution When working with a PTP 820C HP, note the following risk of electric shock and energy hazard: Disconnecting one power supply disconnects only one power supply module. To isolate the unit completely, disconnect all power supplies.
Page 19: Précautions Générales Relatives À L'équipement
Caution L’usage de PTP 820C HP s’accompagne du risque suivant d'électrocution et de danger électrique : le débranchement d'une alimentation électrique ne déconnecte qu'un module d'alimentation électrique. Pour isoler complètement l'unité, il faut débrancher toutes les alimentations électriques.
Page 20 Chapter 1: Product description Safety Precautions & Declared Material Caution Beachten Sie beim Arbeiten mit PTP 820C HP das folgende Stromschlag- und Gefahrenrisiko: Durch Abtrennen einer Stromquelle wird nur ein Caution Stromversorgungsmodul abgetrennt. Um die Einheit vollständig zu isolieren, trennen Sie alle Stromversorgungen ab.
Page 21: Chapter 2: Pre-Installation Instructions
Chapter 2: Pre-Installation Instructions This chapter describes the Pre-Installation instructions for PTP 820C HP. This chapter includes: • Packing • Transportation and Storage • Unpacking • Inspection phn-4794_001v000 Page 2-1...
Page 22: Packing
Check the packing lists and ensure that correct parts numbers quantities of goods have arrived. Inspect for any damage on the cases and equipment. To report any damage or discrepancy to a Cambium Networks representative, use e-mail or fax. phn-4794_001v000...
Page 23: Chapter 3: Product Hardware Description
Chapter 3: Product Hardware Description Inspection Chapter 3: Product Hardware Description This chapter describes the PTP 820C HP components, interfaces and mediation devices. This chapter includes: • PTP 820C HP Hardware Overview • MultiCore Mediation Devices (MCMD) • Adaptors and Installation Kits •...
Page 24: Ptp 820C Hp Hardware Overview
PTP 820C HP Hardware Overview PTP 820C HP Hardware Overview PTP 820C HP features an all-outdoor dual-carrier architecture consisting of a single unit directly mounted on the antenna. Figure 1 PTP 820C HP Rear View (Left) and Front View (Right)
Page 25: Ptp 820C Hp Interfaces
Chapter 3: Product Hardware Description PTP 820C HP Hardware Overview PTP 820C HP Interfaces Figure 3 PTP 820C HP Interfaces • Power Interface (-48V) • Data Port 1 for GbE traffic: Electric 10/100/1000Base-T (RJ-45) • Data Port 2 for GbE traffic: Optical 1000Base-X (SFP) •...
Page 26: Field-Replaceable Diplexers
PTP 820C HP nodes in the site. The diplexer units, because they are passive, are much less likely to require replacement, so the maintenance of spare parts for the diplexer units is much less of a concern for the operator.
Page 27 Chapter 3: Product Hardware Description PTP 820C HP Hardware Overview • General Radio Unit: C060082B219A PTP 820C-HP, Basic Radio,6 GHz C110082B128A PTP 820C-HP, Basic Radio,11 GHz C060082B220A PTP 820C-HP, Basic Radio, NON-MIMO,6 GHz C110082B129A PTP 820C-HP, Basic Radio, NON-MIMO,11 GHz •...
Page 28 Two diplexers are embedded in each diplexer unit. In most cases, both diplexers are the same exact type. However, in some cases a single PTP 820C HP unit might have to operate in two channels that are not covered by the same diplexer. When this is required, the diplexer unit can be ordered with two different diplexers in a single diplexer unit to cover two different channel ranges within the same frequency band.
Page 29: Multicore Mediation Devices (Mcmd)
PTP 820C HP on a standard RFU-C antenna. PTP 820C HP is equipped with two antenna ports, which mandates the use of the following MCMDs for direct mount connections. The specific MCMDs depend on the configuration.
Page 30 Chapter 3: Product Hardware Description MultiCore Mediation Devices (MCMD) Figure 6 Dual-Core Branching Device Figure 7 OMT phn-4794_001v000 Page 3-10...
Page 31 Chapter 3: Product Hardware Description MultiCore Mediation Devices (MCMD) Figure 8 Dual Coupler/Splitter/Circulator Figure 9 Remote Mount Adaptor phn-4794_001v000 Page 3-11...
Page 32: Adaptors And Installation Kits
Chapter 3: Product Hardware Description Adaptors and Installation Kits Adaptors and Installation Kits Table 2 Adaptors and Installation Kits Description 6 GHz 10-11 GHz DUAL COUPLER KIT N060082L227A N110082L142A DUAL SPLITTER KIT N060082L228A N110082L143A DUAL CIRCULATOR KIT N060082L233A N110082L146A SPLITTER KIT N060082L232A N110082L145A OMT KIT...
Page 33: Antenna Connection
Chapter 3: Product Hardware Description Antenna Connection Antenna Connection PTP 820C HP can be mounted directly for 6 to 11 GHz using the following antenna types (for integrated antennas, specific antennas are required): • CommScope: VHLP series • Radiowave: HP series For remote mount installations, the following Flexible Waveguide flanges should be used (millimetric).
Page 34: Power Specifications
Chapter 3: Product Hardware Description Power Specifications Power Specifications Electrical Requirements • -48V DC Nominal • Maximum current rating 4A • Maximum Cable length 300 meter Power Connection Options Power Source Data Connection Connection DC Cable Type / and Range Type Length Gage...
Page 35: Environmental Specifications
Chapter 3: Product Hardware Description Environmental Specifications Environmental Specifications Operating: ETSI EN 300 019-1-4 Class 4.1 Temperature range for continuous operating temperature with high reliability: -33°C (-27°F) to +55°C (131°F) Temperature range for exceptional temperatures; tested successfully, with limited margins: -45°C (-49°F) to +60°C (140°F) Humidity: 5%RH to 100%RH IEC529 IP66...
Page 36: Chapter 4: Cable Installation And Grounding
Chapter 4: Cable Installation and Grounding This chapter describes the PTP 820C HP cable installation and grounding procedure. This chapter includes: • Minimum and Maximum Cable Diameter • Cable Grounding • Surge Protection • Available Cable Options • Securing the Cables •...
Page 37: Minimum And Maximum Cable Diameter
To fit the gland, the outer cable diameter should be between 6-10 mm. This applies to all glands on both the PTP 820C HP unit and the PoE Injector. To fit the grounding clamp, the outer diameter of CAT5E Ethernet Cables must be between 6- 7.1mm.
Page 38: Cable Grounding
Chapter 4: Cable Installation and Grounding Cable Grounding Cable Grounding Cables must be grounded as follows: • For fiber cables (see Connecting an Optical Fiber Cable and SFP on page 4-20), no grounding is required. • For DC power cables (see connecting a DC power cable on page 4-24), no grounding is required.
Page 39 Chapter 4: Cable Installation and Grounding Cable Grounding Procedure Strip the Cable jacket. Place the cable in the middle of the grounding bracket. Close the grounding bracket around the cable. Tighten the two screws to secure the grounding bracket around the cable. phn-4794_001v000 Page 4-4...
Page 40 Chapter 4: Cable Installation and Grounding Cable Grounding Install the grounding lug on the grounding bar, or directly to the tower. Tighten the grounding lug phn-4794_001v000 Page 4-5...
Page 41: Grounding The Ptp 820C Hp Unit
Metric wrench 10mm Procedure On the front of each PTP 820C HP unit, loosen the nut, plain washer and serrated washer from the GND stud, using the metric offset hexagon key and the wrench. Place the cable lug (supplied with the grounding kit) on the screw.
Page 42: Power Source
The user power supply GND must be connected to the positive pole in the PTP 820C HP power supply. Any other connection may cause damage to the system. Note For the warranty to be honored, you must install the PTP 820C HP in accordance with the instructions above. phn-4794_001v000 Page 4-7...
Page 43: Surge Protection
Surge Protection Surge Protection PTP 820C HP includes built-in surge protection for its Ethernet and power interfaces. PTP 820C HP’s surge protection implementation complies with the standards set forth in the Surge Protection Requirements section of the PTP 820C HP Technical Description, provided the Ethernet cables were prepared according to the instructions in Connecting the Ethernet Cable.
Page 44: Available Cable Options
Chapter 4: Cable Installation and Grounding Available Cable Options Available Cable Options Fiber Optic Cables - Single Mode Table 8 Fiber Optic Cables - Single Mode part numbers Part Number Description N000082L139A PTP 820 Optical CABLE, SM, 30m N000082L140A PTP 820 Optical CABLE, SM, 50m N000082L141A PTP 820 Optical CABLE, SM, 80m N000082L142A...
Page 45: Ethernet Cable And Specifications
Chapter 4: Cable Installation and Grounding Available Cable Options Ethernet Cable and Specifications Table 11 Ehternet cable Part Number Description N000082L016A PTP 820 CAT5E Outdoor 100m drum This cable is suitable for: Fast Ethernet Gigabit Ethernet The following figure shows the cable design. The numbers in the figure refer to the items listed beneath the figure.
Page 46: Outdoor Ethernet Cable Specifications
Chapter 4: Cable Installation and Grounding Available Cable Options Pair Wire A Wire B WHITE-brown BROWN Outdoor Ethernet Cable Specifications Table 13 Ethernet Cable Electrical Requirements Electrical Requirements Cable type CAT-5e SFUTP, 4 pairs, according to ANSI/TIA/EIA-568-B-2 Wire gauge 24 AWG Stranding Solid Voltage rating...
Page 47: Outdoor Dc Cable Specifications
Chapter 4: Cable Installation and Grounding Available Cable Options Outdoor DC Cable Specifications Table 14 Outdoor DC Cable Electrical Requirements Electrical Requirements tinned Cable type copper wires Wire gauge 14 AWG (for <328ft installations) 9 AWG (for >328ft installations) Stranding stranded Voltage rating 600V for 9 AWG...
Page 48: Securing The Cables
Chapter 4: Cable Installation and Grounding Securing the Cables Securing the Cables All cables should be secured at every meter on-site using either a T-Rups kit, Marketing Model “Outdoor Ties”, or cable clamps. When using the T-Rups kit, take special care to apply the proper amount of force in order to avoid damage to the cable.
Page 49: Special Instructions For Use Of Glands
Special Instructions for use of Glands Special Instructions for use of Glands Note Each PTP 820C HP unit is supplied with two glands. If additional glands are required, they must be ordered separately, in kits of five glands each. Table 15 Glands kit...
Page 50: General Installation Procedure
Chapter 4: Cable Installation and Grounding Special Instructions for use of Glands Figure 13 Removing glands General Installation Procedure This procedure applies to all cable types and explains how to install the cables using long glands. The gland is supplied assembled. Before inserting a cable, you must disassemble the gland cap and gland rubber from the gland body Slide the gland cap into the cable.
Page 51 Chapter 4: Cable Installation and Grounding Special Instructions for use of Glands Slide the gland rubber into the cable. Slide the cable into the body of the gland. If a gland cap is being used (see Step 5), make sure to leave enough space for the gland cap to fit into the gland without disturbing the cable.
Page 52 Chapter 4: Cable Installation and Grounding Special Instructions for use of Glands If an M28 gland cap is used to close the gland when raising the gland and cable to the radio unit, remove the gland cap from the gland at this point by unscrewing the cap. Connect the cable to the port.
Page 53 Chapter 4: Cable Installation and Grounding Special Instructions for use of Glands Insert the main part of the gland into the thread in the radio body and tighten until there is full contact and the gasket is fully contained between the gland and the radio and cannot be seen.
Page 54 Chapter 4: Cable Installation and Grounding Special Instructions for use of Glands phn-4794_001v000 Page 4-19...
Page 55: Connecting An Optical Fiber Cable And Sfp
Chapter 4: Cable Installation and Grounding Connecting an Optical Fiber Cable and SFP Connecting an Optical Fiber Cable and SFP To connect an optical fiber cable and the SFP transceiver: Use a pre-assembled cable. Split the connector into two separate LC Connectors (one for each fiber). Remove the gland cap and rubber from the gland body.
Page 56 Remove the tie wrap securing the cable to the gland. Note A new tie wrap must be used to secure the cable to the gland at the end of the procedure, as described in Step 13. Connect the connector into the PTP 820C HP LC connector. phn-4794_001v000 Page 4-21...
Page 57 Chapter 4: Cable Installation and Grounding Connecting an Optical Fiber Cable and SFP Tighten the gland to the radio unit until there is full contact between the gland and the radio unit. Tighten the gland cap. Note Before tightening the gland, ensure it is aligned with the taped hole in the unit. Tightening the gland at an angle can ruin the thread on the gland and prevent proper sealing of the interface Tighten the gland gently and make sure there is no resistance.
Page 58 Chapter 4: Cable Installation and Grounding Connecting an Optical Fiber Cable and SFP phn-4794_001v000 Page 4-23...
Page 59: Connecting A Dc Power Cable
Chapter 4: Cable Installation and Grounding Connecting a DC Power Cable Connecting a DC Power Cable Note The DC power cable and connector must be ordered separately. See DC Cable and Connector on page 4-9. To connect a DC power cable: Strip off 45 mm from the cable jacket.
Page 60 Chapter 4: Cable Installation and Grounding Connecting a DC Power Cable Tighten the two top screws. Plug the power cable with connector into the PTP 820C HP power connector. phn-4794_001v000 Page 4-25...
Page 61 Chapter 4: Cable Installation and Grounding Connecting a DC Power Cable Tighten the two front screws. Screw the gland into the radio unit Caution Before tightening the gland, make sure the gland is even with the cover. Tighten the gland gently and make sure there is no resistance. If there is resistance, stop immediately and verify that the gland is not being inserted at an angle.
Page 62: Connecting The Ethernet Cable
Chapter 4: Cable Installation and Grounding Connecting the Ethernet Cable Connecting the Ethernet Cable If you need to assemble the Ethernet cable, follow the instructions in section Preparing the Ethernet Cable and Plug-in Field, then proceed to section Connection of Ethernet Cable to PTP 820C If you using a pre-assembled Ethernet cable, follow the instructions in section Preparing the...
Page 63 Chapter 4: Cable Installation and Grounding Connecting the Ethernet Cable Do not strip off the end of the cable shield, but rather, twist the shield to form a braid. Roll back the foil shield insulation and wrap the drain wire around the foil. Do not remove any insulation from the conductors.
Page 64 Chapter 4: Cable Installation and Grounding Connecting the Ethernet Cable Wrap the twisted braid firmly around the cable jacket and let the crimping tail of the RJ45 plug envelop it. Caution To ensure proper grounding, it is essential that the twisted braid be firmly connected to the RJ45 plug.
Page 65: Preparing The Ethernet Cable Already Assembled
Connection of Ethernet Cable to PTP 820C HP To connect the Ethernet cable to the PTP 820C HP: Remove the relevant cap from the PTP 820C HP radio. You can use the side of the gland to unscrew the cap.
Page 66 Chapter 4: Cable Installation and Grounding Connecting the Ethernet Cable Connect the CAT5E cable to the PTP 820C HP. Screw the gland into the radio unit. Caution Before tightening the gland, make sure the gland is even with the cover. Tighten the gland gently and make sure there is no resistance.
Page 67 Chapter 4: Cable Installation and Grounding Connecting the Ethernet Cable Tighten the gland cap. Secure the cable to the gland using a tie wrap. phn-4794_001v000 Page 4-32...
Page 68: Management Connection For 1+1/2+2 Hsb Configurations
Configurations In 4x4 MIMO and all HSB protection configurations, two Y-splitter cables and a special signaling cable must be used to connect the management ports (MGT/PROT) of the two PTP 820C HP units and provide management access to each unit.
Page 69: Connecting The Mimo/Protection Splitters And Protection Signaling Cable
“MIMO/Prot” port of the second splitter on the mate PTP 820C HP unit. The following figure demonstrates a 4x4 MIMO configuration in which both PTP 820C HP units are connected to an external management station and to each other, using two splitters.
Page 70 Chapter 4: Cable Installation and Grounding Management Connection for 1+1/2+2 HSB Configurations Figure 15 4x4 MIMO or HSB Protection Configuration with External Management phn-4794_001v000 Page 4-35...
Page 71: Chapter 5: Generic Installation Procedures And Notes
Chapter 5: Generic Installation Procedures and Notes Management Connection for 1+1/2+2 HSB Configurations Chapter 5: Generic Installation Procedures and Notes This chapter describes the generic nstallation procedure and notes for PTP 820C HP. This chapter includes: • General Notes Concerning All Installation Procedures •...
Page 72: General Notes Concerning All Installation Procedures
2+0 SP installation, if you want to install a 1+0 SP HW ready for 2+0 SP. One of the major benefits of the PTP 820C HP and the dual core architecture is that upgrading can be done remotely by uploading the correct software license.
Page 73: Torque Requirements
Chapter 5: Generic Installation Procedures and Notes Torque Requirements Torque Requirements When tightening the captive screws, use 20 Nm torque for radio-antenna, radio-mediation device, and mediation device-antenna connections. In order to avoid misalignment, screws should be tightened progressively. When fastening a waveguide to the radio or mediation device, use the following torque, according to frequency and screw type: •...
Page 74: Pole Mount Installation
Metric offset wrench key wrench set Procedure Mount and tighten the PTP 820C HP DC pole mount to a pole with a diameter of 114 mm using the four washers and screws supplied with the PTP 820C HP DC pole mount kit.
Page 75 Mount and tighten the PTP 820C HP Remote Mount Adaptor plate (supplied in PTP 820C HP Adaptor Remote Mount kit) to the PTP 820C HP Pole Mount using the four flat screws supplied with the PTP 820C HP Adaptor Remote Mount kit.
Page 76: General Radio Installation
The PTP 820C HP has been designed for easy installation, with various installation options to provide maximum flexibility. The PTP 820C HP radio can be assembled to the diplexers kit prior to installation, then mounted to the antenna or mediation device as a single unit.
Page 77: Installing The Diplexer On The Radio
Installing the Diplexer on the Radio Installing the Diplexer on the Radio The PTP 820C HP is delivered as two separate components: a generic radio unit and a diplexer unit. This section explains how to attach the diplexer unit to the radio unit.
Page 78 Chapter 5: Generic Installation Procedures and Notes Installing the Diplexer on the Radio Figure 19 Fitting the Diplexer Unit to the Radio Unit - Radio Side Figure 20 Fitting the Diplexer Unit to the Radio Uni - Diplexer Unit Side phn-4794_001v000 Page 5-8...
Page 79 Chapter 5: Generic Installation Procedures and Notes Installing the Diplexer on the Radio Figure 21 Radio and Diplexer Units Together Figure 22 Hook and Carrying Handle phn-4794_001v000 Page 5-9...
Page 80 First, gently tighten the screws in the order shown in Figure 23. Then strongly tighten the screws in the same order. Figure 23 Securing the Diplexer Unit to the Radio Unit Chapter 5 Proceed to install the PTP 820C HP in the desired configuration, as described in 6: . phn-4794_001v000 Page 5-10...
Page 81: Chapter 6: Ptp 820C Hp Detailed Configurations Description
Chapter 6: PTP 820C HP Detailed Configurations Installing the Diplexer on the Radio Description Chapter 6: PTP 820C HP Detailed Configurations Description This chapter describes the PTP 820C HP detailed configuration description. This chapter includes: • MultiCore 2+0 Dual Polarization Direct Mount •...
Page 82: Multicore 2+0 Dual Polarization Direct Mount
Chapter 6: PTP 820C HP Detailed Configurations Description MultiCore 2+0 Dual Polarization Direct Mount MultiCore 2+0 Dual Polarization Direct Mount Note This procedure can also be used for MultiCore 1+0 DP HW ready for MultiCore 2+0 DP configuration. List of Items...
Page 83: Insertion Loss
Signal Path / Remarks 6-8 GHz 11 GHz Devices Each PTP 820C HP antenna port to Mediation device antenna port Procedure 1 Prior to the installation, follow the antenna manufacturer’s instructions to use the circular adaptor. (Remove the existing rectangular transition, swap the O-ring, and install the circular transition instead.)
Page 84 Chapter 6: PTP 820C HP Detailed Configurations Description MultiCore 2+0 Dual Polarization Direct Mount Connect the PTP 820C HP radio/dual coupler to the OMT kit using the four M8 captive screws and washers supplied and tighten the screws. Important: Verify that the O-rings are properly mounted between the OMT ports and the radio/dual coupler.
Page 85: Multicore 2+0 Dual Polarization Remote Mount
Chapter 6: PTP 820C HP Detailed Configurations Description MultiCore 2+0 Dual Polarization Remote Mount MultiCore 2+0 Dual Polarization Remote Mount This procedure is for use with Interface antennas, up to six feet. For standard interface antennas (six feet and larger), no OMT and no Circ./Circ. Adaptor are used, and the flexible waveguides are connected directly to the antenna flanges.
Page 86: Required Tools
4-5 GHz 6-8 GHz 11 GHz OMT and two Each PTP 820C HP antenna port to Mediation device antenna port Procedure 1 Prior to the installation, follow the antenna manufacturer’s instructions to use the circular adaptor. (Remove the existing rectangular transition, swap the O-ring, and install the circular transition instead.)
Page 87 Important: Verify that the O-ring is properly mounted between the antenna transition and the OMT. 3 Mount and tighten the appropriate adapter to the PTP 820C HP OMT ports using the screws supplied with the adapter kit: For 6 GHz, there are two adaptors: Figure 24 6 GHz –...
Page 88 Chapter 6: PTP 820C HP Detailed Configurations Description MultiCore 2+0 Dual Polarization Remote Mount For 7, 8, 10, and 11 GHz, there is a single adaptor: Figure 26 Mounting the Single Adaptor for 7, 8, 10, and 11 GHz 7-8 GHz...
Page 89 Chapter 6: PTP 820C HP Detailed Configurations Description MultiCore 2+0 Dual Polarization Remote Mount 5 Mount and tighten the PTP 820C HP DC pole mount to the pole using the four washers and screws supplied with the PTP 820C HP DC pole mount kit.
Page 90 Chapter 6: PTP 820C HP Detailed Configurations Description MultiCore 2+0 Dual Polarization Remote Mount Mount and tighten the PTP 820C HP Radio to the PTP 820C HP Pole Mount using the four flat screws supplied with the PTP 820C HP Radio.
Page 91: Multicore 2+0 Single Polarization Direct Mount
Chapter 6: PTP 820C HP Detailed Configurations Description MultiCore 2+0 Single Polarization Direct Mount MultiCore 2+0 Single Polarization Direct Mount Note! This procedure can also be used for MultiCore 1+0 SP HW ready for MultiCore 2+0 SP configuration. List of Items...
Page 92 MultiCore 2+0 Single Polarization Direct Mount For vertical polarization, locate the twist with the letter “V” on top. 2 Mount and tighten the PTP 820C HP Splitter Kit on the antenna using the four M8 screws and washers. Important: Verify that the O-ring is properly mounted between the antenna transition and the splitter.
Page 93 Chapter 6: PTP 820C HP Detailed Configurations Description MultiCore 2+0 Single Polarization Direct Mount 3 Connect the PTP 820C HP DC radio to the splitter kit using the four M8 captive screws and washers supplied, and tighten the screws. Important: Verify that the O-rings are properly mounted between the OMT ports and the radio/dual coupler.
Page 94: Multicore 2+2 Hsb Double Polarization Direct Mount
Chapter 6: PTP 820C HP Detailed Configurations Description MultiCore 2+2 HSB Double Polarization Direct Mount MultiCore 2+2 HSB Double Polarization Direct Mount Note! This procedure can also be used for 2 x MultiCore 1+1 HSB DP HW ready for MultiCore 2+2 HSB DP configurations.
Page 95: Insertion Loss
1 Prior to the installation, follow the antenna manufacturer’s instructions to use the circular adaptor. (Remove the existing rectangular transition, swap the O-ring, and install the circular transition instead.) 2 Connect the PTP 820C HP OMT Kit to the antenna and secure it with four screws. Verify existence of the O-ring. Important: Verify that the O-ring is properly mounted between the antenna transition and the OMT.
Page 96 3 Connect the PTP 820C HP Dual Coupler Kit to the OMT Kit using four M8 screws and washers, and tighten the screws. 4 Mount and tighten the PTP 820C HP DC radio unit to both sides of the Dual Coupler Kit using the supplied captive screws and washers. Pay attention that the O-rings are correctly mounted on the radio ports of the PTP 820C HP Dual Coupler.
Page 97 Chapter 6: PTP 820C HP Detailed Configurations Description MultiCore 2+2 HSB Double Polarization Direct Mount Connect the MIMO signaling cable between the management ports of both units. For additional instructions on preparing and connecting this cable, refer to Preparing a MIMO/Protection Signaling Cable on page 4-33.
Page 98: Multicore 2+2 Hsb Double Polarization Remote Mount
Chapter 6: PTP 820C HP Detailed Configurations Description MultiCore 2+2 HSB Double Polarization Remote Mount MultiCore 2+2 HSB Double Polarization Remote Mount Note! This procedure can also be used for 2x MultiCore 1+1 HSB DP HW ready for MultiCore 2+2 HSB DP configurations.
Page 99: Insertion Loss
Chapter 6: PTP 820C HP Detailed Configurations Description MultiCore 2+2 HSB Double Polarization Remote Mount Insertion Loss Mediation Devices Signal Path / Remarks 4-5 GHz 6-8 GHz 11 GHz Double Coupler, OMT and two Main Paths Secondary Paths Procedure 1 Prior to the installation, follow the antenna manufacturer’s instructions to use the circular adaptor.
Page 100 Chapter 6: PTP 820C HP Detailed Configurations Description MultiCore 2+2 HSB Double Polarization Remote Mount Mount and tighten the appropriate adapter to the PTP 820C HP OMT ports using the screws supplied with the adapter kit: For 6 GHz, there are two adaptors: Figure 27 6 GHz –...
Page 101 Chapter 6: PTP 820C HP Detailed Configurations Description MultiCore 2+2 HSB Double Polarization Remote Mount For 7, 8, 10, and 11 GHz, there is a single adaptor: Figure 29 Mounting the Single Adaptor for 7, 8, 10, and 11 GHz Mount and tighten the O-ring and the flexible waveguide to the adapter ports using the screws supplied with the flexible waveguide kit.
Page 102 MultiCore 2+2 HSB Double Polarization Remote Mount Mount and tighten the PTP 820C HP DC pole mount to the pole using the four washers and screws supplied with the PTP 820C HP DC pole mount kit. Mount and tighten the PTP 820C HP Remote Mount Adaptor plate (supplied in PTP 820C HP Adaptor Remote Mount kit) to the PTP 820C HP Pole Mount using the four flat screws supplied with the PTP 820C HP Adaptor Remote Mount kit.
Page 103 Chapter 6: PTP 820C HP Detailed Configurations Description MultiCore 2+2 HSB Double Polarization Remote Mount Coupler kit. Pay attention that the O-rings are mounted on the PTP 820C HP Remote Mount Adaptor. Page 6-23...
Page 104 MultiCore 2+2 HSB Double Polarization Remote Mount Mount and tighten the PTP 820C HP radios on each side of the PTP 820C HP Dual Coupler using the screws assembled on PTP 820C HP radio. Pay attention that the O- rings are correctly assembled on the radio port of the PTP 820C HP Dual coupler.
Page 105 Mount 10 Connect both Flexible Waveguides and Sealing Gaskets supplied with each Flexible Waveguide Kit to the PTP 820C HP Dual Coupler antenna ports. Tighten the screws and washers supplied with the Flexible Waveguide Kit. 11 Connect the protection signaling cable between the management ports of both units.
Page 106: Multicore 2+2 Hsb Single Polarization Direct Mount
Chapter 6: PTP 820C HP Detailed Configurations Description MultiCore 2+2 HSB Single Polarization Direct Mount MultiCore 2+2 HSB Single Polarization Direct Mount Note! This procedure can also be used for 2 x MultiCore 1+1 HSB SP HW ready for MultiCore 2+2 HSB SP configurations.
Page 107: Procedure
Chapter 6: PTP 820C HP Detailed Configurations Description MultiCore 2+2 HSB Single Polarization Direct Mount Procedure Adjust the twist on the Splitter Kit. Perform one of the procedures below, according to the required polarization (horizontal or vertical). For horizontal polarization, locate the twist with the letter “H” on top.
Page 108 Connect the PTP 820C HP Dual Coupler Kit to the Splitter Kit using four M8 screws and washers, and tighten the screws. 4 Mount and tighten the PTP 820C HP radio unit to both sides of the Dual Coupler Kit using the supplied captive screws and washers. Pay attention that the O-rings are correctly mounted on the radio ports of the PTP 820C HP Dual Coupler.
Page 109 Chapter 6: PTP 820C HP Detailed Configurations Description MultiCore 2+2 HSB Single Polarization Direct Mount Connect the protection signaling cable between the management ports of both units. Preparing a For additional instructions on preparing and connecting this cable, refer to MIMO/Protection Signaling Cable on page 4-33.
Page 110: Multicore 2+0 Dual Polarization Direct Mount
Chapter 6: PTP 820C HP Detailed Configurations Description 2 x MultiCore 2+0 Dual Polarization Direct Mount 2 x MultiCore 2+0 Dual Polarization Direct Mount Note! This procedure can also be used for MultiCore 2+0 DP HW ready for 2 x MultiCore 2+0 DP configurations.
Page 111: Procedure
(Remove the existing rectangular transition, swap the O-ring, and install the circular transition instead.) 2 Connect the PTP 820C HP OMT Kit to the antenna and secure it with four screws. Verify existence of the O-ring. Page 6-31...
Page 112 Connect the PTP 820C HP Dual Coupler Kit to the OMT Kit using four M8 screws and washers, and tighten the screws. 4 Mount and tighten the PTP 820C HP DC radio unit to both sides of the Dual Coupler Kit using the supplied captive screws and washers. Pay attention that the O-rings are correctly mounted on the radio ports of the PTP 820C HP Dual Coupler.
Page 113: Multicore 2+0 Dual Polarization Remote Mount
Chapter 6: PTP 820C HP Detailed Configurations Description 2 x MultiCore 2+0 Dual Polarization Remote Mount 2 x MultiCore 2+0 Dual Polarization Remote Mount Note! This procedure can also be used for 2 x MultiCore 1+0 DP HW ready for 2 x MultiCore 2+0 DP configurations.
Page 114: Insertion Loss
Chapter 6: PTP 820C HP Detailed Configurations Description 2 x MultiCore 2+0 Dual Polarization Remote Mount Insertion Loss Mediation Devices Signal Path / Remarks 4-5 GHz 6-8 GHz 11 GHz Double Splitter, OMT and two Radio to antenna port Procedure 1 Prior to the installation, follow the antenna manufacturer’s instructions to use the...
Page 115 Chapter 6: PTP 820C HP Detailed Configurations Description 2 x MultiCore 2+0 Dual Polarization Remote Mount 3 Mount and tighten the appropriate adapter to the PTP 820C HP OMT ports using the screws supplied with the adapter kit: For 6 GHz, there are two adaptors: Figure 30 6 GHz –...
Page 116 Chapter 6: PTP 820C HP Detailed Configurations Description 2 x MultiCore 2+0 Dual Polarization Remote Mount For 7, 8, 10, and 11 GHz, there is a single adaptor: ◦ Figure 32 Mounting the Single Adaptor for 7, 8, 10, and 11 GHz 4 Mount and tighten the O-ring and the flexible waveguide to the adapter ports using the screws supplied with the flexible waveguide kit.
Page 117 Chapter 6: PTP 820C HP Detailed Configurations Description 2 x MultiCore 2+0 Dual Polarization Remote Mount 5 Mount and tighten the PTP 820C HP DC pole mount to the pole using the four washers and screws supplied with the RFU-D-HP DC pole mount kit.
Page 118 Chapter 6: PTP 820C HP Detailed Configurations Description 2 x MultiCore 2+0 Dual Polarization Remote Mount Mount and tighten the PTP 820C HP Radio to the PTP 820C HP Pole Mount using the four flat screws supplied with the RFU-D-HP Radio.
Page 119: Multicore 2+0 Single Polarization Direct Mount
Chapter 6: PTP 820C HP Detailed Configurations Description 2 x MultiCore 2+0 Single Polarization Direct Mount 2 x MultiCore 2+0 Single Polarization Direct Mount Note! This procedure can also be used for 2 x MultiCore 1+0 SP HW ready for 2 x MultiCore 2+0 SP configurations.
Page 120 Chapter 6: PTP 820C HP Detailed Configurations Description 2 x MultiCore 2+0 Single Polarization Direct Mount For vertical polarization, locate the twist with the letter “V” on top. Page 6-40...
Page 121 Chapter 6: PTP 820C HP Detailed Configurations Description 2 x MultiCore 2+0 Single Polarization Direct Mount Mount the Dual Core Kit on the antenna using four M8 screws and washers and tighten the screws. Connect the PTP 820C HP Dual Coupler Kit to the Splitter Kit using four M8 screws and washers, and tighten the screws.
Page 122 Chapter 6: PTP 820C HP Detailed Configurations Description 2 x MultiCore 2+0 Single Polarization Direct Mount Mount and tighten the PTP 820C HP DC radio unit to both sides of the Dual Coupler Kit using the supplied captive screws and washers. Pay attention that the O-rings are correctly mounted on the radio ports of the PTP 820C HP Dual Coupler.
Page 123: 2X2 Los Mimo Direct Mount
Chapter 6: PTP 820C HP Detailed Configurations Description 2x2 LoS MIMO Direct Mount 2x2 LoS MIMO Direct Mount Note! This procedure can also be used for 1+0 SD configurations. List of Items Item Description Quantity Remarks PTP 820C HP Radio...
Page 124: Procedure
Chapter 6: PTP 820C HP Detailed Configurations Description 2x2 LoS MIMO Direct Mount Procedure 1 Adjust the twist on the Splitter Kit. Perform one of the procedures below, according to the required polarization (horizontal or vertical). For horizontal polarization, locate the twist with the letter “H” on top.
Page 125 2 Mount the Splitter Kit on the antenna using four M8 screws and washers and tighten the screws. 3 Connect the PTP 820C HP DC radio to the Splitter kit using the four M8 captive screws and washers supplied, and tighten the screws.
Page 126: 2X2 Los Mimo Remote Mount
Chapter 6: PTP 820C HP Detailed Configurations Description 2x2 LoS MIMO Remote Mount 2x2 LoS MIMO Remote Mount Note! This procedure can also be used for 1+0 SD configurations. List of Items Item Description Quantity Remarks PTP 820C HP RADIO...
Page 127: Procedure
PTP 820C HP Adaptor Remote Mount kit. 2 Mount and tighten the PTP 820C HP Radio to the PTP 820C HP Pole Mount using the four captive screws and washers that are supplied with the PTP 820C HP Radio. Pay attention that the O-rings are mounted on the PTP 820C HP Remote Mount Adaptor.
Page 128 Chapter 6: PTP 820C HP Detailed Configurations Description 2x2 LoS MIMO Remote Mount 3 Mount and tighten both Flexible WGs with their O-ring to the PTP 820C HP Remote Mount Adaptor ports using the four screws supplied with each Flexible WG kit.
Page 129: 4X4 Los Mimo Direct Mount
Chapter 6: PTP 820C HP Detailed Configurations Description 4x4 LoS MIMO Direct Mount 4x4 LoS MIMO Direct Mount Notes: 1) This procedure can also be used for MultiCore 2+0 SP HW ready for 2 x MultiCore 2+0 SP configurations. 2) This procedure can also be used for 2+2 SD configurations.
Page 130: Insertion Loss
MultiCore 2+0 Dual Polarization Direct Mount on page 6-2. 2 Connect the source sharing cable between both EXT REF PTP 820C HP radio connectors. The maximum torque for connecting this cable to the radio is 5Lb.in (0.5N.m). 3 Connect the MIMO data sharing cable between both P3 PTP 820C HP ports.
Page 131 Chapter 6: PTP 820C HP Detailed Configurations Description 4x4 LoS MIMO Direct Mount 4 Connect the MIMO signaling cable between the management ports of both units. For Preparing a additional instructions on preparing and connecting this cable, refer to MIMO/Protection Signaling Cable on page 4-33.
Page 132: 4+0 Dual Polarization, 2+2Hsb Single/Dual Polarization Direct Mount
Chapter 6: PTP 820C HP Detailed Configurations Description 4+0 Dual Polarization, 2+2HSB Single/Dual Polarization Direct Mount 4+0 Dual Polarization, 2+2HSB Single/Dual Polarization Direct Mount List of Items Item Description Quantity Remarks PTP 820C HP Dual Coupler/Splitter/Circulator PTP 820C HP OMT/Splitter Kit...
Page 133 Chapter 6: PTP 820C HP Detailed Configurations Description 4+0 Dual Polarization, 2+2HSB Single/Dual Polarization Direct Mount For vertical polarization, locate the twist with the letter “V” on top. Page 6-53...
Page 134 Mount the OMT/Splitter Kit on the antenna using four M8 screws and washers and tighten the screws. Connect the PTP 820C HP Dual Coupler Kit to the OMT/Splitter Kit using four M8 screws and washers, and tighten the screws. Page 6-54...
Page 135 4+0 Dual Polarization, 2+2HSB Single/Dual Polarization Direct Mount Mount and tighten the PTP 820C HP radio unit to both sides of the Dual Coupler Kit using the supplied captive screws and washers. Pay attention that the O-rings are correctly mounted on the radio ports of the PTP 820C HP Dual Coupler.
Page 136 Chapter 6: PTP 820C HP Detailed Configurations Description 4+0 Dual Polarization, 2+2HSB Single/Dual Polarization Direct Mount Connect the protection signaling cable between the management ports of both units. For additional instructions on preparing and connecting this cable, refer Preparing a MIMO/Protection Signaling Cable on page 4-33.
Page 137: 4+0 With Dual Circulator Direct Mount
Chapter 6: PTP 820C HP Detailed Configurations Description 4+0 with Dual Circulator Direct Mount 4+0 with Dual Circulator Direct Mount The following example illustrates a typical configuration, assuming that: The regulation specifies a channelization of 8 consecutive 28/38MHz channels (1-8 ch).
Page 138: 4+0 Dual Polarization, 2+2Hsb Dual Polarization Remote Mount
Chapter 6: PTP 820C HP Detailed Configurations Description 4+0 Dual Polarization, 2+2HSB Dual Polarization Remote Mount 4+0 Dual Polarization, 2+2HSB Dual Polarization Remote Mount List of Items Item Description Quantity Remarks PTP 820C HP OMT Kit Flexible Waveguide Kit PTP 820C HP Dual...
Page 139 PTP 820C HP Adaptor Remote Mount kit. 3 Mount and tighten the PTP 820C HP Dual Coupler to the PTP 820C HP Pole Mount using the four screws and washers that are supplied with the PTP 820C HP Dual Coupler kit.
Page 140 Coupler/Circulator. Make sure that the O-rings are correctly assembled on the radio ports of the PTP 820C HP dual coupler/circulator. 5 Mount and tighten an PTP 820C HP radio to each PTP 820C HP diplexer unit using the screws assembled with each PTP 820C HP radio.
Page 141 4+0 Dual Polarization, 2+2HSB Dual Polarization Remote Mount 6 Connect both Flexible Waveguides and Sealing Gaskets supplied with each Flexible Waveguide Kit to the PTP 820C HP Dual Coupler antenna ports. Tighten the screws and washers supplied with the Flexible Waveguide Kit. Page 6-61...
Page 142: 4+0 With Dual Circulator Remote Mount
Chapter 6: PTP 820C HP Detailed Configurations Description 4+0 with Dual Circulator Remote Mount 4+0 with Dual Circulator Remote Mount The following example illustrates a typical configuration, assuming that: • The regulation specifies a channelization of 8 consecutive 28/38MHz channels (1-8 ch).
Page 143: 2+2 Hsb Single Polarization Remote Mount
Chapter 6: PTP 820C HP Detailed Configurations Description 2+2 HSB Single Polarization Remote Mount 2+2 HSB Single Polarization Remote Mount Note: This procedure can also be used for 1+1HSB SP HW ready for 2+2HSB SP configurations. ACCP - Protected List of Items...
Page 144 PTP 820C HP Splitter kit. 3 Mount and tighten the PTP 820C HP Dual Coupler to the PTP 820C HP Splitter using the four captive screws and washers that are supplied with the PTP 820C HP Dual Coupler kit.
Page 145 2+2 HSB Single Polarization Remote Mount 4 Mount and tighten the PTP 820C HP unit to the PTP 820C HP Dual Coupler using the four screws and washers that are assembled to the PTP 820C HP unit. Make sure that the O-rings are mounted on the PTP 820C HP Dual Coupler.
Page 146 Chapter 6: PTP 820C HP Detailed Configurations Description 2+2 HSB Single Polarization Remote Mount Page 6-66...
Page 147: Dual Circulator Multi-Carrier Kit Installation
Remote Mount kit). Tighten the four M10 Hex screws and washers supplied within the kit. 6-8 GHz 1 Mount and tighten the PTP 820C HP MC Dual Cir to the PTP 820C HP pillar adapter bracket using the four M8 Hex screws and washers supplied within the kit. Page 6-67...
Page 148 M8 Hex screws and washers supplied within the kit. 2 Mount and tighten the PTP 820C HP MC Dual Cir to the PTP 820C HP MC Extender using the four M8 Hex screws and washers supplied within the kit.
Page 149 Dual Circulator Multi-Carrier Kit Installation 6-11GHz 1 Mount and tighten the PTP 820C HP Dual Cir to each side of the PTP 820 MC Dual Circ using the four M8 Hex screws and washers supplied in the PTP 820 Dual Circ kit. Pay attention that the O-rings on the PTP 820C HP MC Dual Circ are well in place during the mounting.
Page 150 Chapter 6: PTP 820C HP Detailed Configurations Description Dual Circulator Multi-Carrier Kit Installation 3 Mount and tighten the PTP 820C HP MC Remote mount adapter to thePTP 820C HP MC Dual Circ antenna ports using the four screws assembled on the PTP 820C HP radio. Pay attention that the O-rings on the PTP 820C HP MC Remote mount adapter are well in place during the mounting.
Page 151 Chapter 6: PTP 820C HP Detailed Configurations Description Dual Circulator Multi-Carrier Kit Installation The following example illustrates a typical configuration, assuming: • The regulation specifies a channelization of 8 consecutive 28/30 MHz channels (1-8ch). • The actual channels in use are channels 1, 5.
Page 152 Chapter 6: PTP 820C HP Detailed Configurations Description Dual Circulator Multi-Carrier Kit Installation Figure 34 4+0 Configuration Low Channels Radio (i.e: Ch1 V&H) Antenna High Channels Ports Radio (i.e: Ch5 V&H) 1 2 3 4 5 6 7 8 High Channels Radio (i.e Ch5 V&H)
Page 153: Afr 1+0 Hub Site
820C HP or PTP 820C HP units are deployed in two tail sites. The hub site utilizes a single PTP 820C HP unit with two radio carriers. Each carrier is in a link, via its own directional antenna, with a tail site that consists of a PTP 820C HP or PTP 820S unit.
Page 154: Insertion Loss
2 Mount and tighten the Flexible WG to the antenna port using the four screws supplied with the Flexible WG kit. 3 Mount and tighten the PTP 820C HP Remote Mount Adaptor plate (supplied in PTP 820C HP Adaptor Remote Mount kit) to the PTP 820C HP Pole Mount using the four flat screws supplied with the PTP 820C HP Adaptor Remote Mount kit.
Page 155 Chapter 6: PTP 820C HP Detailed Configurations Description AFR 1+0 Hub Site 4 Mount and tighten the PTP 820C HP to the PTP 820C HP Pole Mount using the four captive screws and washers that are supplied with the PTP 820C HP. Pay attention that the O-rings are mounted on the PTP 820C HP Remote Mount Adaptor.
Page 156 Chapter 6: PTP 820C HP Detailed Configurations Description AFR 1+0 Hub Site 5 Mount and tighten both Flexible WGs with their O-ring to the PTP 820C HP Remote Mount Adaptor ports using the four screws supplied with each Flexible WG kit.
Page 157: Chapter 7: Installing Ptp 820C Hp On Third-Party Antenna Adaptors
Chapter 7: Installing PTP 820C HP on Third- Party Antenna Adaptors PTP 820C HP can be mounted to third party mediation devices through PTP 820C HP mediation devices (OMT/Splitter) Special attention must be taken in assembling these configurations, since most of the 3...
Page 158: Special Note On Converting Valuline 3 Antennas
CommScope provided special antennas which are not supported by these adaptors, it is recommended that you supply your Cambium Networks representative with a picture of the current antenna (back plain side), in order to confirm the antenna’s compatibility prior to implementing this solution.
Page 159: Chapter 8: Acceptance And Commissioning Procedures
Chapter 8: Acceptance and Commissioning Procedures Special Note on Converting ValuLine 3 Antennas Chapter 8: Acceptance and Commissioning Procedures This chapter provides Cambium's recommended Acceptance and Commissioning Procedure for PTP 820. Acceptance and commissioning should be performed after initial setup is complete. The purpose of this procedure is to verify correct installation and operation of the installed link and the interoperability with customer end equipment.
Page 160: Site Acceptance Procedure
Chapter 8: Acceptance and Commissioning Procedures Site Acceptance Procedure Site Acceptance Procedure The purpose of the following procedures is to verify that all installation requirements were noted and checked. Following this procedure will ensure proper, long-lasting, and safe operation of the product.
Page 161 Chapter 8: Acceptance and Commissioning Procedures Site Acceptance Procedure Antenna sealing O-Ring is properly fitted and not damaged Antenna/Launch unit polarization is as per link requirements SITE ACCEPTANCE CHECKLIST (continued) 4. OUTDOOR UNIT Type of ODU mount: (Direct or Remote mount) ODU is securely mounted to the antenna or pole ODU is grounded as per installation instructions ODU‘s polarization is as per link requirements...
Page 162 Chapter 8: Acceptance and Commissioning Procedures Site Acceptance Procedure Cable ends are properly labeled SITE ACCEPTANCE CHECKLIST (continued) 7. FLEXIBLE WAVEGUIDE Overall flexible WG length: Flexible WG type: Flexible WG is connected securely to ODU and Antenna Flexible WG connector is weather-proofed (sealed) at the ODU At the ODU, the flexible WG has a service/drip loop to prevent moisture from entering the connector...
Page 163 Chapter 8: Acceptance and Commissioning Procedures Site Acceptance Procedure SITE ACCEPTANCE CHECKLIST (continued) 10. REMARKS/NOTES 11. GENERAL INFORMATION Name: Title: Site accepted by: Company: Signature: Date: Name: Title: Site approved by: Company: Signature: Date: Page 8-4...
Page 164: Site Acceptance Checklist Notes
Chapter 8: Acceptance and Commissioning Procedures Site Acceptance Checklist Notes Site Acceptance Checklist Notes The following notes provide important additional information about the Site Acceptance Checklist. 1. Antenna Mounting Mounting pole is of sufficient height to clear local obstructions, such as parapets, window cleaning gantries, and lift housings.
Page 165 Chapter 8: Acceptance and Commissioning Procedures Site Acceptance Checklist Notes • Antenna labels - for link identity and bearing • ODU labels - for link identity, frequency, and polarization • Cat5/Fiber cable labels - for link identity, close to the ODU, switch, and either end of any joint •...
Page 166: Radio Link Commissioning Procedure
Chapter 8: Acceptance and Commissioning Procedures Radio Link Commissioning Procedure Radio Link Commissioning Procedure Scope This section describes the recommended commissioning tests for PTP 820 radio link in a 1+0 configuration. The purpose of the commissioning tests is to verify correct and proper operation of the product. Commissioning Test The following tests should be performed on each installed link.
Page 167 Chapter 8: Acceptance and Commissioning Procedures Radio Link Commissioning Procedure Management Verification • Launch the HTTP management and verify that you can manage the link and that you are able to perform changes to the link configuration (frequency channel, Tx power, system name, time &...
Page 168: Ptp 820 Commissioning Log
Maintaining the Commissioning Log is important for tracking your installations, and to provide essential data for Cambium Networks. Upon completing the Commissioning Log, send the log to Cambium Networks’ support center at https://support.cambiumnetworks.com.. PTP 820 LINK COMMISSIONING LOG 1.
Page 169 Chapter 8: Acceptance and Commissioning Procedures PTP 820 Commissioning Log Mounting type: Mounting losses: Site 1 Site 2 4. LINK PARAMETERS Link distance: Rain zone: Expected RSL (dBm): Expected Diversity RSL (dBm): RSL Main (dBm): RSL Diversity (dBm): Deviation from exp? RSL ≤4 dB? Site 1 Site 2...
Page 170 Chapter 8: Acceptance and Commissioning Procedures PTP 820 Commissioning Log Page 8-11...
