2 TECHNICAL SPECIFICATIONS

Version: 0-100%LEL Methane, 5 sec. response time.
(Specification for other types on request)
GENERAL
Detection method
IR-Source
Gases detected
Self-test
Calibration
PERFORMANCE
Lifetime stability
(*)
Accuracy
(*)
Response time
Start-up time
(*)
(*) Refers to -20°C to + 45°C
DETECTOR WARNINGS
Early Dirty Optics
Dirty Optics
Detector failure
GD10P User Manual
IR-absorption, dual wavelength, dual path
Solid state IR source, 50Hz flash
Detector versions for several hydrocarbons as well as CO2.
Continuous
Factory set, no field recalibration
±5% of full scale (FS) reading
±3% FS between 0-50 % reading
±5% FS between 50-100 % reading
T20 = 1 sec.
T50 = 2.5 sec.
T90 = 6 sec.
Less than 60 sec., measuring 30 min. full specification
55% signal attenuation
70% signal attenuation
Main function fault or blocked optics.
Page 9 of 44
(Optional 0.3 sec)
(Optional 0.7 sec)
(Optional 1.6 sec)
