INSTALLATION INSTRUCTIONS
COOLDRAWER™ MULTI-TEMPERATURE DRAWER
RB36S & RB90S models
Important!
SAVE THESE INSTRUCTIONS
The models shown in this document may not be available in all markets and are subject to change at any time. For current details about model and specification availability in your country, please go to our website
fisherpaykel.com or contact your local Fisher & Paykel dealer.
1

SAFETY AND WARNINGS

Electrical shock hazard
Disconnect product from main power supply before installing appliance.
Failure to do so may result in electrical shock or death
Cut hazard
Take care - panel edges are sharp.
Failure to use caution could result in injury or cuts.
Tipping hazard
Do not operate this apppliance until it has been securely anchored inside the
cabinetry. The cabinet must be securely anchored to the floor.
Failure to use caution could result in injury or cuts.
Important safety precautions!
Installation of the CoolDrawer™ requires competent mechanical and electrical skills.
Be sure to leave these Instructions with the Customer.
Installation must comply with your local building and electricity regulations.
At the completion of the CoolDrawer™ installation, the Installer must perform the Final Checklist.
Remove all packaging materials supplied with the CoolDrawer™.
The CoolDrawer™ is manufactured for indoor use only.
WARNING!
WARNING!
WARNING!
The CoolDrawer™ MUST be installed to allow for future removal from the enclosure if service is required.
Do not seal the CoolDrawer™ into the cabinetry with silicone or glue. Doing so will make future servicing
difficult. Fisher & Paykel will not be liable for any costs associated with removing or replacing a sealed-in
product, nor for repairing any damage that may be incurred by doing this.
Care should be taken when the appliance is installed or removed to reduce the likelihood of damage to the
power supply cord.
Failure to install the CoolDrawer™ correctly will invalidate any warranty or liability claims.
If the power supply cord is damaged, it must be replaced. Parts are available from your Authorised
Fisher & Paykel dealer.
This appliance is not intended for use by persons (including children) with reduced physical, sensory or
mental capacities, or lack of experience and knowledge unless they are supervised or given instruction
concerning use of the appliance.
Cabinetry must be sufficiently robust to support a combined product and food load of 220 lb (100 kg).
Bearers may be required to support the internal shelf.
Before you install the CoolDrawer™, please ensure that
The switched power outlet must be outside the refrigerator drawer cavity so that it is accessible after
installation.
The switched power outlet must be located outside the cavity, within 55" (1400 mm) from the
CoolDrawer™ cavity if situated on the left-hand side of the cavity and within 33 1/2" (850 mm) if situated on
the right-hand side of the cavity.
The services hole in the refrigerator cavity needs to be large enough for the power supply plug to fit
through.
FRAMELESS CABINETRY
