Amulet Hotkey DXZC Quick Start Manuals

DXZC and DXZC-M
PCoIP zero client

Quick Start Guide

The DXZC is a PC-over-IP® (PCoIP®) zero client used to connect to physical and
virtual workstations, virtual desktops such as VMware Horizon and cloud managed
desktops such as Amazon Workspaces.
The DXZC, based on the Tera2 chipset, supports two heads of video at the desktop.
The DXZC has four USB 2.0 ports.
The DXZC is available in two versions. The standard DXZC has an RJ45 network
port. The DXZC-M has a network port that accepts a copper or fiber SFP module
(available separately). Each is supplied with a PSU and power cable.
Note: This guide uses 'DXZC' as a generic term when referring to both the
standard DXZC product and the DXZC-M product.
Before you start
You must first configure a remote computer and PCoIP host, ready for connection
to the DXZC. The remote computer must be powered and connected to the
appropriate network. You will need the IP address of the PCoIP host.
STEP 1: Connect the Keyboard, Mouse and optional Headset
1. Connect a keyboard and mouse either to the front panel USB ports or to the
USB port at the rear.
2. Connect audio devices, if used.
STEP 2: Connect the Monitor, Network cable, Peripherals and Power
1. Connect at least one compatible monitor to the DXZC, starting at the
Video 1 port.
2. (DXZC-M only) connect the SFP module to the Network Port.
www.amulethotkey.com
Zero Client
3. Connect the network cable.
4. Connect the DXZC PSU.
Use only the PSU supplied with this DXZC!
AMULET
HOTKEY
DXZC Zero Client
DXZC Quick Start Guide v1.0 September 2018
QS-DXZC-0001
®
