Whittier Wood 3499AFGAC Assembly Instructions

Mckenzie cocktail table

Advertisement

Quick Links

Model #
3499AFGAC;
3499AFCAF
McKenzie
Cocktail Table
AFGAC = Glazed Antique Cherry finish
AFCAF = Caffè finish
Congratulations!
This fine piece of furniture will make a gorgeous addition to
your home. For the best results, read the Assembly
Instructions before you begin your project.
Service Policy: We will replace any part that is defective,
missing or damaged during assembly. For a replacement
part, directly contact Whittier Wood Products customer
service department by phone, fax, mail or email.
Hours: Our friendly customer service staff can be reached
Monday-Friday 7:00 a.m. to 5:00 p.m. (Pacific Time). You
may leave a message 24 hours a day, seven days a week.
800-653-3336 • Outside the U.S. or Canada: 541-687-0213 • Fax: 541-687-2060
CALL US FIRST! Do not return this item to the store
www.whittierwood.com • P.O. Box 2827 • Eugene, Oregon 97402, U.S.A.
P.O. Box 2827
Eugene, OR 97402 USA
IMPORTANT NOTES:
For normal household use only. Not recommended for commercial use.
Do not climb, sit or stand on this piece of furniture.
Unload items before you move this unit.
Do not overload the shelf.
Before you load or move this unit, tighten all screws and supports.
Before you begin your project, completely read the Assembly
Instructions.
Store this item: 1- in its box; 2- in a dry place; 3- in temperatures that
range from 40°F to 90°F (not on a cold and possibly damp cement
floor).
Periodically inspect your furniture for any loose glue joints, screws or
any other problem that might affect the stability of your furniture.
Tighten or repair as needed.
Notice to California Customers
California Prop 65 requires consumer goods to be labeled if any one of
850+ different chemicals or substances, including wood dust, is present
even in trace amounts. Drilling, sawing, sanding or machining wood
products generates wood dust, a substance known to the State of
California to cause cancer. Warning: This product contains a chemical
or substance known to the State of California to cause cancer, birth
defects or other reproductive harm. California Health and Safety Code
Section 25249.6
DESIGN SUBJECT TO CHANGE WITHOUT NOTICE.
To Order: Provide the finish and furniture model number
(upper portion of this page), the part letter, production
code, quantity needed, reason for replacement and your
full name, address and telephone number.
Parts ship from our Eugene, Oregon factory within one or
two business days from the time we receive your request.
Please allow five to ten business days for delivery.
Production Code:
VN
WARNING
08/13

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3499AFGAC and is the answer not in the manual?

Questions and answers

Summary of Contents for Whittier Wood 3499AFGAC

  • Page 1 For a replacement (upper portion of this page), the part letter, production part, directly contact Whittier Wood Products customer code, quantity needed, reason for replacement and your service department by phone, fax, mail or email.
  • Page 2 3499AFGAC; 3499AFCAF McKenzie Cocktail Table Parts List Please identify the parts and check that quantities received match those on this list. If you need to replace a part, refer to the following letter and part name. Part Description Quantity Top Assembly Shelf Assembly #8 x 1-1/4"...
  • Page 3 3499AFGAC; 3499AFCAF McKenzie Cocktail Table Assembly Instructions Tools Required: Phillips Screwdriver, 9/16" or Adjustable Wrench Turn the Top Assembly (A) upside-down on a clean, protected surface. Place two Legs (B) at the back of the Top Assembly (A), making sure the drilled corners of the legs face toward the Corner Blocks.
  • Page 4 3499AFGAC; 3499AFCAF McKenzie Cocktail Table Assembly Instructions Using the dowels as guides, place the remaining Legs (B) in the remaining two corners making sure the drilled corners of the Legs face toward the Corner Blocks. See Figure 3. Fig. 3a Fig.
  • Page 5 3499AFGAC; 3499AFCAF McKenzie Cocktail Table Assembly Instructions Turn the unit onto its top and using the pocket holes as guides, secure the Shelf Assembly (C) to the Legs (B) with eight #8 x 1-1/4" Pan Head Screws (D). See Figures 5 and 5a.
