According to EN1176, this bench is not considered as being a
play equipment. Therefore, a TÜV-certificate is not required.
Description
The hexagonal bench consists of 6 benches, which are to be fixed together
in a hexagonal shape. Every bench consists of a beige coloured seat and 2
brown legs. The seat is made of a plank 4 x 15 x 90 cm, cut at both ends at
30°. At both ends, a leg of 4 x 12 x 20 cm is being fixed by means of
stainless steel screws. Both plank and legs have rounded edges (radius 5
mm).
Govaerts Recycling NV | Kolmenstraat 1324 | B-3570 Alken | info@govaplast.com | www.govaplast.com
34 kg
100 % recycled material
180
User manual GP10
„Bench Mini hexagonal"
(version 2015-01)
Latest version can always be found at www.govaplay.com
Material
Solid boards made from recycled plastic (PE), coloured
Ÿ
throughout (brown and beige),
Stainless steel screws (6 mm)
Ÿ
Installation
The Bench Mini Hexagonal consists of 6 benches, pre-
assembled, to be fixed using stainless steel screws (type Torx).
Anchorage is possible but not requested.
1
Advertisement
Related Manuals for Govaplast Play Bench Mini hexagonal
Summary of Contents for Govaplast Play Bench Mini hexagonal
- Page 1 (brown and beige), Stainless steel screws (6 mm) Ÿ Installation The Bench Mini Hexagonal consists of 6 benches, pre- assembled, to be fixed using stainless steel screws (type Torx). Anchorage is possible but not requested. Description The hexagonal bench consists of 6 benches, which are to be fixed together in a hexagonal shape.
- Page 2 Anchorage (option) Anchorage is not requested when supervision is guaranteed. Anchorage is done by fixing the bench legs to the ground by means of brackets and nail plugs. Before screwing, pre-drilling with wood drill bite of 4 mm is recommended. The holes for the nail plugs are to be drilled with a stone drill bit of 8 mm.
