Courtyard Creations KTS127W-WM Assembly Instructions

ASSEMBLY INSTRUCTIONS
ATTENTION: THIS PRODUCT IS NOT FOR COMMERCIAL USE

PARTS LIST

PART
MATERIAL CODE
NO.
1
KTS127W-CS01
2
KTS127W-CS02
3
KTS127W-CS03
4
KTS127W-CS04
5
17C33A0706001Y4
6
17C02A0755131Y4
7
17C01A0716072Y4
8
17FA05040301-Y4
Attention:
Make sure that each bolt needed for all steps matches the
corresponding figure to ensure proper assembly.
Step 1:
Place the right leg (#3) onto a non-abrasive surface, such as
a carpet. At the front of the lounge chair, fasten the seat
assembly (#1) to the legs (#2 and #3) by using bolts (#5) and
washers (#8). Keep the bolts loose. See Figure 1.
Note:
The labels marked "L" and "R" on the legs (#2 and #3) should
coincide with Figure 1 to ensure proper assembly.
Use the correct bolts as indicated. Do not tighten any of the bolts until is completely assembled.
!
Do not discard of any of the packaging until you have checked that you have all of the parts and fittings required.
!
Keep children away during assembly. This item contains small parts that can be swallowed by children.
!
Children should always be under direct adult supervision while using this product.
Retain these assembly instructions for future reference.
!
Quote the following FQC NO. when contacting the service center.
!
INTENDED FOR RESIDENTIAL USE ONLY.
KTS127W
PART Q'TY
SEAT ASSEMBLY
LEFT LEG
RIGHT LEG
BACK ASSEMBLY
BOLT M6*16
BOLT M6*14
BOLT M6*45
WASHER d6.5*D13*1.0
SERVICE CENTER TOLL FREE NO.
TEL: 1-877-539-7436
FAX: 1-877-539-7439
DON'T RETURN TO STORE!
STOP
PAGE 1 OF 2
-WM
PART
MATERIAL CODE
NO.
1
9
18060603030201
1 10
18000C23001
1 11
18000337004
12
1
18000337006
6
13
18000337002
2 14
17KAA0101----Y4
2 15
17KAA0201----Y4
10 16
17KAB1101----Y4
FIGURE 1
PART
PLASTIC WASHER
PLASTIC NUT M6*P1.0
BOLT CAP
BOLT CAP M6
BOLT CAP M6
KEX.KEY WRENCH 4MM
KEX.KEY WRENCH 6MM
NUT WRENCH 10&13MM
1
11
5
8
16
#5 BOLT M6*16
COURTYARD CREATIONS INC.
Q'TY
2
2
6
2
2
1
1
1
2
L
3
R
