Center The Control Surfaces - Flyzone DHC-2T Turbo Beaver Instruction Manual

Center the Control Surfaces

Down
❑
1. Turn on the transmitter, lower the throttle stick all the
way to 0%, and center the trims.
❑
2. Connect the battery to the ESC. The motor will emit a
series of tones indicating the cell count of the battery and
a rising series of tones indicating the ESC is now armed.
WARNING: Make sure this propeller is not installed
for this next step.
A magnetic screwdriver, or a small magnet stuck to a
screw driver to make it magnetic, will be helpful for the
next couple of steps.
ON
Centered
❑
3. Remove the screw from the connector on the elevator
servo arm.
❑
4. Lightly wet the threads of the screw with threadlocker.
❑
5. Reinstall the screw, but do not tighten yet. With the
transmitter and receiver on, center the elevator and tighten
the screw to lock the pushrod down.
15
