b) Using Smart Switch Activation

Using the Smart Switch to Activate Stations

The Smart Switch is a short cut to turn stations on manually for a preset time directly from the main
screen without having to go to the Manual Operations menu.

Procedure to Manually Start/Stop a Station Using Smart Switch

Procedure
1. On the Startup screen, enter the three-digit station number for
the station you want to operate.
2. Press the ENTER/NEXT button.
3. Press the ON/AM button. The station that was entered will
manually operate the amount of time specified in the Set Smart
Switch feature.
4. To turn the station off before the time expires repeat the steps
above except press the OFF/PM button instead of the ON/AM
button.

Set Default Time for the Smart Switch

The default time for the Smart Switch is set at ten minutes.
Procedure
5. Press the down arrow button to option
6) Controller Setup.
6. Press the ENTER/NEXT button, and
then press the down arrow button to
option 5) Set Smart Switch.
7. Press the ENTER/NEXT button and
enter the amount of time you want the
station running in hours: minutes: and
seconds format.
8. Press the ENTER/NEXT button to
return to the menu.
DOCGOMQS550 (Rev B)
™
GALAXY
Quick Start Guide - v5.50
Alternately;
Keypad Display
5) Set Smart Switch 5) Set Smart
5) Set Smart 5) Set Smart
Set Smart Switch
Run Time:
00 hr 19 min 00 sec 00 hr 19 min 00 sec
00 hr 19 min 00 sec 00 hr 19 min 00 sec
5) 5) 5) 5) Set Smart Switch
Field Control Systems
Keypad
Press keys:
Switch
Switch Switch
6) Setup Decoders
7) Test Stations
8) Set Passwords
Set Smart Switch
Set Smart Switch Set Smart Switch
6) Setup Decoders
7) Test Stations
8) Set Passwords
