Page 1 Cambium PTP 250 User Guide System Release 250-02-01...
Page 2 Facilities, Aircraft Navigation or Aircraft Communication Systems, Air Traffic Control, Life Support, or Weapons Systems (High Risk Activities). Cambium and its supplier(s) specifically disclaim any expressed or implied warranty of fitness for such High Risk Activities. © 2012 Cambium Networks Limited. All Rights Reserved. phn-2510_002v000 (Mar 2012)
Page 3: Safety And Regulatory Information
Safety and regulatory information This section describes important safety and regulatory guidelines that must be observed by personnel installing or operating PTP 250 equipment. Important safety information To prevent loss of life or physical injury, observe the safety guidelines in this section.
Page 4 Alternative DC supply If the PTP 250 is to be powered from a DC supply (either as the primary power source or as a backup to the AC supply), the DC supply must be input to the ODU via a PIDU (not a PoE power supply).
Page 5 Installers and users must meet all local regulatory requirements for radar detection. To meet these requirements, users must set the correct country code during commissioning of the the PTP 250. If this is not done, installers and users may be liable to civil and criminal penalties.
Page 6 2-5. Other variants of the PTP 250 are available for use in the rest of the world, but these variants are not supplied to the USA or Canada except under strict controls, when they are needed for export and deployment outside the USA or Canada.
Page 7 Chapter 5: Installation. Training The installer needs to have basic competence in radio and IP network installation. The specific requirements applicable to the PTP 250 should be gained by reading Chapter 5: Installation Chapter 6: Configuration and alignment and by performing sample set ups at base workshop before live deployments.
Page 8 Safety and regulatory information phn-2510_002v000 (Mar 2012)
Page 9: Table Of Contents
Warnings, cautions, and notes ..................... 7 Caring for the environment ......................8 Chapter 1: Product description .................. 1-1 Overview of the PTP 250 ......................1-2 Purpose ..........................1-2 Key features ........................1-2 Typical deployment ......................1-3 System components ......................1-3 Product variants ........................
Page 10 Contents Cable grounding kits ......................1-13 Lightning protection units (LPUs) ..................1-14 Further reading on cabling and lightning protection ............1-15 Wireless operation ........................1-16 Wireless Transmissions ..................... 1-16 Spectrum management ..................... 1-16 Adaptive modulation ......................1-16 MIMO ..........................1-17 Radar avoidance ........................
Page 11 Components required with connectorized ODUs .............. 2-29 Alternative and additional components ................2-34 Chapter 3: Legal information ..................3-1 Cambium Networks end user license agreement ..............3-2 Acceptance of this agreement ..................... 3-2 Definitions ........................... 3-2 Grant of license ........................3-2 Conditions of use .........................
Page 12 Contents Title and restrictions ......................3-4 Confidentiality ........................3-4 Right to use Cambium’s name .................... 3-5 Transfer ..........................3-5 Updates ..........................3-5 Maintenance ........................3-5 Disclaimer ........................... 3-6 Limitation of liability ......................3-6 U.S. government ......................... 3-7 Term of license ........................3-7 Governing law ........................
Page 13 PTP 250 User Guide Chapter 5: Installation ....................5-1 Preparing for installation ......................5-2 Unit pre-configuration ......................5-2 Safety precautions ......................5-2 Protection requirements ..................... 5-2 Selecting installation options ....................5-3 Preparing personnel ......................5-3 Preparing inventory ......................5-3 Preparing tools ........................5-3 Installing the ODU ........................
Page 14 Contents Logging into the web interface ................... 6-6 Upgrading firmware version ..................... 6-9 Checking the installed firmware version ................6-9 Uploading a new firmware version ................... 6-10 Using the configuration wizard ....................6-12 Starting configuration wizard ................... 6-12 Step 1: LAN configuration ....................6-13 Step 2: Date and time settings ..................
Page 15 PTP 250 User Guide Managing email alerts ...................... 7-14 Managing performance ......................7-15 Checking system statistics ....................7-15 Checking channel status ....................7-18 Checking the retry histogram ................... 7-20 Using the diagnostics plotter .................... 7-21 Diagnostics calculated over time ..................7-23 Restoring, resetting and rebooting ..................
Page 16 PTP 250 User Guide List of Figures Figure 1 Typical PTP 250 bridge deployment (grounding not shown) .......... 1-3 Figure 2 Integrated ODU (front and rear views) ................1-5 Figure 3 Connectorized ODU (front and rear views) ..............1-5 Figure 4 ODU interfaces ....................... 1-6 Figure 5 Connectorized ODU antenna interfaces .................
Page 17 PTP 250 User Guide Figure 32 Step 3: SNMP/SMTP Configuration page (neither enabled) ........6-16 Figure 33 SNMP configuration enabled in Step 3 ..............6-17 Figure 34 SMTP configuration enabled in Step 3 ............... 6-19 Figure 35 Step 4: Confirm Configuration page ................6-20 Figure 36 Wireless Configuration Summary page ..............
Page 18 Table 9 Setting maximum power level to meet EIRP limits ............2-14 Table 10 RF cable lengths required to achieve 1.2 dB loss at 5.8 GHz ........2-14 Table 11 PTP 250 kit part numbers ..................... 2-24 Table 12 Inventory for ODU and PoE power supply kits ............. 2-25 Table 13 Additional inventory for standard installations ............
Page 19 Table 49 Diagnostics Plotter attributes ..................7-22 Table 50 PoE power supply LED states ..................8-2 Table 51 RJ45 cable resistance tests at the PoE power supply end ..........8-9 Table 52 Typical resistance values in PTP 250 ODU-PoE drop cable ......... 8-10 phn-2510_002v000 (Mar 2012)
Page 20 List of Tables phn-2510_002v000 (Mar 2012)
Page 21: About This User Guide
PTP 250 User Guide About This User Guide This guide describes the planning, installation and operation of the Cambium PTP 250 Point-to-Point Wireless Ethernet Bridge. It is intended for use by the system designer, system installer and system administrator. Users of this guide should have knowledge of the following areas:...
Page 22: General Information
The following shows the issue status of this document: Document Date of issue Remarks issue 001v000 Jan 2012 System release 250-02-00 002v000 Mar 2012 System release 250-02-01 Contacting Cambium Networks Support website: http://www.cambiumnetworks.com/support Main website: http://www.cambiumnetworks.com Sales enquiries: solutions@cambiumnetworks.com Support enquiries: support@cambiumnetworks.com Telephone number list: http://www.cambiumnetworks.com/contact.php...
Page 23 General information Purpose Cambium Networks Point-To-Point (PTP) documents are intended to instruct and assist personnel in the operation, installation and maintenance of the Cambium PTP equipment and ancillary devices. It is recommended that all personnel engaged in such activities be properly trained.
Page 24: Problems And Warranty
Problems and warranty About This User Guide Problems and warranty Reporting problems If any problems are encountered when installing or operating this equipment, follow this procedure to investigate and report: Search this document and the software release notes of supported releases. Visit the support website.
Page 25 PTP 250 User Guide Problems and warranty Portions of Cambium equipment may be damaged from exposure to electrostatic discharge. Use precautions to prevent damage. phn-2510_002v000 (Mar 2012)
Page 26: Security Advice
Security advice About This User Guide Security advice Cambium Networks systems and equipment provide security parameters that can be configured by the operator based on their particular operating environment. Cambium recommends setting and using these parameters following industry recognized security practices.
Page 27: Warnings, Cautions, And Notes
Warnings, cautions, and notes Warnings, cautions, and notes The following describes how warnings and cautions are used in this document and in all documents of the Cambium Networks document set. Warnings Warnings precede instructions that contain potentially hazardous situations. Warnings are used to alert the reader to possible hazards that could cause loss of life or physical injury.
Page 28: Caring For The Environment
About This User Guide Caring for the environment The following information describes national or regional requirements for the disposal of Cambium Networks supplied equipment and for the approved disposal of surplus packaging. In EU countries The following information is provided to enable regulatory compliance with the European Union (EU) directives identified and any amendments made to these directives when using Cambium equipment in EU countries.
Page 29: Chapter 1: Product Description
PTP 250 User Guide Chapter 1: Product description This chapter provides a high level description of the PTP 250 product. It describes in general terms the function of the product, the main product variants and typical deployment. It also describes the main hardware components.
Page 30: Overview Of The Ptp 250
5.4 GHz and 5.8 GHz unlicensed bands. Users must ensure that the links comply with local operating regulations. The PTP 250 is used to create a transparent bridge between two segments of the operator’s network. This bridge can be treated as a virtual wired connection between two points.
Page 31: Typical Deployment
Overview of the PTP 250 Typical deployment The PTP 250 bridge consists of a pair of identical units, one deployed at each end of the link. The radio link operates on a single frequency channel. One unit is configured as a master and the other as a slave.
Page 32: Product Variants
The PTP 250 is available in the following product variants: FCC/IC or ETSI/RoW: The PTP 250 is available in two regional variants: one is for use in countries where FCC or IC licensing restrictions apply (FCC/IC), and the other is for use in ETSI countries or the rest of the world (ETSI/RoW).
Page 33: Outdoor Unit (Odu)
PTP 250 User Guide Outdoor unit (ODU) Outdoor unit (ODU) This section describes the PTP 250 ODU and its interfaces. ODU description The ODU is a self-contained unit that houses both radio and networking electronics. The ODU is supplied in two configurations: integrated (attached to its own flat plate antenna,...
Page 34: Odu Interfaces
Outdoor unit (ODU) Chapter 1: Product description Connectorized variant The connectorized ODU is designed to work with externally mounted antennas that have higher gains than the integrated antenna. Connectorized units can cope with more difficult radio conditions, as described in When to install connectorized units on page 2-12.
Page 35: Connectorized Odu Antenna Interfaces
PTP 250 User Guide Outdoor unit (ODU) Connectorized ODU antenna interfaces The connectorized ODU also has interfaces to connect to an external antenna (Figure via an N type connector with RF cable of type LMR100, LMR200, LMR300, LMR400 or LMR600. The ‘V’ interface is for vertical polarization and the ‘H interface is for horizontal polarization.
Page 36: Further Reading On The Odu
ODUs and external antennas rather than integrated ODUs. General protection requirements on page 2-17 describes the grounding and lightning protection requirements of a PTP 250 installation, including the ODU. Ordering components on page 2-24 lists the components required for PTP 250 installations, including ODUs, with Cambium part numbers.
Page 37: Power Over Ethernet Injector (Poe Power Supply)
The Cambium High Power Gigabit PoE power supply is a single-port Power over Ethernet injector combining low-voltage DC with Ethernet data in a single cable connecting to a PTP 250 ODU. The PTP 250 is supplied with one of two variants of the PoE power supply: the 9001GR...
Page 38: Poe Power Supply Interfaces
Power over Ethernet injector (PoE power supply) Chapter 1: Product description Figure 7 PoE power supply (type PD7001) PoE power supply interfaces The PoE power supply interfaces are described in Table 2. The PoE power supply LEDs are described in Table 3: PoE type 9001GR has only a PORT LED whereas PoE type PD7001 has AC and PORT LEDs.
Page 39: Further Reading On The Poe Power Supply
ODU, and prepare the network cables. Connecting to the unit on page describes how to connect the PoE power supply to a management PC to allow configuration and alignment of the PTP 250. Connecting to the network on page 6-33 describes how to connect the PoE power supply to the network when configuration, installation and alignment are complete.
Page 40: Cabling And Lightning Protection
Cabling and lightning protection Chapter 1: Product description Cabling and lightning protection This section describes the cabling and lightning protection components of PTP 250 installations. PTP and lightning protection The PoE power supply meets the discharge specifications identified in Electromagnetic...
Page 41: Indoor Connections
PTP 250 User Guide Cabling and lightning protection Indoor connections The CAT5e cable that connects the PoE power supply to the network equipment must meet the following requirements: Screening: Must be either foil screen (FTP) or braided screen (STP) cable.
Page 42: Lightning Protection Units (Lpus)
Cabling and lightning protection Chapter 1: Product description Lightning protection units (LPUs) One LPU kit (Figure 9) is required for each ODU drop cable. The LPU is installed at the building entry point. Figure 9 LPU kit 1-14 phn-2510_002v000 (Mar 2012)
Page 43: Further Reading On Cabling And Lightning Protection
PTP 250 installations. Grounding and lightning protection on page 2-15 describes the grounding and lightning protection requirements of a PTP 250 installation. Ordering components on page 2-24 lists the components required for PTP 250 installations, including cables, connectors, grounding kits and LPUs.
Page 44: Wireless Operation
This section describes how PTP 250 wireless links are operated, including modulation modes, power control and security. Wireless Transmissions The PTP 250 uses Time Division Duplexing (TDD) transmission, which means that a single frequency channel is used for both Transmit and Receive. This is handled automatically by the radio.
Page 45: Mimo
MIMO are combined with those of OFDM techniques and a high link budget, there is a high probability of a robust connection. The PTP 250 transmits two signals on the same radio frequency, one of which is vertically polarized and the other horizontally polarized. The system also has the ability to adapt...
Page 46: Radar Avoidance
Wireless operation Chapter 1: Product description Radar avoidance In regions where protection of radars is part of the local regulations, the PTP 250 must detect interference from radar-like systems and avoid co-channel operation with these systems. The requirements for a master device are: The device can only transmit on available channels, of which there are none at initial power up.
Page 47: Country Of Operation
PTP 250 User Guide Wireless operation The requirements for a slave device are: The slave device can only transmit after receiving a transmission from its associated master to demonstrate that the channel is an available channel. The slave device is required to vacate the channel when the master device has detected a radar signal.
Page 48: Using Frequency Planning
Wireless operation Chapter 1: Product description Using frequency planning Networks will benefit from the use of fixed channel allocations if (a) the network consists of multiple PTP links, and (b) RF interference predominantly arises from equipment in the same network. Frequency planning is the exercise of assigning operating channels to PTP units so as to minimize RF interference between links.
Page 49: Further Reading On Wireless Operation
RF bands, channel width, spectrum settings, maximum power and link loss. Compliance with safety standards on page lists the safety specifications against which the PTP 250 has been tested, and describes how to keep RF exposure within safe limits. Compliance with radio regulations on page 4-12 describes how the PTP 250 complies with the radio regulations that are in force in various countries.
Page 50: Ethernet Bridging
Customer network Transparent Ethernet service The PTP 250 provides an Ethernet service between the Ethernet port at a local ODU and the Ethernet port at an associated remote ODU. The Ethernet service is based on conventional layer two transparent bridging, and is equivalent to the Ethernet Private Line (EPL) service defined by the Metro Ethernet Forum (MEF).
Page 51: Management Network
Ethernet port at the local ODU, and (assuming that the wireless link is established) the Ethernet port at the remote ODU. Wireless link down alert PTP 250 offers a configurable email alert which can be set to send the user an email message in the event of the wireless link going down. Back-to-back links PTP 250 will not operate correctly if a direct cabled connection is made between two PoE power supply units.
Page 52: Protocol Model
Ethernet bridging Chapter 1: Product description Protocol model Ethernet bridging behavior at each end of the wireless link is equivalent to a two-port, managed, transparent MAC bridge where the two ports are: Ethernet Port Wireless Port Frames are transmitted at the Wireless port over a proprietary point-to-point circuit-mode link layer between ends of the link.
Page 53: Further Reading On Ethernet Bridging
6-12 describes how to configure the IP and Ethernet attributes of the PTP 250. Reviewing system configuration attributes on page 6-32 describes how to review the IP and Ethernet attributes of the PTP 250. phn-2510_002v000 (Mar 2012) 1-25...
Page 54: System Management
System management Chapter 1: Product description System management This section introduces the PTP 250 management system, including the web interface, installation, configuration, alerts and upgrades. Management agent PTP 250 equipment is managed through an embedded management agent. Management workstations, network management systems or PCs can be connected to this agent using the in-band management mode.
Page 55: Link And Node Management Modes
PTP 250 User Guide System management Statistics: This page contains performance management counters that are collected at the data, management and wireless ports. Firmware Update: This page is used to update the firmware in the unit. Diagnostics Plotter: This page provides diagnostic measurements over time, as an aid to performance management.
Page 56: Encryption
The management agent supports application firmware upgrade using the web-based interface. PTP 250 firmware images are digitally signed, and the ODU will accept only images that contain a valid PTP digital signature. The ODU always requires a reboot to complete a firmware upgrade.
Page 57: Reset To Factory Defaults
The ‘reset to factory defaults’ feature provides a means to recover from serious configuration errors, such as lost or forgotten passwords. Use the reset plug (supplied in each PTP 250 ‘Link Complete’ or ‘End Complete’ kit) to reset the unit to factory default configuration, including reset of the country that was selected at first login.
Page 58 System management Chapter 1: Product description 1-30 phn-2510_002v000 (Mar 2012)
Page 59: Chapter 2: Planning Considerations
PTP 250 User Guide Chapter 2: Planning considerations This chapter provides information to help the user to plan a PTP 250 link. The following topics are described in this chapter: Regulatory planning on page describes how to plan PTP 250 links to conform to the regulatory restrictions that apply in the country of operation.
Page 60: Regulatory Planning
Once the correct Country Code is set by the user on first login, the PTP 250 caculates these limits automatically. Many countries impose EIRP limits (Allowed EIRP) on products operating in the 5.4 GHz and 5.8 GHz bands.
Page 61: Conforming To The Limits
In Canada, NO operation is permitted in the band 5600 – 5650 MHz. Conforming to the limits When a new PTP 250 unit is first accessed via the web interface, the user is required to select the Country Code from a list. Generally, the PTP 250 firmware does not allow the unit to be configured to operate outside the regulatory limits that apply to the selected country.
Page 62: Radar Detection
For example, at 5.8 GHz in the UK and some other European countries, the RTTT band 5795 MHz to 5815 MHz is barred. With the appropriate configuration for a country in this region, the PTP 250 will not operate on channels within this band.
Page 63: Avoidance Of Weather Radars (Usa Only)
PTP 250 User Guide Regulatory planning Avoidance of weather radars (USA only) To comply with FCC rules (KDB 443999: Interim Plans to Approve UNII Devices Operating in the 5470 - 5725 MHz Band with Radar Detection and DFS Capabilities), units which are...
Page 64: Site Planning
2-7. Power supply selection Select a suitable power supply unit for the PTP 250. The only supported units are the PoE power supply (included in PTP 250 kits) or the PTP 300/500/600 Series PIDU. The PoE power supply is suitable for the majority of installations, but the PIDU is required in the...
Page 65: Maximum Cable Lengths
PTP 250 User Guide Site planning Maximum cable lengths The maximum permitted lengths of interface cables in PTP 250 installations are specified Table Table 6 Maximum cable lengths Interface type Interface Maximum length Ethernet power ODU to network terminating equipment.
Page 66: Table 7 Lateral Force - Metric
Site planning Chapter 2: Planning considerations The lateral force produced by a single PTP 250 ODU (integrated or connectorized model) at different wind speeds is shown in Table Table 7 Lateral force – metric Type of ODU Largest Lateral force (Kg) at wind speed...
Page 67 PTP 250 User Guide Site planning Capabilities of the PTP 250 The structure and mounting brackets of the ODU are capable of withstanding wind speeds up to 242 kph (151 mph). Ensure that the structure to which the ODU is fixed is also capable of withstanding the prevalent wind speeds and loads.
Page 68: Link Planning
This section describes factors to be taken into account when planning links, such as range, obstacles and path loss. PTP LINKPlanner is recommended. PTP LINKPlanner Cambium Networks provide a free tool to help plan your PTP links. Download your copy of LinkPlanner from the support website (see Contacting Cambium Networks on page 2).
Page 69: Path Loss Considerations
PTP 250 User Guide Link planning Path loss considerations Path loss is the amount of attenuation the radio signal undergoes between the two ends of the link. Calculating path loss The path loss is the sum of the attenuation of the path if there were no obstacles in the way (Free Space Path Loss), the attenuation caused by obstacles (Excess Path Loss) and a margin to allow for possible fading of the radio signal (Fade Margin).
Page 70: Planning For Connectorized Units
ODUs with external antennas in PTP 250 links. When to install connectorized units The majority of radio links can be successfully deployed with the integrated PTP 250. However the integrated units may not be sufficient in some areas, for example: Where the path is heavily obscured by dense woodland on an NLOS link.
Page 71: Calculating Maximum Power Level For Connectorized Units
Calculating maximum power level for connectorized units If a connectorized PTP 250 link is to be installed in a country that imposes an EIRP limit in the 5.4 GHz or 5.8 GHz band, choose an external antenna and RF cable that will not cause the PTP 250 to exceed the EIRP limit.
Page 72: Calculating Rf Cable Length (5.8 Ghz Fcc Only)
ODU and antenna of not less than 1.2 dB. If cable loss is below 1.2 dB with a 6 ft diameter external antenna, the connectorized PTP 250 may exceed the maximum radiated spurious emissions allowed under FCC 5.8 GHz rules.
Page 73: Grounding And Lightning Protection
PTP 250 User Guide Grounding and lightning protection Grounding and lightning protection This section describes the grounding and lightning protection requirements of a PTP 250 installation. Electro-magnetic discharge (lightning) damage is not covered under warranty. The recommendations in this guide, when followed correctly, give the user the best protection from the harmful effects of EMD.
Page 74: Lightning Protection Zones
Grounding and lightning protection Chapter 2: Planning considerations Lightning protection zones The ‘rolling sphere method’ (Figure 12) is used to determine where it is safe to mount equipment. An imaginary sphere, typically 50 meters in radius, is rolled over the structure.
Page 75: General Protection Requirements
PTP 250 User Guide Grounding and lightning protection General protection requirements To adequately protect a PTP 250 installation, both ground bonding and transient voltage surge suppression are required. Basic requirements The following basic protection requirements must be implemented: The ODU must be in ‘Zone B’ (see Lightning protection zones on page 2-16).
Page 76: Protection Requirements For A Mast Or Tower Installation
Grounding and lightning protection Chapter 2: Planning considerations Figure 13 Grounding cable minimum bend radius and angle Radius not less than 203 mm (8 in) Angle not less than 90° ODU requirements The following ODU protection requirements must be implemented: The ODU must be grounded to the supporting structure.
Page 77: Figure 14 Grounding And Lightning Protection On Mast Or Tower
PTP 250 User Guide Grounding and lightning protection Figure 14 Grounding and lightning protection on mast or tower Outdoor CAT5e cable: gel-filled, shielded with copper-plated steel CAT5e cable: foil or braid screened, with screened connectors PTP 250 ground cable First point of contact with tower...
Page 78: Protection Requirements For A Wall Installation
Grounding and lightning protection Chapter 2: Planning considerations Protection requirements for a wall installation If the ODU is to be mounted on the wall of a building, then in addition to the general protection requirements (above), the following requirements must be observed: The equipment must be lower than the top of the building or its lightning air terminal.
Page 79: Protection Requirements On A High Rise Building
PTP 250 User Guide Grounding and lightning protection Protection requirements on a high rise building If the ODU is to be mounted on a high rise building, it is likely that cable entry is at roof level (Figure 16) and the equipment room is several floors below (Figure 17).
Page 80: Figure 17 Grounding And Lightning Protection Inside High Building
Grounding and lightning protection Chapter 2: Planning considerations Protection inside a high rise building The following protection requirements must be observed inside multi-story or high rise buildings (Figure 17): The drop cable shield must be bonded to the building grounding system at the entry point to the building.
Page 81: Data Network Planning
‘Green Ethernet’ switches Do not connect PTP 250 units to Ethernet networking products that control the level of the transmitted Ethernet signal based on the measured length of the Ethernet link, for example Green Ethernet products manufactured by D-Link Corporation.
Page 82: Ordering Components
PTP 250 kits The PTP 250 is supplied as a 'Link' or an 'End' kit. A ‘Link’ kit contains components for both ends of a link (including two ODUs and two PoE power supply units). An 'End' kit contains components for one end of a link (including one ODU and one PoE power supply).
Page 83: Table 12 Inventory For Odu And Poe Power Supply Kits
PTP 250 User Guide Ordering components Table 12 Inventory for ODU and PoE power supply kits Item Notes ODUs ODUs may be Integrated (as illustrated) or Connectorized. ‘End Complete’ kit contains one ODU with grounding cable. ‘Link Complete’ kit contains two ODUs with grounding cables.
Page 84 Ordering components Chapter 2: Planning considerations Item Notes Mounting bracket assembly ‘End Complete’ kit contains one bracket. ‘Link Complete’ kit contains two brackets. Choice of mains leads (US, UK and ‘End Complete’ kit contains one US, one UK and one EU lead. ‘Link Complete’...
Page 85: Other Standard Components
PTP 250 User Guide Ordering components Other standard components In addition to ODU and PoE power supply kits, standard installations require the components listed in Table Table 13 Additional inventory for standard installations Item Notes Outdoor drop cable Superior Essex BBDGe cable is...
Page 86 PVC tape, tie- wraps, bolts, washers and nuts. Lightning Protection Unit (LPU) kits Two kits are required per standard link. ‘LPU End Kit PTP 250/300/500’. Cambium part number WB2978. Kit contents: one LPU, one grounding cable, nuts, bolts and two cable glands.
Page 87: Components Required With Connectorized Odus
PTP 250 User Guide Ordering components Item Notes Drop cable tester An optional item for testing the resistances between the RJ45 pins of the drop cable. Order from the support website (see Contacting Cambium Networks on page 2). Components required with connectorized ODUs...
Page 88 5.4 GHz - up to 27 dBi per polarization or antenna. 5.8 GHz - up to 37.6 dBi per polarization or antenna. Antennas not included in these tables are strictly prohibited for use with the PTP 250 in the specified bands.
Page 89: Table 15 Allowed Antennas For Deployment In Usa/Canada - 5.4 Ghz
PTP 250 User Guide Ordering components This radio transmitter ( IC certification number 109AO-5X250 ) has been approved by Industry Canada to operate with the antenna types listed below with the maximum permissible gain and required antenna impedance for each antenna type indicated.
Page 90 Ordering components Chapter 2: Planning considerations Manufacturer Antenna Type Gain (dBi) Parabolic dish Gabriel Gabriel 6-foot High Performance QuickFire 37.4 Parabolic, HQF6-52-N Gabriel Gabriel 2-foot High Performance Dual 28.1 QuickFire Parabolic, HQFD2-52-N Gabriel Gabriel 4-foot High Performance Dual 34.3 QuickFire Parabolic, HQFD4-52-N Gabriel Gabriel 6-foot High Performance Dual 37.3...
Page 91 PTP 250 User Guide Ordering components Manufacturer Antenna Type Gain (dBi) Parabolic dish RadioWaves Radio Waves 3-foot Dual-Pol Parabolic, 31.1 SPD3-5.2 (31.1 dBi) RadioWaves Radio Waves 3-foot Parabolic, SP3-5.2 31.4 (31.4 dBi) RadioWaves Radio Waves 4-foot Dual-Pol Parabolic, 34.4 SPD4-5.2 (34.4 dBi) RadioWaves Radio Waves 4-foot Parabolic, SP4-5.2...
Page 92: Alternative And Additional Components
Ordering components Chapter 2: Planning considerations Alternative and additional components Some alternatives and additions to standard PTP 250 components are listed in Table Table 17 Alternative PTP 250 components Item Notes Powered Indoor Unit (PIDU Plus) This is the approved alternative to the PoE power supply.
Page 93: Chapter 3: Legal Information
Any such modifications could void the user’s authority to operate the equipment and will void the manufacturer’s warranty. The following topics are described in this chapter: Cambium Networks end user license agreement on page Hardware warranty on page...
Page 94: Cambium Networks End User License Agreement
Software and Documentation is licensed for use. Grant of license Cambium Networks Limited (“Cambium”) grants you (“Licensee” or “you”) a personal, nonexclusive, non-transferable license to use the Software and Documentation subject to the Conditions of Use set forth in “Conditions of use” and the terms and conditions of this Agreement.
Page 95: Conditions Of Use
PTP 250 User Guide Cambium Networks end user license agreement Conditions of use Any use of the Software and Documentation outside of the conditions set forth in this Agreement is strictly prohibited and will be deemed a breach of this Agreement.
Page 96: Title And Restrictions
Cambium Networks end user license agreement Chapter 3: Legal information Title and restrictions If you transfer possession of any copy of the Software and Documentation to another party outside of the terms of this agreement, your license is automatically terminated.
Page 97: Right To Use Cambium's Name
PTP 250 User Guide Cambium Networks end user license agreement Right to use Cambium’s name Except as required in “Conditions of use”, you will not, during the term of this Agreement or thereafter, use any trademark of Cambium, or any word or symbol likely to be confused with any Cambium trademark, either alone or in any combination with another word or words.
Page 98: Disclaimer
Cambium Networks end user license agreement Chapter 3: Legal information Disclaimer CAMBIUM DISCLAIMS ALL WARRANTIES OF ANY KIND, WHETHER EXPRESS, IMPLIED, STATUTORY, OR IN ANY COMMUNICATION WITH YOU. CAMBIUM SPECIFICALLY DISCLAIMS ANY WARRANTY INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILTY, NONINFRINGEMENT, OR FITNESS FOR A PARTICULAR PURPOSE.
Page 99: U.s. Government
PTP 250 User Guide Cambium Networks end user license agreement U.S. government If you are acquiring the Product on behalf of any unit or agency of the U.S. Government, the following applies. Use, duplication, or disclosure of the Software and Documentation is subject to the restrictions set forth in subparagraphs (c) (1) and (2) of the Commercial Computer Software –...
Page 100: Assignment
Cambium Networks end user license agreement Chapter 3: Legal information Assignment This agreement may not be assigned by you without Cambium’s prior written consent. Survival of provisions The parties agree that where the context of any provision indicates an intent that it survives the term of this Agreement, then it will survive.
Page 101 PTP 250 Third Party Licenses and Attributions The document contains licenses and attributions for third party software components that are incorporated into the PTP 250 product. This document is available for download from the support website (see Contacting Cambium Networks on page 2).
Page 102: Hardware Warranty
Hardware warranty Chapter 3: Legal information Hardware warranty Cambium’s standard hardware warranty is for one (1) year from date of shipment from Cambium or a Cambium Point-To-Point Distributor. Cambium warrants that hardware will conform to the relevant published specifications and will be free from material defects in material and workmanship under normal use and service.
Page 103: Limit Of Liability
PTP 250 User Guide Limit of liability Limit of liability IN NO EVENT SHALL CAMBIUM NETWORKS BE LIABLE TO YOU OR ANY OTHER PARTY FOR ANY DIRECT, INDIRECT, GENERAL, SPECIAL, INCIDENTAL, CONSEQUENTIAL, EXEMPLARY OR OTHER DAMAGE ARISING OUT OF THE USE OR...
Page 104 Limit of liability Chapter 3: Legal information 3-12 phn-2510_002v000 (Mar 2012)
Page 105: Chapter 4: Reference Information
Ethernet interface. Compliance with safety standards on page lists the safety specifications against which the PTP 250 has been tested and certified. It also describes how to keep RF exposure within safe limits. Compliance with radio regulations on page 4-12 describes how the PTP 250 complies with the radio regulations that are in force in various countries.
Page 106: Equipment Specifications
Equipment specifications Chapter 4: Reference information Equipment specifications This section contains specifications of the ODU and power supply unit that are required for PTP 250 installations. ODU specifications The ODU conforms to the specifications listed in Table Table 19 Table...
Page 107: Power Supply Unit Specifications
PTP 250 User Guide Equipment specifications Power supply unit specifications The power supply units (PoE and PIDU) conform to the specifications listed in Table Table 22, Table 23 Table Table 21 Power supply unit physical specifications Category PoE power supply...
Page 108: Table 23 Power Supply Unit Electrical Specifications
Equipment specifications Chapter 4: Reference information Table 23 Power supply unit electrical specifications Category PoE power supply PIDU (9001GR and PD7001) AC input voltage 100 to 240 V AC 90 to 264 V AC AC input current 0.8A @ 110 to 220 V AC AC frequency 50 to 60 Hz 47 to 60 Hz...
Page 109: Wireless Specifications
PTP 250 User Guide Wireless specifications Wireless specifications This section contains specifications of the PTP 250 wireless interface. These specifications include RF bands, channel width and link loss. General wireless specifications Table 25 contains radio system specifications for the 5.4 GHz band.
Page 110: Table 26 5.8 Ghz Rf Specifications
Wireless specifications Chapter 4: Reference information Table 26 5.8 GHz RF specifications Radio technology Specification RF band 5.725-5.850 GHz Channel selection By dynamic frequency control and manual intervention Automatic detection on start-up and continual adaptation. Dynamic frequency control Initial capture 10-15 sec. Out of service on interference 100 ms.
Page 111: Data Network Specifications
PTP 250 User Guide Data network specifications Data network specifications This section contains specifications of the PTP 250 Ethernet interface. Ethernet interfaces The PTP 250 Ethernet ports conform to the specifications listed in Table Table 27 Ethernet bridging specifications Ethernet bridging Specification Protocol IEEE802.1 compatible...
Page 112: Compliance With Safety Standards
EN301 489-4. For EN 61000-4-2: 1995 Electro Static Discharge (ESD), Class 2, 8 kV air, 4 kV contact discharge, the PTP 250 have been tested to ensure immunity to 15 kV air and 8 kV contact.
Page 113: Human Exposure To Radio Frequency Energy
Limiting Exposure to Time-Varying Electric, Magnetic, and Electromagnetic Fields. Power density exposure limit Install the radios for the PTP 250 families of PTP wireless solutions so as to provide and maintain the minimum separation distances from all persons. The applicable power density exposure limit from the standards (see...
Page 114 Compliance with safety standards Chapter 4: Reference information Calculation of power density The following calculation is based on the ANSI IEEE C95.1-1991 method, as that provides a worst case analysis. Details of the assessment to EN50383:2002 can be provided, if required.
Page 115: Table 30 Power Compliance Margins
PTP 250 User Guide Compliance with safety standards Table 30 Power compliance margins Band Antenna Tx Burst P (W) d (m) R (m) (W/m 5.4 GHz Integrated 0.0050 0.0050 0.089 Max gain 0.0025 0.0025 0.089 connectorized ETSI Integrated 0.0200 0.0200 0.178...
Page 116: Compliance With Radio Regulations
Compliance with radio regulations Chapter 4: Reference information Compliance with radio regulations This section describes how the PTP 250 complies with the radio regulations that are in force in various countries. Changes or modifications not expressly approved by Cambium could void the user’s authority to operate the system.
Page 117: Fcc And Etsi Compliance Testing
Notwithstanding that Cambium has designed (and qualified) the PTP 250 products to generally meet the Class B requirement to minimize the potential for interference, the PTP 250 product ranges are not marketed for use in a residential environment. phn-2510_002v000 (Mar 2012)
Page 118: Notifications
Chapter 4: Reference information Notifications The PTP 250 5.4 GHz variant complies with the radio regulations that are in force in Europe. The PTP 250 5.8 GHz variant complies with the radio regulations that are in force in the USA, Canada and Europe. The relevant notifications are specified in this section.
Page 119: 5.8 Ghz Fcc And Ic Notification
PTP 250 User Guide Notifications 5.8 GHz FCC and IC notification This system has achieved Type Approval in various countries around the world. This means that the system has been tested against various local technical regulations and found to comply. The frequency band in which the system operates is ‘license exempt’ and the system is allowed to be used provided it does not cause interference.
Page 120: Figure 19 Fcc And Ic Certifications On Product Labels
Notifications Chapter 4: Reference information Industry Canada (IC) This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B conforme á la norme NMB-003 du Canada. RSS-GEN issue 3 (7.1.3) Licence-Exempt Radio Apparatus: This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
Page 121: 5.8 Ghz European Union Notification
Notifications 5.8 GHz European Union notification PTP 250 units operating in the 5.8 GHz band are Class 2 devices as they operate on frequencies that are not harmonized across the EU. Currently, only Denmark, Germany, Eire (IRL), Norway, Spain and the UK allow the products to operate in the 5.8 GHz band.
Page 122 Notifications Chapter 4: Reference information 4-18 phn-2510_002v000 (Mar 2012)
Page 123: Chapter 5: Installation
PTP 250 User Guide Chapter 5: Installation This chapter describes how to install the PTP 250 hardware, To install the equipment at each PTP 250 link end, perform these tasks: Preparing for installation on page describes the checks to be performed before proceeding with the installation.
Page 124: Preparing For Installation
Preparing for installation Chapter 5: Installation Preparing for installation This section describes the checks to be performed before proceeding with the installation. Unit pre-configuration It is common practice to pre-configure the units during staging before site installation by performing the following tasks from Chapter 6: Configuration and alignment: Connecting to the unit...
Page 125: Selecting Installation Options
2-10. Preparing personnel In no event shall Cambium Networks be liable for any injury or damage caused during the installation of the Cambium PTP 250. Ensure that only qualified personnel undertake the installation of a PTP 250 link.
Page 126: Installing The Odu
Installing the ODU Chapter 5: Installation Installing the ODU Perform this task to install the ODU (integrated or connectorized) on the supporting structure. This task consists of the following procedures: Checks and safety precautions on page Selecting a position for the ODU (connectorized) on page Mounting the ODU on page...
Page 127: Selecting A Position For The Odu (Connectorized)
PTP 250 User Guide Installing the ODU Check that the ODU is pre-fitted with a mounting bracket (designed to ease installation) and with a ground cable (Figure 22). Figure 22 Checking the ODU before mounting Selecting a position for the ODU (connectorized)
Page 128: Mounting The Odu
Installing the ODU Chapter 5: Installation Mounting the ODU To mount the ODU, proceed as follows: Attach the ODU bracket strap to the pole using M8 x 40 mm or M8 x 70 mm bolts, M8 flat washers and M8 coil washers. Tighten to ensure the assembly grips, but can be adjusted on the pole.
Page 129 PTP 250 User Guide Installing the ODU Connect the ODU ground cable to the to the grounding system, within 0.3 meters (1 ft) of the ODU bracket and on the same metal (if necessary, remove paint and apply anti-oxidant compound first).
Page 130: Installing Connectorized Antennas
Installing connectorized antennas Chapter 5: Installation Installing connectorized antennas If the ODU is connectorized, perform this task to install separate antenna(s). Preparing for connectorized installations Before proceeding with the installation, perform the following checks: Check that the correct components are available, as described in Ordering components on page 2-24.
Page 131 PTP 250 User Guide Installing connectorized antennas If the ODU is to be mounted indoors, assemble the Polyphaser LSXL-ME or LSXL as shown: If the ODU is to be mounted indoors, install lightning arrestors at the building entry point and connect the lighting arrestors to the master ground bar of the...
Page 132 Installing connectorized antennas Chapter 5: Installation When dressing the antenna cables, form drip loops near the lower ends. These ensure that water is not constantly channeled towards the connectors. If the ODU is mounted outdoors, weatherproof the N type connectors fitted to the ODU by following the procedure Weatherproofing an N type connector on page...
Page 133: Weatherproofing An N Type Connector
PTP 250 User Guide Installing connectorized antennas Dress the antenna cables and attach them to the supporting structure using site approved methods. Ensure that no undue strain is placed on the ODU or antenna connectors. Ensure that the cables do not flap in the wind, as flapping cables are prone to damage and induce unwanted vibrations in the supporting structure.
Page 134 Installing connectorized antennas Chapter 5: Installation Smooth tape edges: Cut a 125mm (5 inches) length of rubber tape (self amalgamating): Expand the width of the tape by stretching it so that it will wrap completely around the connector and cable: Press the tape edges together so that there are no gaps.
Page 135 PTP 250 User Guide Installing connectorized antennas Wrap a layer of 50 mm (2 inch) PVC tape from bottom to top, starting from 25 mm (1 inch) below the edge of the self-amalgamating tape, overlapping at half width. Repeat with a further four layers of 19 mm (0.75 inch) PVC tape, always overlapping at half width.
Page 136: Installing The Drop Cable And Lpu
Installing the drop cable and LPU Chapter 5: Installation Installing the drop cable and LPU Perform this task to install the drop cable from the ODU to the PoE power supply, and to provide grounding and lightning protection for the installation. This task consists of the following procedures: Preparing drop cables on page 5-15.
Page 137: Preparing Drop Cables
PTP 250 User Guide Installing the drop cable and LPU Preparing drop cables Perform this task to prepare the CAT5e cables that connect the ODU to the PoE power supply. Always use Cat5e cable that is gel-filled and shielded with copper-plated steel. Alternative types of cable are not supported by Cambium.
Page 138: Assembling An Rj45 Connector And Gland
Installing the drop cable and LPU Chapter 5: Installation Assembling an RJ45 connector and gland Perform this task to prepare the outdoor CAT5e cable with connectors and glands. Safety precautions The metal screen of the drop cable is very sharp and may cause personal injury. When preparing the drop cable, take the following safety precautions: ALWAYS wear cut resistant gloves (check the label to ensure they are cut resistant).
Page 139: Figure 23 Correct Cable Preparation For Drop Cable Of The Supported Type
PTP 250 User Guide Installing the drop cable and LPU Figure 23 Correct cable preparation for drop cable of the supported type Check that the crimp tool matches the RJ45 connector being used; otherwise the cable or connector may be damaged.
Page 140: Installing And Grounding The Main Drop Cable
Installing the drop cable and LPU Chapter 5: Installation Figure 24 Drop cable with RJ45 and gland Installing and grounding the main drop cable Perform this procedure to install the main drop cable, connect it to the ODU, and ground it to the supporting structure.
Page 141: Connecting An Rj45 And Gland To A Unit
PTP 250 User Guide Installing the drop cable and LPU Connecting an RJ45 and gland to a unit Perform this task to connect the drop cable to an ODU or LPU. This procedure contains illustrations of an ODU, but it applies in principle to both the ODU and the LPU.
Page 142 Installing the drop cable and LPU Chapter 5: Installation When the gland body has been fitted, tighten the gland back shell. Do not over-tighten the gland back shell, as the internal seal and structure may be damaged. The following example shows correctly tightened and over- tightened gland back shells: 5-20 phn-2510_002v000 (Mar 2012)
Page 143: Disconnecting An Rj45 And Gland From A Unit
PTP 250 User Guide Installing the drop cable and LPU Disconnecting an RJ45 and gland from a unit Perform this task to disconnect the drop cable from an ODU or LPU. This procedure contains illustrations of an ODU, but it applies in principle to both the ODU and the LPU.
Page 144: Making A Drop Cable Ground Point
Installing the drop cable and LPU Chapter 5: Installation Making a drop cable ground point Perform this task to connect the screen of the drop cable to the metal of the supporting structure using a cable grounding kit. The cable grounding kit for 1/4” and 3/8” cable (Figure 8) contains the following components:...
Page 145 PTP 250 User Guide Installing the drop cable and LPU Fold the ground wire strap around the drop cable screen and fit cable ties. Tighten the cable ties with pliers. Cut the surplus from the cable ties. Cut a 38mm (1.5 inches) section of self-amalgamating tape and wrap it completely around the joint between the drop and ground cables.
Page 146 Installing the drop cable and LPU Chapter 5: Installation Use the remainder of the self-amalgamating tape to wrap the complete assembly. Press the tape edges together so that there are no gaps. Wrap a layer of PVC tape from bottom to top, starting from 25 mm (1 inch) below and finishing 25 mm (1 inch) above the edge of the self-amalgamating tape, over lapping at half width.
Page 147 PTP 250 User Guide Installing the drop cable and LPU Repeat with a further four layers of PVC tape, always overlapping at half width. Wrap the layers in alternate directions: Second layer: top to bottom. Third layer: bottom to top.
Page 148: Installing And Grounding The Drop Cable At Building Entry
Installing the drop cable and LPU Chapter 5: Installation Installing and grounding the drop cable at building entry Perform this procedure to install and ground the drop cable and LPU at the building (or cabinet) entry point (Figure 25). Figure 25 Grounding at building entry To run the drop cable into the building, proceed as follows: Make an entry point into the building and run the main drop cable into the building.
Page 149 PTP 250 User Guide Installing the drop cable and LPU Connect the LPU-PoE cable to the other port of the LPU, as described in Connecting an RJ45 and gland to a unit on page 5-19. Run the LPU-PoE cable to the location of the PoE power supply.
Page 150: Installing The Poe Power Supply
The PoE power supply is not a repeater, and does not amplify the Ethernet data signal. Do not configure the cable length between the Ethernet network source, the PoE power supply and the PTP 250 ODU beyond 100 meters (333ft). The PoE power supply is not waterproof and should be mounted away from sources of moisture.
Page 151: Connecting The Poe Power Supply To The Drop Cable
PTP 250 User Guide Installing the PoE power supply Connecting the PoE power supply to the drop cable Do not dress the PoE power supply cables too tightly, as this may make the connections unreliable. Fit an RJ45 connector (but no gland) to the PoE end of the LPU-PoE cable. Connect the cable to the DATA &...
Page 152 Installing the PoE power supply Chapter 5: Installation 5-30 phn-2510_002v000 (Mar 2012)
Page 153: Chapter 6: Configuration And Alignment
PTP 250 User Guide Chapter 6: Configuration and alignment This chapter describes all configuration and alignment tasks that are performed when a PTP 250 link is deployed. Before proceeding with unit configuration and antenna alignment, observe the precautions described in Preparing for configuration and alignment on page 6-2.
Page 154: Preparing For Configuration And Alignment
Preparing for configuration and alignment Chapter 6: Configuration and alignment Preparing for configuration and alignment This section describes the checks to be performed before proceeding with unit configuration and antenna alignment. Safety precautions during configuration and alignment All national and local safety standards must be followed while configuring the units and aligning the antennas.
Page 155: Connecting To The Unit
Install Java on the management PC (if not already installed), as this is used by the PTP 250 web interface. To configure the local management PC to communicate with the PTP 250, proceed as follows: Select Properties for the Ethernet port.
Page 156 Connecting to the unit Chapter 6: Configuration and alignment Click on Properties. Enter an IP address that is valid for the 169.254.X.X network, avoiding: 169.254.0.0 and 169.254.1.1 and 169.254.1.2 A good example is 169.254.1.3: Enter a subnet mask of 255.255.0.0. Leave the default gateway blank.
Page 157: Connecting To The Pc And Powering Up
PTP 250 User Guide Connecting to the unit Connecting to the PC and powering up Ensure AC power is supplied to the PoE power supply using an AC cable with an appropriate ground connection approved for the country of operation.
Page 158: Logging Into The Web Interface
Connecting to the unit Chapter 6: Configuration and alignment Logging into the web interface To log into the web interface as a system administrator, proceed as follows: Start the web browser from the management PC. Type the IP address of the unit (factory default is 169.254.1.1) into the browser address bar.
Page 159 PTP 250 User Guide Connecting to the unit On the first login to a new unit, or on the first login to a unit that has been reset to full or partial default configuration, the Change Password page is displayed: Enter and confirm the new Password.
Page 160: Figure 27 Menu And System Summary Page (On First Login)
Connecting to the unit Chapter 6: Configuration and alignment Figure 27 Menu and System Summary page (on first login) When a wireless link is established, "link" management becomes available. The procedure for toggling between link and node management is described in Selecting link or node management on page 7-4.
Page 161: Upgrading Firmware Version
PTP 250 User Guide Upgrading firmware version Upgrading firmware version Perform this task to ensure that the latest firmware version is installed on the unit. This task consists of the following procedures: Checking the installed firmware version on page Uploading a new firmware version...
Page 162: Uploading A New Firmware Version
Save the pre-upgrade system configuration as described in Saving the system configuration on page 6-34. Go to the support website (see Contacting Cambium Networks on page 2) and find Point-to-Point software updates. Download and save the required firmware image PTP250-04-01.bin (for example Select menu option Firmware Update.
Page 163: Figure 28 Firmware Update With Link Management
PTP 250 User Guide Upgrading firmware version On completion, the Upload Successful page is displayed: Select Apply and Reboot. The reboot process will take up to 120 seconds. During this time it will not be possible to communicate with the unit. After the reboot, check that the required firmware image is loaded and running.
Page 164: Using The Configuration Wizard
Using the configuration wizard Chapter 6: Configuration and alignment Using the configuration wizard Perform this task to configure the LAN, date SNMP and SMTP attributes of the unit. This task consists of the following procedures: Starting configuration wizard on page 6-12 Step 1: LAN configuration on page...
Page 165: Step 1: Lan Configuration
PTP 250 User Guide Using the configuration wizard Step 1: LAN configuration Step 1 of the configuration wizard is for updating the LAN configuration (Figure 30). The attributes are described in Table 32. Update IP Address, Subnet Mask and Gateway IP Address to meet network requirements (as specified by the network administrator).
Page 166 Ensure that the configured VLAN is accessible, otherwise it will not be possible to access the unit following the next reboot. The PTP 250 management function is only compatible with single VLAN tagged packets. Any management packet with two or more packets will be ignored.
Page 167: Step 2: Date And Time Settings
PTP 250 User Guide Using the configuration wizard Step 2: Date and time settings Step 2 of the configuration wizard is for setting the date and time (Figure 31). The attributes are described in Table 33. Update the attributes as required and select Next.
Page 168: Step 3: Snmp/Smtp Configuration
Time Zone The time zone in which this unit operates. Enable NTP If this is ticked, the PTP 250 will obtain accurate date and time updates from a networked time server. Time Server IP The IP address of the networked NTP server.
Page 169: Table 34 Snmp Mib Ii Configuration Attributes
PTP 250 User Guide Using the configuration wizard Configuring MIB II Enter the MIB II attributes for this managed node (Table 34). Table 34 SNMP MIB II Configuration attributes Attribute Meaning MIB II Sys Name An administratively-assigned name for this managed node. By convention, this is the fully-qualified domain name.
Page 170: Table 35 Snmp Configuration Attributes
‘public’. Access Access level allowed. To allow operators to monitor the status of links, SNMP clients (PTP 250 systems) are limited to read only access to the SNMP server. The point in the object identifier hierarchy at which access is allowed.
Page 171: Table 36 Smtp Configuration Attributes
The email address to which the PTP 250 will send the alert messages. Email From The email address used by the PTP 250 to log into the email server. This must be recognized by the server. Email Server IP The IP address of the networked email server.
Page 172: Step 4: Confirm Configuration
Using the configuration wizard Chapter 6: Configuration and alignment Step 4: Confirm configuration Step 4 of the configuration wizard is for reviewing and confirming the updated attributes (Figure 35). Updated attributes are highlighted in yellow. If any of the attributes are incorrect, select Back to return to previous steps and update them.
Page 173: Using The Wireless Wizard
PTP 250 User Guide Using the wireless wizard Using the wireless wizard Perform this task to configure the wireless attributes of the unit. This task consists of the following procedures: Starting wireless wizard on page 6-21 Step 1: Wireless configuration...
Page 174: Step 1: Wireless Configuration
2-5. When operating with external antennas in countries that impose an EIRP limit, choose an external antenna and RF cable that will not cause the PTP 250 to exceed the EIRP limit, based on the instructions in Calculating maximum power level for connectorized units page 2-13.
Page 175: Table 37 Step 1: Wireless Configuration Attributes
Table 37 Step 1: Wireless Configuration attributes Attribute Meaning System Name Name of this PTP 250 system (link). Spaces are not allowed, so use underscores instead. Site Name An identifier for the link end. Spaces are not allowed, so use underscores instead.
Page 176 Using the wireless wizard Chapter 6: Configuration and alignment Attribute Meaning Channel Width Width (MHz) of the radio channel used by this link. The selection depends upon the frequency variant and country of operation. This can only be updated at the Master unit. Channel Selection The channel (MHz) in which this link operates.
Page 177: Step 2: Confirm Wireless Configuration
PTP 250 User Guide Using the wireless wizard Attribute Meaning Enable 40MHz When enabled, this feature shortens the cyclic prefix in 40 MHz Optimization mode. Encryption Key Key to be used for link encryption. The same key must be used at (64 hexadecimal both ends of the link.
Page 178 Using the wireless wizard Chapter 6: Configuration and alignment If any of the attributes are incorrect, select Back to return to previous steps and update them. If all attributes are correct, choose one of the following options: If antenna alignment tones are not wanted, select Finish. This is the preferred option before bench testing the units.
Page 179: Aligning Antennas
PTP 250 User Guide Aligning antennas Aligning antennas Before performing this task, check that hardware installation is complete (apart from the network connections) at both the Master and Slave sites. This task consists of the following procedures: Starting up the units...
Page 180: Aligning Antennas
Aligning antennas Chapter 6: Configuration and alignment Aligning antennas Use this procedure to align linked antennas (master and slave), whether integrated or connectorized. Prior to alignment, ensure that the following parameters are available: Location of both sites (latitude and longitude). Bearing to the other end of the link for both sites.
Page 181: Aligning Separate Antennas For Spatial Diversity
PTP 250 User Guide Aligning antennas If after repeated attempts to align, the receive level still does not lie within the predicted range, this may be because the data provided to the prediction tool (such as PTP LINKPlanner) is inaccurate. For example estimates of path obstructions, antenna heights or site locations may be inaccurate.
Page 182: Table 38 Antenna Alignment Tones
Aligning antennas Chapter 6: Configuration and alignment Antenna alignment tones This is the first method that may be used to monitor receive signal level during antenna alignment. The ODU emits audible tones during installation to assist with alignment. The pitch of the alignment tone is proportional to the received power of the wireless signals.
Page 183: Disarming The Units
PTP 250 User Guide Aligning antennas Graphical alignment This is the second method that may be used to monitor receive signal level during antenna alignment. Select menu option Installation Wizard, Graphical Alignment. The Graphical Alignment page is displayed (Figure 39).
Page 184: Connecting Link To The Network
Connecting link to the network Chapter 6: Configuration and alignment Connecting link to the network When antenna alignment is complete, the link performance must be checked and then the link connected to the network for operational running. Also, the system configuration should be saved.
Page 185: Connecting To The Network
PTP 250 User Guide Connecting link to the network Figure 40 System Status page Connecting to the network To connect to the network, proceed as follows: Disconnect the local PC from the PoE power supply at the Master and Slave sites.
Page 186: Saving The System Configuration
Connecting link to the network Chapter 6: Configuration and alignment Saving the system configuration Save the system configuration in the following situations: After a new unit has been fully configured as described in this chapter. After any change has been made to the configuration. Before upgrading the unit to a new firmware version.
Page 187 PTP 250 User Guide Chapter 7: Operation This chapter provides instructions for operators of the PTP 250 web user interface. The following topics are described in this chapter: Web-based management on page describes the layout and the main menu options of the PTP 250 web-based management interface.
Page 188: Chapter 7: Operation
Web-based management Chapter 7: Operation Web-based management This section describes the layout and the main menu options of the PTP 250 web-based management interface. The following topics are covered: Accessing the web interface on page Using the menu options on page...
Page 189: Using The Menu Options
PTP 250 User Guide Web-based management Figure 43 Menu and System Summary page (wireless link up) Using the menu options All web pages contain the menu navigation bar on the left hand side. The menu is used to navigate to other web pages. The currently selected option is always highlighted with a light blue background.
Page 190: Selecting Link Or Node Management
Web-based management Chapter 7: Operation Using the configuration wizard on page 6-12 Recovering a lost IP address on page 7-28 Saving the system configuration on page 6-34 Restoring the system configuration on page 7-24 Resetting to default configuration (no country reset) on page Using the wireless wizard on page...
Page 191: Figure 45 Example Of Web Page In Link Management Mode
PTP 250 User Guide Web-based management If Link is selected, the GUI is set to ‘link’ management mode. This means that the web interface is being used to manage both units in the link. In link mode, many of the web pages display attributes for both the ‘Managed’...
Page 192: Viewing The System Summary
For more information, refer to Managing link status and alerts on page 7-13. System Name Name of this PTP 250 system (link). This is set in the Installation Wizard; see Step 1: Wireless configuration on page 6-22. Site Name Location of this link end.
Page 193: Viewing The System Status
PTP 250 User Guide Web-based management Attribute Meaning System Clock The system clock presented as local time, allowing for zone and daylight saving. This is set in the Installation Wizard; see Step 2: Date and time settings on page 6-15.
Page 194: Table 41 System Status Equipment Attributes
Table Table 41 System Status Equipment attributes Attribute Meaning System Name Name of this PTP 250 system (link). This is set in the Installation Wizard; see Step 1: Wireless configuration on page 6-22. Site Name Location of this link end. This is set in the Installation Wizard; see Step 1: Wireless configuration on page 6-22.
Page 195: Table 42 System Status Lan Attributes
PTP 250 User Guide Web-based management Table 42 System Status LAN attributes Attribute Meaning IP Address Internet protocol (IP) address. The factory default is 169.254.1.1, but it may be reset in the Installation Wizard; see Step 1: LAN configuration on page 6-13.
Page 196: Table 43 System Status Wireless Attributes
Web-based management Chapter 7: Operation Table 43 System Status Wireless attributes Attribute Meaning Link Status Current status of the wireless link. A state of ‘Up’ on a green background indicates that a point-to-point link is established. Any status on a yellow background indicates that the wireless link is not established.
Page 197 PTP 250 User Guide Web-based management Attribute Meaning Link Loss The maximum, mean, minimum and latest measurements of Link Loss (dB). See Diagnostics calculated over time on page 7-23. The link loss is the total attenuation of the wireless signal between the two point-to-point units.
Page 198: Changing Password
Web-based management Chapter 7: Operation Attribute Meaning Wireless Reception The maximum, mean, minimum and latest measurements of Rate Receive Data Rate (Mbps). See Diagnostics calculated over time on page 7-23. Transmit The modulation mode currently being used on the transmit Modulation Mode channel.
Page 199: Managing Link Status And Alerts
PTP 250 User Guide Managing link status and alerts Managing link status and alerts This section describes how to manage PTP 250 link status and alerts. This section contains the following procedures: Managing link status on page 7-13. Managing email alerts on page 7-14.
Page 200: Managing Email Alerts
Managing link status and alerts Chapter 7: Operation Table 44 Wireless Link Status attribute values Value Meaning The wireless link is up and running. Registering The wireless link is up, but not yet running (still handshaking, setting security and so on). Acquiring The Master unit is waiting for a slave.
Page 201: Managing Performance
PTP 250 User Guide Managing performance Managing performance This section describes how to manage the performance of the PTP 250 link. This section contains the following procedures: Checking system statistics on page 7-15 Checking channel status on page 7-18 Checking the retry histogram...
Page 202: Table 46 Data Port Counter Attributes In The System Statistics Page
Managing performance Chapter 7: Operation The System Statistics page contains the following system counters: Data port counters (Table Management port counters (Table Wireless port counters (Table The packet counter attributes each contain a number in parentheses; this shows the number of packets received since the last page refresh. The page automatically refreshes every two seconds.
Page 203: Table 48 Wireless Port Counter Attributes In The System Statistics Page
PTP 250 User Guide Managing performance Table 48 Wireless Port Counter attributes in the System Statistics page Attribute Meaning Rx Packets The number of good packets the bridge has received from the wireless interface. Tx Packets The number of good packets the bridge has sent for transmission by the wireless interface.
Page 204: Checking Channel Status
Managing performance Chapter 7: Operation Checking channel status To check channel status, select menu option Statistics, Channel Status. The Channel Status page is displayed (Figure 51). This page shows the status of each channel as recorded by the latest band scan. Figure 51 Channel Status page The Signal Strength graph is described in Figure...
Page 205: Figure 52 Channel Status Page - Signal Strength Graph
PTP 250 User Guide Managing performance Figure 52 Channel Status page – Signal Strength graph phn-2510_002v000 (Mar 2012) 7-19...
Page 206: Checking The Retry Histogram
Managing performance Chapter 7: Operation Checking the retry histogram The retry histogram gives an indication of wireless quality. It records how many frames have been re-transmitted how many times. Valid values can vary; a short range LOS link should run with very few retries. A longer range nLOS link may run with up to 10% retries. To check the retry histogram, select menu option Statistics, Retry Histogram.
Page 207: Using The Diagnostics Plotter
PTP 250 User Guide Managing performance Using the diagnostics plotter To plot key performance statistics against time, select menu option Diagnostics Plotter. The Diagnostics Plotter page is displayed (Figure 54). Use the Diagnostics Selector drop- down list to select a diagnostic type to plot. Use the Trace Selection to select traces of the maximum (blue), mean (red) or minimum (green) values of the diagnostic type.
Page 208: Table 49 Diagnostics Plotter Attributes
Managing performance Chapter 7: Operation Table 49 Diagnostics Plotter attributes Attribute Meaning Link Loss Defined in Table Transmit Power Defined in Table Receive Power Defined in Table Receive Vector Error Defined in Table Transmit Data Rate Defined in Table Receive Data Rate Defined in Table Aggregated Data Rate...
Page 209: Diagnostics Calculated Over Time
PTP 250 User Guide Managing performance Diagnostics calculated over time The System Status page (Figure 47) contains seven diagnostic attributes that are calculated over time and presented as arrays of four elements (Figure 55). Figure 55 Diagnostic attributes calculated over time...
Page 210: Restoring, Resetting And Rebooting
Restoring, resetting and rebooting Chapter 7: Operation Restoring, resetting and rebooting This section describes how to restore the system configuration, reset to defaults, recover the IP address and reboot the unit. This section contains the following procedures: Restoring the system configuration on page 7-24 Resetting to default configuration (no country reset)
Page 211: Resetting To Default Configuration (No Country Reset)
PTP 250 User Guide Restoring, resetting and rebooting Resetting to default configuration (no country reset) Use the Save & Restore page to reset the unit to factory default configuration, without resetting the country of operation (selected at first login). When the unit is reset to default configuration, the current configuration is lost and the unit reboots, causing loss of service.
Page 212: Resetting To Default Configuration (With Country Reset)
Chapter 7: Operation Resetting to default configuration (with country reset) Use the reset plug (supplied in each PTP 250 ‘Link Complete’ or ‘End Complete’ kit) to reset the unit to factory default configuration, including reset of the country of operation (this will have to be reselected at first login after the reset).
Page 213 When logging into the unit, change Password and select Country Code (these will be prompted). If the power supply is a PIDU, the PIDU reset switch WILL NOT work. The PTP 250 reset plug must be used. phn-2510_002v000 (Mar 2012)
Page 214: Recovering A Lost Ip Address
Select menu option Configuration, LAN Configuration. Obtain the correct IP address of the unit from the LAN Configuration page. Rebooting the unit To reboot the ODU select menu option Reboot PTP 250. The Reboot Wireless Unit page is displayed (Figure 56).
Page 215: Chapter 8: Troubleshooting
PTP 250 User Guide Chapter 8: Troubleshooting This chapter contains procedures for identifying and correcting faults in a PTP 250 link. These procedures can be performed either on a newly installed link, or on an operational link if communication is lost, or after a lightning strike.
Page 216: Testing Link End Hardware
If a fault is suspected in the link end hardware, check the PoE power supply LED states and use Table 50 to choose the correct test procedure. The PTP 250 is supplied with one of two variants of the PoE power supply: the 9001GR (Figure 6) or the PD7001 (Figure...
Page 217: No Power Detected
PTP 250 User Guide Testing link end hardware No power detected LED state: PoE type 9001GR: PORT is off. PoE type PD7001: AC is off. Meaning: The PoE power supply is not receiving power from the AC outlet. Action: Remove the power lead from the PoE power supply. Test that the AC outlet and power lead are working: if they are working, report a suspected PoE power supply fault to Cambium.
Page 218 Testing link end hardware Chapter 8: Troubleshooting Use the LPU (if installed) to check that power is available on the cable to the ODU. Access the connections by rotating the LPU lid as shown: Slacken the lid nut but do not remove it. Test that test point P1 on the LPU PCB corresponds to pin 1 on the RJ45.
Page 219: No Device (Odu) Detected
PTP 250 User Guide Testing link end hardware No device (ODU) detected LED state: PoE type 9001GR: PORT is on yellow (steady). PoE type PD7001: AC is on green (steady) and PORT is off. Meaning: The PoE power supply is receiving power from an AC outlet, but no device (ODU) is detected at the DATA &...
Page 220: Figure 57 Ethernet Packet Test Flowchart
Testing link end hardware Chapter 8: Troubleshooting Figure 57 Ethernet packet test flowchart phn-2510_002v000 (Mar 2012)
Page 221 PTP 250 User Guide Testing link end hardware Test Ethernet packet errors reported by ODU Log in to the unit and select menu option Statistics. Select Reset Counters at the bottom of the page and wait until the Data Port Rx Packets counter has reached 1 million. If the...
Page 222: Testing Resistance In The Odu Cable
2) by selecting Order Cable Tester and completing the order form. The resistance values printed on the PTP drop cable tester do not apply to the PTP 250. Instead, refer to the resistance values given in Table 52 for guidance.
Page 223: Table 51 Rj45 Cable Resistance Tests At The Poe Power Supply End
PTP 250 User Guide Testing link end hardware Unplug the drop cable from the DATA & POWER OUT port of the PoE power supply. Insert the drop cable RJ45 plug into the drop cable tester socket. Then, perform the tests...
Page 224: Table 52 Typical Resistance Values In Ptp 250 Odu-Poe Drop Cable
Testing link end hardware Chapter 8: Troubleshooting Table 52 Typical resistance values in PTP 250 ODU-PoE drop cable Cable length Resistance (Ohms) between (ODU to PoE power supply) pins 1&2, 3&6, 4&5 and 7&8 0 meters (0 feet) 10 meters (33 feet)
Page 225: Testing The Radio Link
PTP 250 User Guide Testing the radio link Testing the radio link This section describes how to test the link when there is no radio communication, when it is unreliable, when the data throughput rate is too low, or when a unit is causing radio or TV interference.
Page 226: Some Activity
7-21. Radio and television interference If a PTP 250 unit is interfering with radio or television reception (this can be determined by turning the equipment off and on), attempt the following corrective actions: Realign or relocate the antenna.
Page 227: Glossary
PTP 250 User Guide Glossary Term Definition Address Resolution Protocol ATPC Automatic Transmit Power Control BPSK Binary Phase Shift Keying Channel Availability Check cross-sectional area Critical Security Parameter Direct Current Distinguished Encoding Rules Dynamic Frequency Selection EIRP Equivalent Isotropic Radiated Power...
Page 228 Glossary Term Definition NLOS Non-Line-of-Sight NMEA National Marine Electronics Association Network Time Protocol Outdoor Unit OFDM Orthogonal Frequency Division Multiplex IBM Compatible Personal Computer Power over Ethernet PING ICMP Echo Request Point-to-Point Quadrature Amplitude Modulation Random Access Memory Radio Frequency RSSI Received Signal Strength Indication SELV...

Cambium Networks PTP 250 User Manual

Chapter 1: Product Description

Chapter 2: Planning Considerations

Chapter 3: Legal Information

Chapter 4: Reference Information

Chapter 5: Installation

Chapter 6: Configuration and Alignment

Chapter 7: Operation

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cambium Networks PTP 250

Summary of Contents for Cambium Networks PTP 250
