Signature Control Systems, Inc. GALAXY Quick Start Manual page 6

™
GALAXY Field Control Systems
Quick Start Guide - v5.50
ON/AM
OFF/PM
ESC/PREVIOUS
ENTER/NEXT
UP, DOWN, RIGHT and LEFT ARROWS
0 thru 9
Page 6 of 16
Activates watering days and/or pump stations. Sets the clock to AM when using
the 12-hour format, and turns stations on with the smart switch.
Deactivates watering days and/or pump stations. Sets the clock to PM when
using the 12-hour format, and turns stations off with the smart switch.
Exits the current menu or data entry position without saving entries.
From the Startup screen, this button activates the Main menu for programming
the controller. From the Main menu, this button saves the current information in
the highlighted menu option.
Moves the cursor in the direction indicated. The right and left arrows are also
used to scroll through predefined options when setting up sensors, watering
schedules or changing languages.
Data entry keypad buttons.
DOCGOMQS550 (Rev B)
