Signature Control Systems, Inc. GALAXY Quick Start Manual page 10

™
GALAXY Field Control Systems
Quick Start Guide - v5.50
Procedure
1. From the Startup screen press Enter.
Then select option 1) Manual Modes.
Then select option 1) Manual Station.
2. Press ENTER/NEXT button again.
3. At menu option 1) Station, press keys
to enter a three-digit number to identify
the station number; for example, press
keys 001 for Station 1.
4. Press the ON/AM button or press left or
right arrows until ON is the Mode.
5. Press down arrow to option 3) Time,
enter the Water Time for the station in
hours: minutes: second's format. For
example, to enter a Water Time of 10
minutes, press right arrow twice, press
key 1.
6. Press down arrow to option 4) Delay,
enter the Delay Time for the station in
hours: minutes: second's format. For
example, to enter a delay time of 10
seconds, you would press keys
000010.
7. To start the station, press the
ENTER/NEXT button.
The station starts or if you entered a
delay time, the delay countdown
begins.
8. To add another station with the same
Water Time and Delay Time, enter a
station number and press the ON/AM
button; and then press the
ENTER/NEXT button to activate the
station(s).
A Delay time is not required to activate a station.
Page 10 of 16
Keypad
Press keys:
or
Arrow twice and
Press key: 1
Press keys: 000010
Display
1) 1) 1) 1) Station: Station: Station: - - - - -- -- -- -- Station:
2) Mode:
3) Time: 00:00:00
4) Delay: 00:00:00
1) Station: 001
2) 2) 2) 2) Mode: On Mode: On Mode: On Mode: On
3) Time: 00:00:00
4) Delay: 00:00:00
1) Station: 001
2) Mode: ON
3) 3) 3) 3) Time Time: 00:10:00 : 00:10:00
Time Time : 00:10:00 : 00:10:00
4) Delay: 00:10:00
1) Station: 001
2) Mode: ON
3) Time: 00:10:00
4) Delay: 00:00:10 4) Delay: 00:00:10 4) Delay: 00:00:10 4) Delay: 00:00:10
1) 1) 1) 1) Station Station Station: 001 Station : 001 : 001 : 001
2) Mode:
3) Time: 00:10:00
4) Delay: 00:00:10
1) 1) 1) 1) Station Station Station: : : : --- --- --- --- Station
2) Mode:
3) Time: 00:10:00
4) Delay: 00:00:10
DOCGOMQS550 (Rev B)
