5.9.5.2.

Connecting the TS-series access reader

The following figure shows the possibilities for connecting the TMR33 devices to a PZE-MasterIV for
access control. The TMR33 devices have to be set depending on the interface used (RS232 or
RS485).
RS 485
Settings of dip switch 6
Access MasterIV
ZK-; PZE-; AE-IV
More modules are possible.
PZE-MasterIV to 8 Modules
ZK-MasterIV to 16 Modules
Dip switch 8 is for terminate the RS485 bus line:
The DIP switches 1 - 5 are for bus configuration. Via the switches, the bus number of the device is
set. DIP switch 1 in position "ON" and switches 2 - 5 in position "'OFF"' stand for bus number "1".
DIP switches 1 and 2 in position "ON" and switches 3 - 5 in position "OFF" stand for bus no. "3".
Handbuch Datafox EVO 3.5 Pure
Combination module
Reader + Relay TMR33
(LTM)
Door module TMR33
Relay (TM)
Combination module
Reader + Relay TMR33
(LTM)
Door module TMR33
Relay (TM)
Seite 85
RS 232
Settings of dip switch 6
Reader TMR33
(L)
Reader TMR33
(L)
