Q-Logic 2 Quick Guide
1. LCD Screen
2. Drive/Function Inhibit
3. On/Off Mode Select Lever
4. Joystick
5. Mono Jacks
6. Key 1 Select Button
7. Menu Button
8. Horn Button
9. Key 2 Select Button
10. Speed Adjustment
11. Charger Port
12. Light Button
13. Left Turn Indicator Button
14. Right Turn Indicator Button
15. Battery Condition Meter
December 2015. This information is correct at the time of printing.
From time to time, product specifications are changed by manufacturers without prior notice.
Advertisement
Table of Contents
Related Manuals for ALLIED MEDICAL Q-Logic 2
Summary of Contents for ALLIED MEDICAL Q-Logic 2
- Page 1 Q-Logic 2 Quick Guide 1. LCD Screen 2. Drive/Function Inhibit 3. On/Off Mode Select Lever 4. Joystick 5. Mono Jacks 6. Key 1 Select Button 7. Menu Button 8. Horn Button 9. Key 2 Select Button 10. Speed Adjustment 11. Charger Port 12.
- Page 2 Q-Logic Quick Guide Ensure you turn off the chair for transfers. Freewheel your chair by disengaging both motors. Never disengage your motors when on a slope! Locked and in drive mode Place unit on level ground and stand to one side when changing between modes.
