Whittier Wood 3460CAFb Assembly Instructions Manual

Stayton media tables

Advertisement

Stayton Media
Tables
CAF = Caffè finish
Model #
3460CAFb
Stayton Media
Console
3462CAFb
Stayton Media
Center
Congratulations!
This fine piece of furniture will make a gorgeous addition to
your home. For the best results, read the Assembly
Instructions before you begin your project.
Service Policy: We will replace any part that is defective,
missing or damaged during assembly. For a replacement
part, directly contact Whittier Wood Products customer
service department by phone, fax, mail or email.
Hours: Our friendly customer service staff can be reached
Monday-Friday 7:00 a.m. to 5:00 p.m. (Pacific Time). You
may leave a message 24 hours a day, seven days a week.
800-653-3336 • Outside the U.S. or Canada: 541-687-0213 • Fax: 541-687-2060
CALL US FIRST! Do not return this item to the store
www.whittierwood.com • P.O. Box 2827 • Eugene, Oregon 97402, U.S.A.
P.O. Box 2827
Eugene, OR 97402 USA

IMPORTANT NOTES:

• For normal household use only. Not recommended for commercial use.
• Do not climb, sit or stand on this piece of furniture.
• Unload items before you move this unit.
• Do not overload the drawer or shelves.
• Before you load or move this unit, tighten all screws and supports.
• Before you begin your project, completely read the Assembly
Instructions.
• Store this item: 1- in its box; 2- in a dry place; 3- in temperatures that
range from 40°F to 90°F (not on a cold and possibly damp cement
floor).
• Periodically inspect your furniture for any loose glue joints, screws or
any other problem that might affect the stability of your furniture.
Tighten or repair as needed.
• This assembly requires two people.
Serious or fatal crushing injuries can occur from furniture tip-over. Use of
tip-over restraints may only reduce but not eliminate the risk of tip-over.
To help prevent tip-over:
Place heaviest items in the bottom drawers.
Unless specifically designed to accommodate, do not set TVs or other
heavy objects on top of this product.
Never allow children to climb or hang on drawers, doors or shelves.
Never open more than one drawer at a time.
Warning: At least one tipping restraint kit was included with your piece of
Whittier Wood Furniture. When you receive your furniture, be sure to find
and properly install the tipping restraint(s). If you cannot locate the
restraint(s), please contact us immediately for replacement.
Notice to California Customers
California Prop 65 requires consumer goods to be labeled if any one of
850+ different chemicals or substances, including wood dust, is present
even in trace amounts. Drilling, sawing, sanding or machining wood
products generates wood dust, a substance known to the State of
California to cause cancer. Warning: This product contains a chemical
or substance known to the State of California to cause cancer, birth
defects or other reproductive harm. California Health and Safety Code
Section 25249.6
DESIGN SUBJECT TO CHANGE WITHOUT NOTICE.
To Order: Provide the finish and furniture model number
(upper portion of this page), the part letter, production
code, quantity needed, reason for replacement and your
full name, address and telephone number.
Parts ship from our Eugene, Oregon factory within one or
two business days from the time we receive your request.
Please allow five to ten business days for delivery.
Production Code:
VN

WARNING

08/15

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3460CAFb and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Whittier Wood 3460CAFb

  • Page 1 Never open more than one drawer at a time. Warning: At least one tipping restraint kit was included with your piece of Whittier Wood Furniture. When you receive your furniture, be sure to find and properly install the tipping restraint(s). If you cannot locate the restraint(s), please contact us immediately for replacement.
  • Page 2 3460CAFb Stayton Media Console; 3462CAFb Stayton Media Center Parts List Please identify the parts and check that quantities received match those on this list. If you need to replace a part, refer to the following letter and part name. Quantity...
  • Page 3 3460CAFb Stayton Media Console; 3462CAFb Stayton Media Center Assembly Instructions Tools Required: Phillips Screwdriver, 9/16" or Adjustable Wrench, Rubber Mallet or Padded Hammer and pencil. Remove the Drawer (F) from the Top Assembly (A). To remove the drawer, pull up on the left side of the Drawer Release Lever while pushing down on the right Drawer Release Lever.
  • Page 4 3460CAFb Stayton Media Console; 3462CAFb Stayton Media Center Assembly Instructions Rotate the Top and Leg assembly so that is sets on the back legs. Turn the Lower Shelf Assembly (Cb) and the Upper Shelf Assembly (D) bottom-side-down and place the dowels into the dowel holes in the Legs.
  • Page 5 3460CAFb Stayton Media Console; 3462CAFb Stayton Media Center Assembly Instructions Attach the legs to the Top Assembly with 5/16" Flat Washers (P) and 3/8" x 2-1/2" Hex Bolts (R) See Figures 5 and 5a. Fig. 5a Fig. 5 Turn the unit onto its top and using the pocket holes as guides, secure the Lower Shelf Assembly (Cb) and the Upper Shelf Assembly (D) to the Legs (B) with eight #8 x 1-1/4"...
  • Page 6 3460CAFb Stayton Media Console; 3462CAFb Stayton Media Center Assembly Instructions Lay the unit with the drawer opening face down. The back apron of the Top Assembly has pre- punched location holes. Place the Back Assembly (E) with the horizontal cleat of the top edge against the back apron of the Top Assembly.
  • Page 7 Before you begin this assembly, identify each part and make sure the quantities received match what is on this list. If you need to replace a part, contact Whittier Wood Furniture customer service and refer to the following list for its name and letter code.
  • Page 8 3460CAFb Stayton Media Console; 3462CAFb Stayton Media Center Assembly Instructions 11. Move the item back into position against the wall and reach underneath the piece of furniture to grasp the loop in the free end of the strap. Pull the free end of the strap until portion between the Cam Buckle (A) and the back apron of the item is tight.
