Collet Holder Kits
Instructions for Use
PLEASE USE THIS INSTRUCTION SHEET IN CONJUNCTION WITH SECURE-GRIP AND VALVE CHANGE OUT MANUALS
Specialist kits have been developed to enable the Equalizer Secure Grip Hydraulic Flange Spreaders and Valve Change
Out Tools to be operated in situations where the standard tool may not fit.
It shortens/lengthens the collet holders, effectively opening/closing up the tool so that it engages the flanges on
either side of the valve or spacer.
For example, on larger flange-joints or where clearance around the flange is restricted.
GENERAL ARRANGEMENTS AND PARTS LISTS
SG4TM/SG6TM Collet Holder Kit
ITEM NO
1
2
3
SG13TE/SG15TE Collet Holder Kit
ITEM NO
DESCRIPTION
1
Collet Holder
2
Drive Tube
TS_Collet-Holder-Kit_Rev01b_A4
DESCRIPTION
QTY
Collet Holder
2
Drive Cone
2
Collet
2
SG18TE Collet Holder Kit
QTY
ITEM NO
2
1
2
2
SG11TM Collet Holder Kit
ITEM NO
1
2
DESCRIPTION
QTY
Collet Plug
1
Drive Cone
1
DESCRIPTION
QTY
Collet Holder
2
Drive Cone
2
SG25TE Collet Holder Kit
ITEM NO
DESCRIPTION
1
Collet Plug
2
Drive Tube
3
Washer
QTY
1
1
2
09 February 2018
