INSTALLATION INSTRUCTIONS
UNLEASH.
THE SMARTEST PERFORMANCE TUNING TECHNOLOGY
BMW R1200R | 07-11
F1084
FUEL CONTROL
1>READ
WARNINGS >
• We strongly suggest that an experienced technician install this product.
• Read through all instructions before beginning installation.
• This document is intended for use by qualified technicians.
• This is not a replacement for the Engine Control Unit (ECU).
• Refer to a factory service manual for more specific stock component
identification/location information and removal/assembly procedures.
WARNINGS >
• Use only in race or other closed-course applications and never on public roads.
• Z-Fi products are not certified by the California Air Resource Board (CARB) for
use on CA highways.
GETTING HELP
• Factory support is available in the US at 909-597-8300.
• For fastest support outside of the US, find your local importer at bazzaz.net.
INSTALLING
USING
R
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Bazzaz F1084
Summary of Contents for Bazzaz F1084
- Page 1 • Z-Fi products are not certified by the California Air Resource Board (CARB) for use on CA highways. GETTING HELP • Factory support is available in the US at 909-597-8300. • For fastest support outside of the US, find your local importer at bazzaz.net.
-
Page 2: Included Parts
2>IDENTIFY INCLUDED PARTS 1. Z-Fi control unit 2. Fuel harness 3. USB cable 4. Scotchlok (2) 5. Zip ties 6. Velcro FUEL HARNESS GROUND INJ 2 (RIGHT) INJ 1 CKPS POWER (LEFT) MAP SELECT Z-AFM CONNECTOR MAIN... - Page 3 3>REMOVE 1. Seats 2. All side panels 3. Tank 4>SECURE Using the supplied Velcro patch, secure the Bazzaz control unit under the tank and against the fuse box.
- Page 4 5>CONNECT/ROUTE 1. Connect the main connector of the Bazzaz fuel harness to the control unit. 2. Route the portion of the fuel harness with the injector #2 and CKPS connectors to the right side of the bike. 3. Route the portion with the +12V switched power connector towards the rear, next to the battery.
- Page 5 INJECTOR 1. Locate the factory Throttle Position Sensor (TPS) and connector, just below the left side injector. 2. Disconnect the TPS connector from the sensor and connect the Bazzaz TPS connectors in-line between the factory connector and sensor. FACTORY BAZZAZ...
- Page 6 8>ROUTE/CONNECT 1. Locate the factory diagnostic connector in the rear of the bike, beneath the rider seat. 2. Route the Bazzaz +12V power connector (labeled with orange tag) to the diagnostic connector. 3. Carefully open up the factory harness (to expose the wiring)
- Page 7 FACTORY FACTORY CONNECTOR INJECTOR 1. Route the Bazzaz Crank Position Sensor (CKPS) lead to the front BAZZAZ right side of the bike. CONNECTOR 2. Locate the factory CKPS connector which can be found near the factory alternator, on the right side, attached to the frame rail.
- Page 8 If problem still persists, please contact Bazzaz tech support • Factory support is available in the US at 909-597-8300. • For fastest support outside of the US, find your local importer at bazzaz.net 11>REINSTALL After it is determined that everything is correct, reinstall the components removed in step 3.
- Page 9 13>SOFTWARE Download the latest software and instructions at bazzaz.net Use software to: View and/or make adjustments to fuel maps • Activate Z-AFM self mapper (sold separately) • Save and load new fuel maps • Re-calibrate throttle position sensor after throttle modifications •...
- Page 10 Weatherproof toggle and easy installation. SELF MAPPER Purchased separately. Build race-level fuel maps for your specific modifications, fuel type, engine, and atmospheric conditions simply while riding. 02 sensor mounts into exhaust and control box easily plugs in to any Bazzaz Z-Fi product. 299.95...
- Page 12 THE SMARTEST PERFORMANCE TUNING TECHNOLOGY F1084...
