- Page 1 ROADCAST ELAY Operations Manual P/N 100-145-0024 February 2018 Software Version 5.14.xxx Model TSS-2470 Broadcast Time Delay Model TSS-2470 Variable Time Delay Copyright© 2018, 360 Systems All rights reserved...
-
Page 2: Table Of Contents
Product Improvements and Upgrades ..............6 Trademarks and Software Copyrights ..............6 Introduction ........................7 TSS-2470 Time Delay Features .................. 9 TSS-2470 II Time Delay Additional Features ............10 Installation ........................11 Unpacking ........................11 Package Contents ....................11 Rack Mounting......................12 System Cooling ...................... - Page 3 Edit Configure Dialog.....................23 Configure Network ....................26 Date and Time ......................29 Network Time Protocol ..................30 Technical Specifications..................... 32 Connector Pin Designations ..................34 HDBNC Connectors....................34 System Board Ports ....................34 Mechanical Drawing ....................35 Program Updates from USB Memory ..............36 Maintenance........................
-
Page 4: Safety Notices
Only qualified personnel should perform installation and service. Refer to appropriate sections of this product manual for instruction. Contact 360 Systems Customer Support for further explanation, or to clarify any uncertainty. Disconnect both power cords before removing the cover. -
Page 5: Product Damage Precautions
To avoid risk of fire, replace the power cord only with same type and rating as specified. Replace damaged power cords immediately. This product is grounded through the grounding conductor of the power cord. To avoid electric shock, do not remove or modify the contacts on the plug. Prevent the power cord from being walked on, pinched, or abraded. -
Page 6: Product Registration
360 Systems in the U.S. and/or foreign countries. Other trademarks referred to in this document are the property of their respective owners. Software in this product is based on the work of, or is copyright by, 360 Systems, Trolltech, and FreeType Team. Copyright 2003-2018 by 360 Systems. -
Page 7: Introduction
TSS-2470 Time Delay Introduction There are two versions of the 360 Systems Time Delay. The TSS-2470 Time Delay and the TSS-2470 Variable Time Delay. Both offer a high-quality program delay for television broadcast, satellite delivery, and other applications requiring a user-settable delay time for video, audio, and ancillary data. - Page 8 time period; if several Time Delays are fed identical input signals, they will remain in sync indefinitely. The TSS-2470 is convertible from an SD delay server to an HD delay server with no additional hardware or software. It employs high quality, HD video encoding at 100 Mb/s or SD encoding at 30 Mb/s which is ideal for this application, providing superior final image quality when used in conjunction with other codec processes such as MPEG or H.264 for satellite transmission and cable distribution.
-
Page 9: Tss-2470 Time Delay Features
TSS-2470 Time Delay Features Functions in a stand-alone configuration with no external machine controls, and requires no third-party software. Operates unattended for long periods of time. No operator intervention or file maintenance required for continuous operation. All settings are non-volatile, allowing unattended restart on power-up. The unit automatically reconfigures itself for the last-specified delay time, and re-enters the record/playback cycle. -
Page 10: Tss-2470 Ii Time Delay Additional Features
TSS-2470 Time Delay Additional Features Same feature set as the TSS-2470 Time Delay but with the added benefit of being able to reset the delay time without a restart. Four “quick set” delay time buttons for setting or resetting a delay time. Transport controls over the delay feed such as Pause, Jog, FF, REW, and Play are available ... -
Page 11: Installation
There must be at least two inches (50mm) of space between the product and outer container. The corners of the product must be protected. Package Contents Confirm that all items on the packing list have been received. Contact 360 Systems if any item is missing. Model TSS-2470 Time Delay Keyboard ... -
Page 12: Rack Mounting
times, even when switched away from it. When first powering up the TSS-2470 Time Delay, use only the supplied keyboard and mouse directly connected. Then test the KVM switch system that will be used thoroughly before installation is completed. Be especially careful about this when using extender cables. -
Page 13: Power Conditioning
A disadvantage is that it may create its own power transients when switching between utility power and its inverter supply. For this reason 360 Systems does not recommend this type for use with the TSS-2470 Time Delay. Continuous Conversion UPS Design This improved design continuously converts utility power to DC, stores it in a battery, then produces isolated AC power from an inverter. - Page 14 360 Systems’ engineers have experience with thousands of installations, and have become aware of a number of environmental factors that can adversely affect performance. Two of these have already been discussed: power conditioning and inadequate cooling.
-
Page 15: About Tss-2470 Time Delay Software
Several steps can be taken to protect equipment from static discharge: Do not install critical broadcast equipment in a room with carpeting. Connect equipment racks directly to an earth ground with a heavy copper conductor. Do not operate equipment with a lifted safety ground (green frame ground). ... -
Page 16: Front Panel Features
Front Panel Features Front Panel The front panel is held on by two roller clips, one on each end of the panel. To remove the front panel, grasp the left or right end of the panel and pull straight out. The front panel is reinstalled by reversing this process. -
Page 17: Indicators
Indicators Three blue LED Status Indicators appear on the front panel. These indicators are illuminated continuously or in some cases are dark when inactive on not connected. The NIC indicator will flash on and off if a network cable is attached indicating network activity. Error conditions are Front Panel Indicators indicated by flashing of the SYS indicator. -
Page 18: Rear Panel Drawing
Rear Panel Drawing SDI Video I/O Power Supply Module 1 Power Supply Module 2 USB ports for Keyboard / Mouse Gigabit Ethernet port 1 Gigabit Ethernet port 2 VGA Video monitor output 18 TSS-2470 Time Delay... -
Page 19: Rear Panel Connectors
Rear Panel Connectors The TSS-2470 Time Delay provides one video input with up to 16 Embedded audio channels, one delayed video output with audio, and a second monitoring output which reflects input video and audio (E-E). ANEL ESIGNATION ONNECTOR UNCTION HDBNC HD-SDI/SD-SDI Video Program Input HDBNC... -
Page 20: Operations
Operations The Graphical User Interface The TSS-2470 Time Delay uses a Graphical User Interface (GUI) to control most functions. A keyboard and mouse are included, and the user needs to supply an SVGA compliant monitor. The GUI is divided into two sections: Run/Stop control, and Time Delay Set. Controls and displays for each section are described below. -
Page 21: Basic Tss-2470 Run/Stop Control
Basic TSS-2470 Run/Stop Control The RUN button initiates or restarts the TSS-2470 Time Delay process. Press RUN to begin a new delay cycle and start the Time-to-Air countdown. When the countdown reaches zero, it changes to ON LINE, and the delayed video begins playing from the main Program Output. Upon power up the TSS-2470 Time Delay will automatically enter Run mode and start the delay process if a valid input is detected, or if Frame Synchronizer is selected a valid reference signal is detected. -
Page 22: Tss-2470 Ii Variable Control Functions
TSS-2470 II Variable Control Functions The TSS-2470 II has the same main control window for setting up the initial delay time. Once the initial delay is established, the functions in the output channel window will become available. Playback Time The Playback Time Window displays the Time of Day that the current output frame was recorded. -
Page 23: Edit Configure Dialog
Delay Presets The four numbered Delay Presets buttons are available for quickly setting or resetting the delay time. The time setting for each button is configurable at any time. Once a delay time is established on a delay preset, clicking the numbered button immediately reconfigures and starts the delay for the established time. - Page 24 This field adjusts the amount of VANC data (such as Closed Captions) stored by the server. Valid range is from 0KB per frame to 4KB per frame. Consult with 360 Systems technicians before setting this to values higher than 4 KB/frame.
- Page 25 The Output Timing values are the only parameters that are adjustable while the TSS-2470 Time Delay is in RUN to allow timing while in operation. Adjustments take effect immediately without using Apply or OK, allowing the effects to be seen easily. The picture will blank while the change takes effect.
-
Page 26: Configure Network
Configure Network Network parameters are set in the Configure Network dialog. Network communication for the TSS-2470 Time Delay is designed primarily to support access to error logs and factory diagnostics. It can also support automatic time updates using the NTP protocol. The system time is used only in the diagnostic system message logs;... - Page 27 Each TSS-2470 Time Delay is shipped with a unique default network Host Name and IP Address. Update these configurations to suit your specific network environment. Factory defaults for networking are: Disable Network is checked Use DHCP is unchecked Disable Network Checkbox: This selection turns the network off or on.
- Page 28 Note: When URLs (non-numeric site address such as pool.ntp.org) are used in the NTP Servers field, the IP address of at least one DNS (Domain Name server) in the Name Servers field must be provided. Typically, this address is supplied by your Internet Service Provider. These name servers translate URL names into numeric IP addresses needed to access the sites in question.
-
Page 29: Date And Time
Once established, the server’s file share becomes accessible from a networked PC by either browsing the local network or mapping the share as a drive. When mapping the share to a drive the following convention should be utilized. <host name> TSS_Video_Files <host name>... -
Page 30: Network Time Protocol
Date and Time dialog Network Time Protocol Automatic Date/Time Updates The TSS-2470 Time Delay’s clock can be set automatically from a network time server that is referenced to Coordinated Universal Time (UTC). This is accomplished using the Network Time Protocol (NTP). A time server could be an in-house computer that is equipped with a GPS receiver, or a radio receiver locked to signals from the NIST radio station W W V . - Page 31 Figure 1 - NTP Network Block Diagram Configuring NTP The TSS-2470 Time Delay GUI is used to set the time zone and to enter the networking parameters. Selecting the Time Zone Starting at the main menu bar, Click Edit->Configure->Date-Time screen. When “Automatic Updates”...
-
Page 32: Technical Specifications
Technical Specifications Video Time delay Adjustable, 30 sec to >24 hrs. (HD) Time set format HH:MM:SS:FF (True number of frames per hour) Video reference Synchronizes to video input. Accuracy Frame accurate. Inputs 1 HD-SDI/SD-SDI, 75 HDBNC connector Outputs 1 delayed output, 1 E-E monitor. Each available as both HD-SDI/SD-SDI 75... - Page 33 Miscellaneous Operating system Linux® Front panel indicators LED: Power-on, Network Connectivity, System alarm Miscellaneous ports USB, SVGA display, Ethernet Cooling Forced air Power 100 to 240 volts universal, 50/60 Hz, 165 watts Mechanical 3½” x 19” x 18” (89 x 483 x 457 mm) H-W-D Mounting Rack mount (1U) Weight...
-
Page 34: Connector Pin Designations
This resolution is best viewed on 17-inch or larger monitors. 360 Systems does not provide monitors for the TSS-2470 Time Delay. Use only VESA compliant monitors with a maximum refresh rate of at least 75 Hz. -
Page 35: Mechanical Drawing
Mechanical Drawing Dimensional Drawing • 35 Mechanical Drawing... -
Page 36: Program Updates From Usb Memory
1. Discontinue all record, play, network transfer or system-level operations. 2. With power applied, insert a 360 Systems USB Flash Drive into one of the USB sockets. 3. Press the front panel power switch briefly to shutdown the TSS-2470 Time Delay. -
Page 37: Maintenance
POWER FLASHING indicates that there is a Shut down the TSS-2470 Time Delay and fault in the system power supply. contact 360 Systems Customer Support for further hardware diagnosis. SYSTEM FLASHING indicates that the CPU fan Shut down the TSS-2470 Time Delay and is running slow, or stopped;... -
Page 38: Gigabit Ethernet Indicators
Gigabit Ethernet Indicators The Gigabit Ethernet port NET1 has the following indicator LEDs: Label Indication Meaning Green on The port is connected to a valid link partner ACT/LNK (Left) Green flashing Data activity No link 10 Mbps 10=OFF 100=YELLOW Yellow flashing 100 Mbps 1000=GREEN Green... -
Page 39: Removing The Top Cover
NOTE: The TSS-2470 Time Delay is vulnerable to accidental system reset while removing or re- installing the front panel. It is recommended that the front panel be removed or attached only while the system is OFF. Removing the Top Cover Using a No. -
Page 40: General Handling Precautions
General Handling Precautions ESD Precautions Observe electrostatic discharge (ESD) precautions to avoid damaging static-sensitive components when handling any PC card or disk drive. When the case of your server is open and its internal parts are exposed, do not touch any internal part without first grounding yourself to the chassis. -
Page 41: Accessing The Main System Board
Accessing the Main System Board There are no user-configurable options on the main system board. If you suspect that the system board is not operating properly, consult with 360 Systems before proceeding. DO NOT undertake any repairs on it. Managing the RAID Disk Array The RAID Disk Array is for the most part, self maintaining. - Page 42 GUI Drive Fault Indication Status messages you may see on the status line: Initializing, indicated by "Initializing" Degraded, indicated by "Degraded" Resyncing, indicated by "Resyncing x%" Recovering, indicated by "Recovering x%" Drive Removed, indicated by "Drive ‘n’ removed" where ‘n’ corresponds the drive number of a drive that has either failed or been physically removed.
- Page 43 If the rebuild process does not start automatically, it may be necessary to cycle power. If this does not result in the rebuild starting automatically, contact 360 Systems support. When powering up with a newly replaced drive, the RAID boot up screen should indicate that the drive is present.
- Page 44 Replacing a Hard Drive Each hard drive bay is numbered 0 through 3, as are the drives. If for any reason one or more drives have been removed, they must be reinstalled in a bay whose number matches the drive. Installation in the wrong location will damage data stored on all drives. Although the drives are hot swappable and can be replaced while the system is running, it is recommended that if possible the unit be taken offline and powered off prior to conducting any maintenance or repairs.
-
Page 45: Notices
Important: As the owner of new capital equipment, you will want to take advantage of product information, enhancements, upgrades, or notifications issued by 360 Systems. Please register your product so 360 Systems can remain in contact with you. To register your product, visit http://360systems.com/support/product-registration/ or call our Customer Service Department at 818-991-0360. -
Page 46: Software
Software Software in this product is based on the work of, or copyright by, 360 Systems, Montavista, Trolltech, and FreeType Team. Copyright 2003-2016 by 360 Systems. 46 TSS-2470 Time Delay... -
Page 47: End User License Agreement
For 360 Systems® TSS-2470 Time Delay Software IMPORTANT THIS IS A LEGAL AGREEMENT BETWEEN YOU (“YOU”) AND 360 SYSTEMS® (“COMPANY”). COMPANY IS WILLING TO LICENSE THE TSS-2470 TIME DELAY SOFTWARE TO YOU ONLY UPON THE CONDITION THAT YOU ACCEPT ALL OF THE TERMS CONTAINED IN THIS SOFTWARE LICENSE AGREEMENT (“AGREEMENT”). - Page 48 Multiple User License. Software provided under this option may be installed on more than one TSS-2470 owned or controlled by You, the maximum number of which is indicated on the purchase invoice for this Software. 2. You may not transfer the Software to another entity or person. Any such transfer terminates your license under this Agreement.
- Page 49 6. You may terminate the license granted in Section 1 of this Agreement at any time by destroying or erasing your copy of the Software. Company may terminate this Agreement immediately and without notice if you fail to comply with any term or condition of this Agreement. In the event of termination of this Agreement, all the sections of this Agreement will survive except for Section 1.
-
Page 50: Limited Warranty
In the case of replacement, if the replacement for a defective product is no longer available, 360 Systems will replace it with a similar product or, if not available, a product of equal value. - Page 51 EMPLOYEES OR REPRESENTATIVES BE LIABLE FOR DIRECT, CONSEQUENTIAL, PUNITIVE, SPECIAL OR INDIRECT DAMAGES, LOSS OF PROFITS, INCONVENIENCE OR ANY OTHER LOSSES DUE TO THE PRODUCT OR ITS OPERATION, DUE TO ITS FAILURE TO OPERATE IN ACCORDANCE WITH ITS SPECIFICATIONS. Some states do not allow the exclusion or limitation of incidental or consequential damages under certain circumstances, so the above limitations and exclusions may not apply to you.
-
Page 52: Index
Motherboard ..............41 Telephone ............45 Mounting ................12 Website ..............45 Network Time Protocol ........... 30 Address, 360 Systems ............45 Notices, General ..............45 Configure Options Dialog ..........23 NTP ..................30 Connectors Output Timing ............24, 25 BNC ............... - Page 53 Time Delay Presets ............21 Time Delay Setting ............21 Program Updates ..........36 Time to Air ................21 VANC Line Selection ............24 Timing, Output ............24, 25 Variable Control Functions ..........22 Top Cover Vertical (Lines) timing adjustment ........ 25 Removing .............
