TRANSIT-USA
INSTALLATION GUIDE
(For Extended and PS-270 versions)
September 19, 2002
Part no : 9875220
This information is furnished for guidance, and with no guarantee as to its accuracy or completeness; its publication conveys no license
under any patent or other right, nor does the publisher assume liability for any consequence of its use; specifications and availability of
goods mentioned in it are subject to change without notice; it is not to be reproduced in any way, in whole or in part, without the written
consent of the publisher.
