Ford F53 Owner's Manual page 82

Fuse or Relay
Number
J6
J7
J8
J9
J10
J11
J12
J13
J14
J15
J16
1
Mini fuse.
2
J case fuse.
Diode and Relay Module
Locate the module box with the power
distribution box in from of the radiator.
Motorhome (TY3) Canada/United States of America, enUSA, Edition date: 201712, Second Printing
Fuses
Fuse Rating
Headlamp daytime running lamp relay
feed.
High beam headlamps flash to pass.
(Instrument panel fuses #25, 31).
Ignition switch feeds (instrument panel
2
40A
fuses #F26).
Instrument panel fuses #F24, F22, F20,
2
40A
F26, F21, F8, F6, F4, F2.
Power distribution box fuses M4, M1-4.
Instrument panel fuses F11, F13, F15, F17.
2
50A
Starter relay feed.
2
30A
Starter motor solenoid.
Power distribution box fuse M1-1.
2
60A
Power brake assist motor (HydroMax).
Trailer tow electronic brake.
2
30A
Lighting primary.
2
60A
Power distribution box fuse M1-2.
Instrument panel fuses #F19, F5, F3.
Brake on/off.
2
20A
Hazard.
Horn.
2
20A
HydroMax anti-lock brake system module.
2
60A
Trailer tow parking lamps.
2
20A
79
Protected Components
