SKF TKSA 41 Quick Start Manual

Shaft alignment tool

Hide thumbs Also See for TKSA 41:

Need help?

Do you have a question about the TKSA 41 and is the answer not in the manual?

Page 1 SKF Shaft Alignment Tool TKSA 31 & TKSA 41 Quick Start Guide...
Page 2 10. 2 ™ Micro USB to USB cables* 11. Printed Quick Start Guide (EN)* 12. Printed certiicate of Calibration and conformance* 13. 1 ™ Page of QR code stickers (TKSA 41 only)* * not shown 2. Mount the Measuring Units (MU) •...
Page 3: Enter Dimensions
• Click on the left arrow to go back • Click on the next arrow to go to the next step • Imperial Units can be selected in the Settings before starting the alignment SKF TKSA 31 & TKSA 41...
Page 4: Take A Measurement
6. Turn the shafts to the blue wedge at the 3 o’clock position (+90°) Click on the “next” arrow to take a measurement 8. Results Horizontal correction Symbol Go to corrections Take measurements Finish and create again report Change tolerance SKF TKSA 31 & TKSA 41...
Page 5 Down arrow means the motor has to go to the left • Tighten the bolts when the correction is complete • It is recommended to remeasure the alignment after correction 11. Create a report Report name is mandatory SKF TKSA 31 & TKSA 41...
Page 6: 12. Declaration Of Conformity
The laser complies with 21 CFR 1040.10 and 1040.11 except for deviations pursuant to Laser Notice No. 50, dated June 24, 2007. TKSA 41 only: The enclosed device complies with Part 15 of the FCC Rules. 47CFR: 2011 Part 15 Sub Part B Unintentional Radiators Contains FCC ID: 0C3BM1871, QDID: B020997.

Tksa 31
