Section B; Turning Stations On And Off; A) Using Manual Modes Menu; Using The Main Menu To Activate Stations - Signature Control Systems, Inc. GALAXY Quick Start Manual

Section B describes the procedures to start and stop stations manually. Detailed Descriptions can
be found in the "GALAXY Field Controller Programming Guide, DOCGALPG550."
There are 2 ways to start or stop stations, either thru using (a) Manual Modes Menu or (b) Smart
Switch Activation.

a) Using Manual Modes Menu

Using the Main Menu to Activate Stations

1) Manual Modes 1) Manual Modes 1) Manual Modes 1) Manual Modes
2) Set ON/OFF
3) Programming
4) Budget: 100%
The above "Manual Modes" sub-menu options perform these tasks:
•
Manually starting or stopping a station.
•
Manually starting or stopping a program.
•
Stop all active stations on the Field Controller.
•
Stop all active stations on the site. In order to use this option, there must be a means of
communication between the Field Controllers on the site.
There are optional parameters to set specific DELAY durations.
The Delay Time duration, HHMMSS, is an optional parameter.
•
If the Delay Time duration is omitted in an ON operation, no DELAY is used and the
station starts immediately. If used, it defines the DELAY duration, after expiration of this
duration the Station will start.
The Run Time duration may be used by itself without specifying the Delay Time duration, but if using
the Delay Time duration the Run Time duration must be specified.
Neither of the parameters is required for OFF operations.
DOCGOMQS550 (Rev B)
Section B Turning Stations ON
1) 1) 1) 1) Manual Station Manual Station
Manual Station Manual Station
2) Manual Program
3) All Stations OFF
4) Global OFF
™
GALAXY Field Control Systems
Quick Start Guide - v5.50
and OFF
Manually Starting and Stopping
of Stations
Page 9 of 16
