ExSilent Qleaf Pro Quick Start Manual

Contents of the package

1 Qleaf Pro module 1 5
2 Introduction set of soft tips
made of hypoallergenic material
(S open en closed version,
M and L closed version)
3
Battery ejection tool
3
Colored side indicator 6
4
5 Carrying box
2
6 Quick start guide, L
4
User manual and
M
Data sheet
S
1

Placing the battery and switching the module on

First remove the sticker from the battery. Place the battery in the module with
the (+) sign (this is the at side of the battery where the sticker was) at the same
side as the (+) sign on the module. The module is set to program 1.
2

Placing the module in the soft tip

Hold the soft tip with the pull cord pointed upwards. Place the module in the
soft tip with the arrow facing towards you.
Push the module gradually into the soft tip. Insert the module all the way into
the soft tip. The device is now ready for use.
