TERMINAL CONFIGURATION

Ethernet Reader requires TCP/IP connection to the YSoft SafeQ server. Ethernet Reader has own IP and MAC
address.
There is special tool for configuration of Ethernet Reader – SafeQ Terminal Configuration utils – see Picture 4.
Note: This util applies to Ethernet Reader (based on YSoft SafeQ® Terminal UltraLight) with firmware version
1.2 and newer. There is another tool for older firmware version.
Picture 4 - SafeQ Terminal Configuration util
When you start this tool and press on Scan button, the tool discovers all the readers in the same network (in-
dependently on the network settings), see Picture 5. You can change settings for the particular reader in the list
and using Save button the configuration is applied. Upon successful configuration change the terminal will be
rebooted.
