ECOPURE EPHY Installation And Operation Manual page 25

Key
Part No.
No.
50 7338111 Screw, #6-19 x 3.5 cm (2 req.)
51 7281291 Motor
52 7337474 Motor Mount
53 7284964 Cam & Gear
54 7030713 Switch
Drain Hose Adaptor Kit
– 7331185
(includes Key Nos. 55-59)
55 Clip, Drain
56 Drain Hose Adaptor
57 Hose Clamp
58 O-Ring, 15.9 x 20.6 mm
59 Flow Plug, 7.6 lpm
– 7129716 Seal Kit (includes Key Nos. 60-65)
60 O-Ring, 11.1 x 15.9 mm
61 O-Ring, 19.1 x 23.8 mm
62 O-Ring, 85.7 x 92.1 mm
63 Rotor Seal
64 O-Ring, 9.5 x 14.3 mm
65 Seal, Nozzle & Venturi
66 7082087 Wave Washer
67 7199232 Rotor & Disc
Drain Plug Kit, 3/4"
– 7342665
(includes Key Nos. 64, 68 & 69)
68 Plug, Drain Seal
69 Spring
70 7337563 Clip, 3/4", pack of 4
Questions? Call Toll Free 1-800-693-1138
When you call, please be prepared to provide the model and serial number,
found on the rating decal, typically located on the rim below the salt lid hinges.
Valve Parts List
Description
To order repair parts call toll free 1-800-693-1138.
Manufactured and warranted by
Ecodyne Water Systems
1890 Woodlane Drive
Woodbury, MN 55125
Key
Part No.
No.
71 7370286
72 7337571
– 7113040
73
74
75 7082053
76 7081201
77 7342649
78 1202600
– 7257454
79 7081104
80 7095030
81 1148800
7114533
82
7204362
83 7084607
84 7146043
85 7167659
86 7170262
87 7199729
88 7309803
89 7337466
90 7342657
www.ecopure.com
or visit
25
Description
Bypass Valve Assembly, 3/4", in -
cluding 2 O-Rings (See Key No. 72)
O-Ring, 23.8 x 30.2 mm, pack of 4
Turbine & Support Assembly,
including 2 O-Rings (See Key No.
72) & 1 ea. of Key Nos. 73 & 74
Turbine Support & Shaft
Turbine
Valve Body
Retainer, Nozzle & Venturi
O-Ring, 6.4 x 9.5 mm, pack of 2
Nut - Ferrule
Nozzle & Venturi Assembly,
(includes Key Nos. 76, 77 & 79-87)
Housing, Nozzle & Venturi
Cone Screen
Flow Plug, 1.1 lpm
Nozzle & Venturi Gasket Kit
Gasket Only
Flow Plug, 0.57 lpm
Screen
Screen Support
O-Ring, 28.6 x 34.9 mm
Cap
Wire Harness, Sensor
Valve Cover
Screw, #10-14 x 5 cm, pack of 5
