2.2.2. Connecting RS232 via a Velos Panel reader cable..........4 2.3. Connecting to a Velos VPU via CAN communication............5 2.3.1. Connecting one VP1103 Panel reader ..............5 2.3.2. Connecting several VP1103 Panel readers to a Velos VPU ........6 Starting up operation......................7 3.1. Turn on the power.........................7 3.2.
1.1. Description The VP1103 Panel reader system consists of a Panel reader unit that is connected to a VPU using CAN communication or a connection to a PC or a weight scale through RS232. 1. Panel reader unit VP1103 2.
1.2. Functioning The VP1103 Panel reader creates a magnetic field around the antenna that is used to identify the tags on ISO frequency 134.2 kHz. The Panel reader is connected to a VPU using CAN communication or to a PC or a weight scale through RS232.
Drill zone at least 4 cm from the sides Figure 3. Mounting positions on rear view VP1103 Panel reader Mount the Panel reader in 4 positions with screws, bolts, and plugs etc. suitable to support the Panel reader. Use a large washer behind the bolt/screw to give extra support. Use a screw or washer with a minimum head diameter of 18 mm.
2.2.1. Connecting RS232 via a Sub-D connector Connect a PC or a weight scale to the VP1103 Panel reader RS232 Sub-D connection from the connector. Use an extension cable (art. nr 7707037) of 4 meters to extend the cable if necessary.
2.3. Connecting to a Velos VPU via CAN communication 2.3.1. Connecting one VP1103 Panel reader Connect the Panel reader cable (art.nr.7707029) to the VPU connectors. VP8001 Power supply (VP2001) VP1103 Orange / White Orange /White Orange Orange Shield Shield Blue / White...
2.3.2. Connecting several VP1103 Panel readers to a Velos VPU Connect the Panel readers VP1103 to the Velos connection boxes. Power supply VP8001 (VP2001) Max = 2x4A Max 80m From VPU to last VP1103 Velos cable part no. 7705310 Velos cable...
3.2.2. Checking the RS232 connection to a PC Check the operation of the VP1103 Panel reader that is connected to a PC with the Hyper Terminal program. Set the baud rate of the Hyper Terminal communication program to 9600. The other settings are default.
4.2. Malfunction If the Panel reader VP1103 is connected to a VPU, view the actual state of the Panel reader in the webpage Maintenance > V-packs – Overview. A reduced antenna performance may be caused by a strong electrical background noise. Install cables and power supply / transformers >...
6.2 kg Electrical supply Main supply 100V - 240V Frequency 50 – 60 Hz Input voltage (always use Nedap power supply) 12 - 27 V DC Input current (mA) depends on input voltage 0.75 – 0.5 A Environmental Operating temperatures - 10°C / + 50°C...
The identification distance of the antenna field The identification distance of the antenna varies per installation. It depends on the iron and the background noise in the ISO- reader area. VP1103-200PM-00GB-Panel reader Manual version 1.1 / Page 10...
