SKF Shaft Alignment Tool
TKSA 11
Quick Start Guide

1. Description

7
1. Measuring unit
2. Power button
3. Connection blue LED
4. Status red/green LED
8
5
5. Two inductive proximity sensors
6. V-Bracket with locking chain
7. Magnetic bar holder
8. Reference bar
1
3
4
6
2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TKSA 11 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SKF TKSA 11

Summary of Contents for SKF TKSA 11

  • Page 1 SKF Shaft Alignment Tool TKSA 11 Quick Start Guide 1. Description 1. Measuring unit 5. Two inductive proximity sensors 2. Power button 6. V-Bracket with locking chain 3. Connection blue LED 7. Magnetic bar holder 4. Status red/green LED 8. Reference bar...
  • Page 2 2. Compatible display devices • SKF TKSA DISPLAY2, Samsung Galaxy Tab Active 2 and iPad Mini recommended • iPad, iPod Touch, iPhone SE, Galaxy S6 or above (all not included) 3. Installing the app Note: Alignment apps are pre-installed and ready to use on the SKF TKSA DISPLAY2 device.
  • Page 3 Help section of the apps and SKF.com/Alignment b. Technical support SKF Technical Support website link is available in the help section the apps. Please visit www.skf.com/cm/tsg to find help or file a support request. Videos Short instructional videos are available in the help section of the apps.
  • Page 4 Adjust the gap between the inductive proximity sensors and the reference bar to app. 3 mm ±0,5 mm (120 mils ±20 mils). “Sensor status” in the app indicates the correct distance. The TKSA 11 can be mounted directly on couplings when needed.
  • Page 5 Safety recommendations • The complete instructions for use are available on SKF.com and within the SKF TKSA 11 app. • Read and follow all warnings in this document before handling and operating the equipment. You can be seriously injured, equipment and data can be damaged if you do not follow the safety warnings.

  • Page 6: Eu Declaration Of Conformity

    Sébastien David Manager Product Development and Quality SKF Maintenance Products ® SKF is a registered trademark of the SKF Group. © SKF Group 2018/08 www.mapro.skf.com • www.skf.com/mount • MP5432EN The contents of this publication are the copyright of the publisher and may not be reproduced (even extracts) unless prior written permission is granted.
