INSTALLATION INSTRUCTIONS
UNLEASH.
THE SMARTEST PERFORMANCE TUNING TECHNOLOGY
FUEL MANAGEMENT
DUCATI HYPERMOTARD 821 | 2014-2015
F198 | T198
1>READ
WARNINGS >
•
We strongly suggest that an experienced technician install this product.
Read through all instructions before beginning installation.
•
•
This document is intended for use by qualified technicians.
•
This is not a replacement for the factory Engine Control Unit (ECU).
•
Refer to a factory service manual for more specific stock component
identification/location information and removal/assembly procedures.
WARNINGS >
Use only in race or other closed-course applications and never on public roads.
•
•
Z-Fi products are not certified by the California Air Resource Board (CARB) for
use on CA highways.
GETTING HELP
Factory support is available in the US at 909-597-8300.
•
•
For fastest support outside of the US, find your local importer at bazzaz.net.
FUEL + QS + TRACTION CONTROL
INSTALLING
USING
R
Advertisement
Table of Contents
Related Manuals for Bazzaz ZFi
Summary of Contents for Bazzaz ZFi
- Page 1 Z-Fi products are not certified by the California Air Resource Board (CARB) for use on CA highways. GETTING HELP Factory support is available in the US at 909-597-8300. • • For fastest support outside of the US, find your local importer at bazzaz.net.
- Page 2 4. Shift switch and mounting hardware (For Z-Fi TC only) 5. O2 stabilizer 6. Speed amplifier 7. USB cable 8. Swingarm stickers 9. Velcro 10. Download Bazzaz software from bazzaz.net/index.php/software-overview FUEL HARNESS 1. Main 2. Map Select 3. Z-AFM 4. TPS 5.
- Page 3 NOTE: DO NOT DISCONNECT THE FACTORY ECU DURING THE INSTALLATION 4>SECURE 1. The Bazzaz control unit will be installed and secured on top of the air box. 2. Connect the Bazzaz fuel harness and begin to route the harness towards the air box along the right hand side of the bike.
- Page 4 1. Locate the factory front injector, which can be found between the radiator and cylinder valve cover. 2. Disconnect the factory injector connector and install the Bazzaz injector connectors inline (To ease in the installation you may loosen the radiator to create more space).
- Page 5 5>CONNECT (CONT.) 1. Locate the factory rear injector near the back of the airbox. 2. Disconnect the factory injector connector and install the Bazzaz injector connectors inline. FACTORY BAZZAZ 1. Locate the factory neutral sensor, which can be found on the back side of the motor on the right hand side near the exhaust.
- Page 6 2. Disconnect the factory rear wheel speed sensor connector and install the Bazzaz speed amplifier in line. 3. Connect the remaining lead to the Bazzaz BAZZAZ harness. 1. Locate the white tail light connector in FACTORY the tail section of the bike.
- Page 7 6>CONNECT (FOR USE WITH Z-FI TC ONLY!) 1. Connect the Bazzaz coil harness to the Bazzaz control unit, and begin to route the harness towards the left side of the bike and back towards the tail section of the bike.
- Page 8 2. Remove the factory shift rod and begin to install the Bazzaz shift switch using one of the supplied allen stud bolts and tighten. 3. Begin to install the Bazzaz shift rod. The shift rod may need to be cut to get your original shift pedal height.
- Page 9 You can switch from map 1 to map 2 by unplugging the map select jumper on the Bazzaz fuel harness. Map 1 will be pre-programmed; depending on your model, there may be a pre- programmed map in the map 2 slot.
- Page 10 After it is determined that everything is correct, reinstall the components removed in step 3. 12>USE MAPS The Bazzaz controller is capable of storing two maps. Switch maps by connecting or disconnecting the map select jumper supplied with the kit. Or use the optional handlebar-mounted switch to switch maps on the fly (sold separately).
- Page 11 Purchased separately. Build race-level fuel maps for your specific modifications, fuel type, engine, and atmospheric conditions simply while riding. 02 sensor mounts into exhaust and control box easily plugs in to any Bazzaz Z-Fi product. 299.95 MAP SELECT/ TC ADJUST SWITCH Purchased separately.
- Page 12 THE SMARTEST PERFORMANCE TUNING TECHNOLOGY F198 |T198...
