OUTPUT SIGNAL
Standard
Option
Maintenance
ELECTRICAL
Power supply
Power consumption
Connection
Cable entry
TEMPERATURE RANGE
Storage
Operating
Humidity (operation) 100% RH
HOUSING
Main compartment
Terminal comp.
Protection category
Housing material
Weight
Dimensions
WARRANTY
5 years full warranty on complete instrument
15 years warranty on the IR-sources
GD10P User Manual
Current source 4 – 20 mA, max. load impedance 500 Ohm
Current sink 4 – 20 mA
HART® interface
24 VDC, range 18-32 VDC
Approx. 3.5 W
3 wires (0.5mm2 - 1.5mm2)
M20 Ex e cable gland
-40°C to + 70°C (-40°F to +158°F)
-40°C to + 65°C (-40°F to +149°F)
Ex d IIC T6 Gb
Ex e
IP66/IP67 DIN 40050
Stainless steel SIS2343 (ASTM 316)
Approx. 2.9 kg (6.4 Lbs)
264L x 104W x 106H (mm) - 10.4 x 4.1 x 4.2 (inches)
