Clarity ALTOPLUS Quick Start Manual

Basic Installation

Step 1: Install the backup batteries (optional) by removing the battery cover as shown in
Figure 1.
Step 2: Pull the ends of the phone cord to untable the cord; connect the loose end of the
phone cord into your wall telephone outlet
Step 3: Place handset in cradle
Step 4: Pull the ends of the power cord apart to untangle the cord; plug the adapter into
your wall's electrical outlet
IMPORTANT: Use only with Class (Classe) 2 power source, provided with your
product
Step 5:
for use If not, check all connections again
Figure 1
four AA alkaline backup batteries (not included)
The phone operates as a regular phone if there is no power or backup batteries In this case, the
We recommend installing batteries if you live in an area with frequent power outages
ALTOPLUS QUICK START GUIDE
If you hear a dial tone, your telephone is ready
Figure 2
