- Page 1 Last update 04/27/2018...
-
Page 2: How To Use
Implementation of the Preventative Maintenance Procedure How to use Pre-Visit Common Common Maintenance Serviced Process Process Process History Check (Before) (After) This document was developed by Canon USA Engineering Services and Solutions to perform consistent, effective and efficient maintenance on all Canon products. - Page 3 iR ADV C255iF/ C355iF Advanced Maintenance Guide Procedure Detail Note Time • Enter the machine Serial Number to check the Log into Snapshot : following: Firmware Version – Prepare Firmware if necessary Communications Counters – Machine Usage Event History – Check History for Errors, Alarms Action Prior to and Jams...
- Page 4 iR ADV C255iF/ C355iF Advanced Maintenance Guide Procedure Detail Note Time Point: Ask the customer about the condition of the machine and validate any issues they have. To perform efficient maintenance, we need to Verify Customers’ ask the customer about the machine condition. Ask Questions to find out if there are any following Check Concern...
- Page 5 iR ADV C255iF/ C355iF Advanced Maintenance Guide Procedure Detail Note Time Point: 1. Check Service Log 1. Check the log to see if there is any reoccurring Visual Check issues. If you see the same issues listed on the log, then the root cause hasn’t been fixed.
- Page 6 iR ADV C255iF/ C355iF Advanced Maintenance Guide Procedure Detail Note Time Visual Check Point: 1. Check the Drum counter. COPIER>COUNTER>LF Replace the drums by referring to the value Check the Drum counter below to eliminate drum over life related issues.
- Page 7 iR ADV C255iF/ C355iF Advanced Maintenance Guide Procedure Detail Note Time Make the following Copy/Print samples from ADF and Any issues, resolve them as needed. Copy Glass. 2.CA7 Make Samples (Before Sample) Check Check 3. PG6 4. PG10 Check Perform C10 and C11 at the same time to save time Inspect paper Feed Make copies from all Cassette using at least 5 originals Make copies using the following cassette.
- Page 8 iR ADV C255iF/ C355iF Advanced Maintenance Guide Procedure Detail & Action Note Time Point: 1. Inside cover Clean Clean ADF for Dust Clean the rollers if they were not replaced in step No.5. 1. Separation Pad 2. P/U, Rollers Clean the rollers using lint free paper with water.
- Page 9 iR ADV C255iF/ C355iF Advanced Maintenance Guide Procedure Detail Note Time Clean the rollers if they were not replace in step Clean the rollers using lint free paper with water. No.5. 1. Pick up Roller 2. Feed Roller 3. Separation Roller 1.Check that there is no foreign particles such as paper dust, etc.
- Page 10 iR ADV C255iF/ C355iF Advanced Maintenance Guide Procedure Detail Note Time Point: Check that the Transfer Roller is not worn and Clean Inside of the deformed and has a cut/dirt. machine. Feed Guide / Rib Transfer Guide Static Eliminator Patch sensor Drum ...
- Page 11 iR ADV C255iF/ C355iF Advanced Maintenance Guide Procedure Detail Note Time [M11] Clean the Registration Roller / Pre- Reg Roller Clean Inside of the machine continued [M12] Clean the Secondary Transfer Clean Guide Using the Dustproof Glass Tool located on the door, clean the dustproof glass from the hole of the Waste Toner Container.
-
Page 12: Toner Bottle
iR ADV C255iF/ C355iF Advanced Maintenance Guide Procedure Detail Note Time Empty waste toner container every service call. Visual Check Be sure to keep the waste toner container in a horizontal position when removing the container Empty the Waste to prevent toner spillage onto floor. toner bottle. -
Page 13: Complete Documentation
iR ADV C255iF/ C355iF Advanced Maintenance Guide Procedure Detail Note Time Point: Service Log 1. Let the customer print the test prints from their PC while Fill completing the documentation. 2. Write down the detail actions and all part names and part # in the Fill Out service log for the next visit. - Page 14 iR ADV C255iF/ C355iF Advanced Maintenance Guide Procedure Detail & Action Note Time 1. Check the ADS and make sure the Monitor symbol is indicated. If COM-TEST is NG, fix this issue at Check 2. If the Monitor symbol is indicated, first.
