Mitsubishi Electric PAC-DRP10DP-E Installation Manual

Air Conditioning For Building Application
Drain Water Lift-Up Kit PAC-DRP10DP-E

Installation Manual

This installation manual contains only the description of how to install the Drain water Lift-Up Kit PAC-DRP10DP-E. For information
about how to wire and how to install air conditioning units, see the installation manual for them.
For your safety, first be sure to read section 1. "Safety Precautions" below thoroughly and then install the Drain water Lift-Up Kit
PAC-DRP10DP-E correctly.

1. Safety precautions

• The following two symbols are used to denote dangers that may be caused by incorrect use and their degree:
WARNING
This symbol denotes what could lead to serious injury or death if you misuse the PAC-DRP10DP-E.
This symbol denotes what could lead to a personal injury or damage to your property if you misuse the
CAUTION
PAC-DRP10DP-E.
• After reading this installation manual, keep it in a place where the final user can see it anytime he or she wants to it.
When someone moves, repairs, or uses the PAC-DRP10DP-E, make sure that this manual is forwarded to the final user.
WARNING
Always have the unit installed by Authorized Mitsubishi
Representative or similar professional.
Improper installation by the user could result in problems such as
water leakage, electric shock or fire.
Always use the designated cables and connect them properly.
When connecting the terminals, make sure that external forces
from the cable is not being conveyed to the terminal and then
tighten it securely.
Improper or loose connections could cause excessive heat or fire.
Only use Mitsubishi-approved accessories, such as an air
cleaner, humidifier or electric heater.
Always have such accessories installed by an Authorized Mitsubishi
Representative or similar professional. Improper installation by the
user may result in water leakage, electric shock or fire.
CAUTION
PRECAUTIONS BEFORE INSTALLATION
Never use for special applications such as storing food, plants,
precision equipment or art.
The quality of these items may deteriorate.
Never use the unit in special environments.
Special environments with high concentrations of oil, steam or sulfuric
gases will reduce the performance of the air condition and cause its
parts to deteriorate.
Never install the unit where run-off could result in damage.
If the humidity in the room exceeds 80% or if the drain becomes
clogged, water may drain off of the indoor unit. When the unit is used
for heating, there may be drainage from the outdoor unit. If required,
provide collector drain for the outdoor unit.
Install the unit according to this Installation Manual.
If the unit is installed improperly, water leakage, electric shock or fire
may result.
Have all electric work performed by a properly licensed
electrician. Electric work should be performed in strict adherence
to procedures to this Installation Manual. Always provide a
dedicated power supply.
If the capacity of the power supply is inadequate, it could result in
problems such as electric shock or fire.
Never modify the unit and always have repairs performed by an
Authorized Mitsubishi Representative.
Improper repair could result in problems such as water leakage,
electric shock or fire.
Always provide adequate signal noise protection when installing
in facilities such as hospitals and communication stations.
Equipment at these facilities, such as inverters, in-house generators,
high-frequency medical equipment, two-way communication
equipment, may cause the air conditioner to operate improperly.
Conversely, the signal noise from the air conditioner may affect
the operation of medical equipment and two-way communication
equipment and this could interfere with the medical treatment being
given a patient or cause disturbances or interference in video
broadcasting equipment.
