Locosys GW-60 Quick Start Manual page 8

ACTION SPEED
3.12
RSLT1A~RSLT4B: Speed result selection options
3.13
(Screen 1~4).
These are 4 speed genie windows which scroll once
speed goes above and then under [SPD GENIE] setting.
Each window has two sub-screens: A(top half) and
B(bottom half).
Each window has two possibilities, a split screen
showing two results in small font, or a single display of
one result in big font.
To achieve the big font single display set A and B to the
same category (speed type) for that screen number.
To achieve the split screen set A and B to different
categories for that screen number.
Each screen can assign one or two of the following speed
types:
8
(ACT
SPEED : Current speed (200ms average)
MAX: maximum speed
NSEC: N-second average speed(N=[AVG NSEC])
MSEC: M-second average speed(M=[AVG MSC])
&500: Alpha 500 meter run
100M:100 meter run
250M: 250 meter run
500M: 500 meter run
SPD): Speed display type
Example:
RSLT1A/1B
RSLT2A/2B
RSLT3A/3B
