Escort SmartRadar Quick Reference

Installation
Connecting the Power Direct-Wire Power Connection
WARNING: Attempting to install SmartRadar
without expertise in automotive electronic
installations can cause personal injury
or damage to your device or your vehicle.
Consult a professional if you have no
experience with 12-volt installations.
Rearview Mirror Power Connection
1 Plug the modular connector end of the power
cord into the receiver unit's power (12 VDC)
Fuse
jack.
Black Ground Wire Fuse
Red 12V Switched Wire
2 Attach the lug on the cord's black wire to any
grounded screw under your vehicle's
1 Plug the modular connector end of the power dashboard.
cord into the receiver unit's power (12 VDC)
jack. 3 Position the blue 3M connector around an
existing switched (powers on and off with the
2 Unplug the wiring harness from the back of ignition) wire.
your powered rearview mirror. NOTE: The connector can ONLY be used with
wire gauges 14–18.
3 Slide the lead from the cord's black wire into
the ground slot. 4 Squeeze the connector with pliers until the
halves snap together.
4 Slide the lead from the cord's red wire into
the +12V switched (powers on and off with
the ignition) slot.
5 Ensure the wires have a snug and secure
connection.
5 Plug the insulated male spade lug on the red
6 Use the mounting tape and zip ties to secure striped wire into the 3M connector, ensuring
any loose/dangling wires. the insulator completely covers the connector.
7 Place the wiring harness back into the slot on 6 Use the mounting tape and zip ties to secure
the rearview mirror. any loose/dangling wires.
6
Registration Downloading ESCORT Live!
Before downloading ESCORT Live, you must first 1 Enter the iTunes App Store on your iPhone
register your SmartRadar device. Be sure to have and search for ESCORT Live!
your receiver unit nearby, as you will need the
serial number, found on the bottom of the unit.
1 Visit www.escortinc.com and click Product
Registration.
2 Click the link for SmartCord Live/SmartRadar.
2 Follow the onscreen instructions to
3 Follow the onscreen instructions to register download.
your device.
3 When prompted, enter the username and
Be sure to write down the username and password you created when registering your
password you create, as you will need this SmartRadar device.
information to access and download ESCORT
Live. (You will also receive an e-mail with this
information, once you have registered your
device.)
7
Pairing with your iPhone Contact Us
To pair your iPhone with SmartRadar:
Premium
1 Ensure SmartRadar power is ON.
automotive Accessories
2 On your iPhone, enter the Settings menu.
800.433.3487
3 Tap General, then Bluetooth.
EscortInc.com
4 Ensure Bluetooth is ON.
5 SmartRadar should appear under devices.
Made for
iPhone 4S, iPhone 4, iPhone 3GS
iPhone is a trademark of Apple Inc., registered in the U.S. and other
countries.
"Made for iPhone" means that an electronic accessory has been designed
to connect specifically to iPhone and has been certified by the developer
to meet Apple performance standards. Apple is not responsible for the
operation of this device or its compliance with safety and regulatory
standards. Please note that the use of this accessory with iPhone may
affect wireless performance.
FCC ID: QKLESR. Contains FCC ID: QKLBT1.
6 Tap SmartRadar to pair the device to your
Designed in the USA
iPhone.
ESCORT Inc.
7 The Power/Bluetooth indicator on your 5440 West Chester Road
receiver will turn blue to confirm the
West Chester OH 45069
connection.
Sales/Service 800.433.3487
www.EscortInc.com
8 Open the app, walk through the tutorial, and
you're ready to hit the road!
©2012 ESCORT Inc. Escort®, Escort Live!™, SmartRadar™, Defender®, AFR®,
TrueLock™, Passport®, SmartShield®, SpecDisplay™, AutoSensitivity™,
For Bluetooth pairing tips and more information
SpecDisplay™, ExpertMeter™ and Cincinnati Microwave are trademarks
of ESCORT Inc. Manufactured in Canada. Features, specifications and
on using ESCORT Live! see the enclosed user
prices subject to change without notice.
manual or visit www.EscortInc.com
