Ford F53 Owner's Manual page 77

Fuse or Relay
Number
J3
J4
J5
J6
J7
J8
J9
J10
J11
J12
J13
J14
Motorhome (TY3) Canada/United States of America, enUSA, Edition date: 201712, Second Printing
Fuses
Fuse Rating
Daytime running lamps on/off relay coil.
Headlamp daytime running lamp relay
feed.
Instrument panel fuses #25, 31.
Vehicle power.
2
30A
Powertrain control module relay feed.
Power distribution box fuse F16, F17, F18,
J22.
Cigar lighter feed.
2
20A
Diagnostic tool connector.
— Not used.
Starter relay feed.
2
30A
Starter motor solenoid.
Anti-lock brake system module (Hydro-
2
40A
boost).
Power brake assist motor (HydroMax).
2
60A
Power distribution box fuse #F20.
Trailer tow park lamps.
2
20A
Instrument panel fuse #4, 10, 16, 22.
2
50A
HydroMax anti-lock brake system module.
2
60A
Hydroboost anti-lock brake system
2
40A
module.
Fuel pump relay feed.
2
20A
Fuel injectors.
Mass air flow sensor.
Fuel pump motor.
Powertrain control module.
Trailer tow electronic brake.
2
30A
Ignition switch feed (instrument panel
2
40A
fuses #1, 5, 7, 11, 13, 14, 17, 19, 23, 36).
(Power distribution box fuse #F19, F22,
F21).
— Not used.
74
Protected Components
