ASSEMBLY

It's your choice to install either the landing gear or the fl oats.
Start the assembly after making this decision.

Mount the Landing Gear

❑
1. Use a #2 Phillips screwdriver to fasten both main landing
gears to the fuselage with three M3x16 screws in each side.
❑
2. Mount the tail gear with two M2.5x8 screws, then fasten
the pushrod wires as shown. Make sure the tail wheel is
perpendicular with the steering arm and tighten the screws.

Mount the Floats

❑
1. Connect the fl oats to each other with the horizontal
struts and four M2.5x20 machine-thread screws.
