TECHNICAL SPECIFICATIONS
Inputs: ............................... Mic 6.3 mm jack
Outputs: ............................ Master 6.3 mm jack (balanced)
.................................
.................................
Interfaces: ......................... USB for audio, video and touch transmission
Power supply unit: .............. 12V/3A
Dimensions: ....................... 594 x 377 x 43 mm
Weight: .............................. 3,7 kg
MEASUREMENT ITEM
OUTPUT LEVEL
S/N NOISE LEVEL
THD + N
58
Master RCA (unbalanced)
Headphones 6.3/3.5 mm jack
MEASUREMENT SIGNAL MICROPHONE VR
MASTER OUT(RCA)
MIN
MASTER OUT(TRS)
HEADPHONE MIN
MIC (RCA) MAX
MASTER OUT(RCA)
MIN
MASTER OUT(TRS)
HEADPHONE MIN
MASTER OUT(RCA)
MIN
MASTER OUT(TRS)
HEADPHONE MIN
SPECIFICATION REMARKS
- 0dB
2.0 ± 0.2 V
- 1kHz Sine Wave from PC
2.0 ± 0.2 V
- No Microphone lnput
- 0dB
- 1kHz
1.2V ± 0.2V - No audio from PCC
- No Microphone lnput
- Headphone (load32Ω)
- No audio from PC
1.0V ± 0.2V - + 3mV Vrms Microphone lnput
- 50-ohm UNbalanced AP audio generator output
- 0dB
Less than -80dBr
- 1kHz Sine Wave from PC
Less than -80dBr
- No Microphone lnput
- 0dB
Less than -80dBr - 1kHz Sine Wave from PC
- No Microphone lnput
- 0dB
Less than 0.05%
- 1kHz Sine Wave from PC
Less than 0.05%
- No Microphone lnput
- 0dB
Less than 0.05% - 1kHz Sine Wave from PC
- No Microphone lnput
