IDEAL SK698 Instructions

KIT INCLUDES:

• 1 Smart Alert wireless receiver with alarm/ chime option
WIRELESS SAFETY ALERT • 1 DC Adapter for the wireless receiver
• 2 Wireless motion sensors, factory linked to the receiver
WITH MOTION SENSORS
• 2 field of detection shields for the wireless motion sensors
• 2 9V batteries for the wireless motion sensors
• 2 Wireless remote control units, factory linked to the receiver
• 2 Coin cell batteries for the Wireless remote control units
WITH REMOTES

IMPORTANT TIPS

The receiver unit is not a siren; it is an ALERT, to inform or warn
of some type of incident that a sensor has detected .
The receiver has six zones, each zone has a unique sound,
each associated with a different sensor or contact. The 2 motion
sensors in this bundle will take up 2 of the zones. The 2 remotes
will also take 2 of the zones for panic button functions.
The included sensors and the remotes are factory linked to the
receiver for ease of set up and use.
The 2 remaining zones can be used for 2 other IDEAL
SECURITY sensors or detectors such as SK621 or SK625
DOOR & WINDOW
DETECTOR or additional SK615 MOTION SENSORS.
Additional sensors will have to be linked to the receiver before
use. Please see USING THE "LEARN" FUNCTION
www.idealalert.ca for more information.
1. Do not install the receiver where it will be exposed to direct
sunlight or rain ( for indoor use only)
2. The receiver sounds are very loud, never put the system
close to your ear.
3. The system should be installed away from heat sources such
as radiators, heating ducts and stoves. If the Receiver sounds
randomly, it is possible that it is too close to a heat source.
INSTRUCTIONS
Changing the location or direction of the receiver or sensors
may correct the problem.
NOTE: This kit can provide additional protection for your home
and property if utilized properly. However, its use cannot
guarantee complete protection against burglary or robbery. Ideal
www.idealinc.com SK698
Security cannot assume any responsibility for any loss or
damages as a result of installing this kit.
e-mail: info@idealinc.com • Tel.: 800-361-2236

WIRELESS RECEIVER

Description of Components

1. Sound ON/OFF switch
2. DC jack port
1 SOUND
ON
OFF
3. Power ON/OFF switch
4. Sensor battery low
indicator/trigger indication LED
5. "READY" indication LED
6. Receiver battery low
2
indicator/trigger indication LED
POWER 3
ON
8
7. Speaker OFF
8. "Learn ID code" button
(for LINKING to sensors) 9
9. Receiver battery cover

Features

• Up to 6 "IDEAL" wireless sensors can be linked to the receiver
(including remote controls)
• Receives signals from sensors and sounds alerts.
• Six different alert tones, indicate which sensor was triggered
The alert sounds are:
1. Bi-Bi 2. Di-Di-Di 3. Ding-Dong
4. Di Du 5. WuWu 6. DiDiDiDuDuDu
CONTACTS, or SK616 WATER
• Wireless RF transmission distance between sensors and
receiver of up to 50 meters (160 feet).
• A/C adapter included. (3 C batteries, not included may be used
or visit
as a power failure backup or to make unit portable)
• Battery low LED indicators on receiver for both the receiver and
linked sensors: When the receiver battery is low or no batteries
are installed the right LED will flash once every 4 seconds.
When the receiver detects a sensor battery is low the left LED
will flash once every 3 seconds (The battery low indicator LED
on the affected sensor will blink once every second)

Installation

1. Plug included DC adapter into the wall and to the DC jack on
the receiver unit. Receiver must be within 50 meters (160 feet)
of linked sensors
2. You can install 3 C batteries (not included) as a backup in case
of power failure or to make the unit fully portable. Remove the
screw from back of the receiver cover and slide open the
battery cover door. (Fig.1)

Operation With Included Motion Sensors

4 5 6 1. The included Motion Sensors are factory linked to trigger alert
Description of Components
sounds 1. (Bi-Bi) and 2. (Di-Di-Di)
1. Mounting bracket
7
2. Place the receiver within 50 meters (160 feet) of all sensors
2. Motion sensor window
3. Turn the power and sound switches to ON, the receiver will
3. Battery low LED
beep and the two outer LED lights will flash once indicating
4. Battery compartment
that the unit is in ready mode. The middle LED light will start
to flash indicating unit is on and ready to receive signals.
When a sensor is triggered it will send a wireless signal to the
receiver. The two outer LED lights on the receiver will flash
1. Remove the screws from the
and you will hear an alert for 10 seconds. As long as motion is
battery compartment cover.
detected the outer lights will continue to flash and the alert will
2. Install 9V battery.
LEARN
continue to sound with short pauses between alerts. When
3. Replace the battery cover
motion is no longer detected the receiver will return to ready
and screws. (Fig. 2)
mode.
4. Sound ON/OFF switch: In the ON position, when a sensor is
ATTENTION: DO NOT DRILL ANY HOLES BEFORE
triggered and the receiver is in the ON position the alert will

TESTING THE CONNECTION TO THE RECEIVER

sound and the two outer LED lights will flash. With the sound
in the OFF position when a sensor is triggered no alert will 4. Choose a suitable location, 1.5 - 2.0 meters (5 - 6 feet) above
floor level. Test the sensor transmitting range before mounting
sound, only the two outer LED lights will flash.
it permanently. Make sure the receiver is ON, then wave your
5. Using the receiver with a REMOTE CONTROL / PANIC
hand in front of the sensor lens, the receiver will sound for 10
BUTTON: With the POWER and SOUND switches in the ON
seconds and the LED's will flash. If no signal is received a
position you may arm or disarm the receiver with a remote
change of location is required. Test the sensor detection area:
control. The panic button will work either in arm or disarm
the alert will sound until you walk beyond the sensor detection
mode. When pressed It will cause the receiver to sound for
area. Adjust the sensor direction, or the installation location to
one 10 second cycle. (see "REMOTE CONTROL" section for
get the desired detection area.
more detail)
The Motion sensor range is up to 8 meters (26 feet)
6. To REMOVE a sensor
with up to 110° angle of detection. (FIG. 4)
If you want to unlink a sensor (remove it), all the learned
5. Mount the motion sensor: Use the swivel wall mount bracket
sensor codes must be deleted from the receiver. To do this
to mark the mounting location, drill holes and install anchors
press and hold the LEARN button at the back of the receiver
and attach the bracket with the provided screws. Slide the
for 12 seconds. (Fig. 7 ) You will hear two long beeps
main unit onto the bracket until it clicks into place (fig 3).
confirming that all codes have been deleted. The receiver will
Adjust the bracket to obtain the best coverage of the intended
not respond to signals from any sensors. You must now relink
protected area.(Fig 4)
all the sensors to the receiver (see "USING THE "LEARN"
NOTE: The angle of detection can be reduced by using
FUNCTION for more details).
the detection shield supplied. (Fig 5)
(Fig. 1)
1.5~2m
(5'~6')

WIRELESS MOTION DETECTOR

REMOTE CONTROL

Description of Components
1
1. Panic button
2
2
2. Disarm Button
3
3 3. Arm button
4
1
4. Battery compartment
Installation Instructions
1. Remove the battery compartment
cover by lifting it in the direction of
the arrow.
2. Install batteries. Make sure the
polarity (+ or -) of the batteries
(Fig. 2)
match the polarity marks inside
the unit. (Fig. 6)
3. Replace battery cover.
4. To use the remote control functions the power switch on the
receiver unit must be in the ON position.
5. To arm the system press and hold the"ARM" (lock) button for
1 second, the receiver unit will sound a beep and the two
outer LED's will flash once to confirm it is now armed. The
center LED will flash at 4 second intervals
6. To disarm the system press and hold the"DISARM" (unlock)
button for 1 second. The receiver unit will sound 2 beeps and
the the two outer LED's will flash twice to confirm it is now
disarmed. The center LED will stop flashing. When disarmed
the receiver unit will not respond to sensor signals.
7. If you press and hold the "PANIC" (siren) button for 1 second
the portable receiver unit will sound for 10 seconds with the
alert sound associated to that remote. The panic button will
work even if the the system is disarmed (the receiver must be
ON & the SOUND switch must be ON).
NOTE: The normal operating range of the remote control unit is
up to 20 meters (65 feet). When the batteries in the remote
control become weak the range will shorten. When this
happens replace the batteries.

USING THE DETECTION SHIELD

USING THE "LEARN" FUNCTION
(Fig. 3)
110°
NOTE: Place black side
of shield inwards
5~8m (16~26')
(Fig. 4) (Fig. 5 ) towards the lens
USING THE "LEARN" FUNCTION
LINK ADDITIONAL WIRELESS SENSORS OR REMOTE
CONTROLS TO THE RECEIVER.
You may link 2 additional Ideal sensors to the receiver using the
"LEARN" function. A total of 6 sensors can be linked to this unit.
Each additional sensor or remote must be linked to the receiver
individually using the following steps:
4
1. Set the power switch to ON and the sound switch to ON,
2. Press and release the "LEARN" button (Fig. 7) on the back of
the receiver you will hear one of the alert sounds listed below.
Continuing to press and release the "LEARN" button will cycle
through the sounds that are not linked to another sensor.
3. Press and hold the learn button again for a single confirming
beep. You are now ready to send a signal from a sensor.
(Fig. 6)
4. Trigger the sensor. If you hear a long beep then the sensor is
successfully linked to the receiver. If you hear 4 short beeps
linking was unsuccessful, please try (re-learn) again.
Each additional sensor (up to 6) is linked the same way. Each
time you link a sensor the sound associated with that sensor will
become unavailable until all six alert sounds have been used.
Listed below are the six different sounds in order.
ALERT SOUNDS:
1. Bi-Bi 2. Di-Di-Di 3. Ding-Dong
4. Di Du 5. WuWu 6. DiDiDiDuDuDu
NOTE: Alerts will sound for 10 seconds per cycle with the
exception of the "Ding-Dong" alert which sounds only once
per cycle.
TIP: How to trigger sensors or remote controls that you are
trying to link with a receiver:
• Wireless motion detector SK615, by moving hand in front of
sensor will trigger and send signal. (please see tip below)
• Wireless door/window sensor SK621 & SK625, separating the
magnetic contacts will trigger and send signal.
• Wireless water alarm sensor SK616, put sensor in water will
trigger and send signal.
• Wireless temperature sensor SK627, pressing the test button
will trigger and send signal.
• Remote control SK629, pressing any key will trigger and send
signal.
LEARN
BUTTON
TIP: if you have learned a motion detector to your receiver,
cover the motion sensor before learning other items as the
motion sensor will send a signal to the receiver every time
you move.
(Fig. 7 )
